- Page 1 QUICK START MANUAL SSI2USB Adapter Sample: SSI2USB Adapter DB15 (VA01) (SSI Encoder: UCD-SHPPP-PPPP-L100-CRW) Copyright ©FRABA...
-
Page 2: Device Connection
Device Connection 1. Connect the encoder to the Terminal block. 2. Plug the Terminal block into the SSI2USB Adapter. 3. Plug the USB port to a PC. 4. Install the interface software in the PC. Copyright ©FRABA... -
Page 3: Software Installation
Software Installation 1. Click to download the instruction on the Adapter box. 2. Click to download the interface software. Easy to install. Copyright ©FRABA... -
Page 4: Pin Assignment
Pin Assignment 1. White pin to terminal 12. It is the GND level. 2. Grey pin to terminal 9. It is SSI DAT+. 3. Green pin to terminal 10. It is SSI CLK+. 4. Yellow pin to terminal 2. It is SSI CLK-. 5. - Page 5 Connect 1. Click to scan USB devices. 2. Choose device in the pull-down menu. 3. Click to connect. 4. Click to reset all the settings Copyright ©FRABA...
- Page 6 Power Supply Mode & SSI Parameter 1. Choose the power supply mode. 2. Click to power on the encoder. 3. Choose SSI mode between Binary and Gray. 4. Choose SSI Clock Frequency in the pull down menu. Copyright ©FRABA...
- Page 7 Measurement 1. Choose ST Bits. 2. Choose MT Bits. 3. Click on to display as Hex. 4. Single Sample. 5. Continues Sample Copyright ©FRABA...
- Page 8 Display 1. Displays the MT position. 2. Displays the ST position. 3. Display History messages. Copyright ©FRABA...
- Page 9 Preset/Out1 Function 1. Apply high signal on Out1. 2. Then remove the high signal from Out1. The present position will be set to the initial position. This is the preset function. Copyright ©FRABA...
- Page 10 Direction / Out2 Function 1. As long as there is high signal applied on Out2, the direction is inverted. 2. To restore default direction, remove the high signal on Out2. This is the function of changing Direction with the Out2 pin. Copyright ©FRABA...
- Page 11 Copyright ©FRABA...
