Treadmill by
Treadmill User Manual
SL-Q16-9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-Q16-9 and is the answer not in the manual?

Questions and answers

Summary of Contents for Revo SL-Q16-9

  • Page 1 Treadmill by Treadmill User Manual SL-Q16-9...
  • Page 2 Revo Treadmill Have an issue with your revo Enjoy hassle-free replacements, if your Revo is defective or damaged in transit, we’ll ship out a new one for ABSOLUTELY FREE! For Fast & Knowledgeable Service get in touch with our Customer Services Right Now! To check out more of the products we offer visit: www.revomadic.com...

  • Page 3: Safety Notice

    1. Caution To avoid any accidental injuries, please read this manual carefully before using. For safety purpose, do not stand on running belt while running. Please stop immediately for any feeling of vomit or jerky during using. Please adjust the speed slowly. Do not adjust the belt during using.

  • Page 4: Caution During Use

    −−−May cause injuryduetofall. The machine must be grounded. In the event of malfunction, grounding will provideapathofleast resistance for current to reduce the risk of electric shock. 4. Technical Specification Product Name: Treadmill Item No. SL-Q16-9 Voltage 110V Frequency 60Hz Speed 0.5-4MPH...

  • Page 5: Control Panel

    5. Control Panel Display (1.) “TIME” window has two modes which shows the running time. ①Forwardcounting time is from 0:00 to 99:59 minutes. ②Countdown is count to0fromtheset time(setting range: 5:00~99:00 minutes). The machine will stopslowlywhenitcounts to 0:00 and shows” end”, then the machine will come to thestandbymodeafter 5 seconds.
  • Page 6 1.3 After the treadmill is started, every window will be displayed cyclically at a ninterval of 5 seconds. You can press the "M" button to switch betweencyclicdisplay mode and single display mode. Function Of The Remote Control “Start/Stop”: (1) In standby or countdown mode: Pressing “start/stop” button to start the machine.Note: The default speed is 0.5mph.
  • Page 7 Functional Instruction 3.1 Sports mode: Press “start” key to start the machine and the SPEED window will count from“3 2 1 ”. Machine starts in P00 mode. Start countin (0:00~99:59, re-timecounting from 0:00 when overflow) Note: The default speed is 0.5mphandyoucanpress“+”“-” to adjust speed. 3.2 Countdown mode: when in standby, press“M”...

  • Page 8: Running Belt Adjustment

    7. Running Belt Adjustment Running belt deviate to left Start the machine by speed at 1-2mph without loading, use die nut to make the screw go 1/4circle(see fig1). Then make the machine running without loading 1-2 minutes. Please adjust like this to make the belt till to mid place. Running belt deviate to right Start the machine by speed at 1-2mph without loading, use die nut to make the screw go 1/4circle(see fig2).

  • Page 9: Troubleshooting

    9. Trouble Shooting Error Code Meaning Problem Problem Over Current Control board short 1. Open the motor cover and check Protection circuit or motor whether the motor is blocked. blocked Removethe block if yes. 2. Replace the control boardif it’snot blocked, or the error still shows.
