LDC1000/750/500/250 Series
Thin Cabinet
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LDC1000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for AURORA SIGNAGE LDC1000 Series

Summary of Contents for AURORA SIGNAGE LDC1000 Series

  • Page 1 LDC1000/750/500/250 Series Thin Cabinet User Manual...

  • Page 2: Copyright Statement

    Aurora logo and identifying product names and numbers here are trademarks of Aurora Signage Claimed copyright protection includes all forms of copyrighted material and information now permitted by statutory or judicial law, or hereunder granted. Product names used in this document may be...

  • Page 3: Disclaimer

    Disclaimer Aurora Signage and all corporation companies hereby disclaim any liability for property, equipment, building and electrical damage, personal injury and direct or indirect economic losses related to the use of or reliance on any information contained in this document, and /or as a result of improper, unsafe,...

  • Page 4: Table Of Contents

    Table of Contents COPYRIGHT STATEMENT..........................2 DISCLAIMER ..............................3 1. SAFETY INFORMATION ..........................5 2. PRODUCT INTRODUCTION .......................... 7 2.1 T .............................. 7 ABIENT ERIES 2.2 F ................................7 EATURES 2.3 S ........................8 PECIFICATIONS OF ABIENT ERIES 2.4 T ..........................

  • Page 5: Safety Information

    1. Safety Information Warn! Please read the safety precautions listed in this section carefully before installation, connection, operation and maintenance. Before installing, powering, operating or maintaining this product, please read the instruction manual carefully to understand the meaning of the signs in the instruction manual and on the product lock, and strictly follow the requirements listed in the safety protection measures.
  • Page 6 Whenever installing, maintaining or moving this product, please block off the work area or access. Check that all external masks and hardware are Injury Prevention locked correctly. When hoisting, it is necessary to install from top to bottom and disassemble from bottom to top. The power cords connected to the system have Power Cable special protection and are not intended for use by...

  • Page 7: Product Introduction

    2. Product Introduction 2.1 Thin Cabient Series Thin cabinet series has the ability to display high-quality content with excellent clarity and detail, making it an excellent indoor display product. Their flexibility in size and shape allows them to be configured to fit almost any space and can be tilted to create unique and visually stunning displays. It provides a versatile, high-quality and durable solution for a wide range of indoor video display applications.

  • Page 8: Specifications Of Thin Cabient Series

    2.3 Specifications of Thin Cabient Series 1000x500mm 750x500mm...
  • Page 9 500x500mm 1000x250mm...
  • Page 10 750x250mm 500x250mm...

  • Page 11: Thin Cabient Series Details

    2.4 Thin Cabient Series details Positioning post Data sticker Front mounting Wall mounting hole rear mounting hole screw holes 1000*500 rear cabinet picture...
  • Page 12 Receiving card Power supply Upper and lower mounting screws Front mounting screw holes Network port left and right mounting screws HUB board 1000*500 cabinet front picture...
  • Page 13 Upper and lower mounting screws Power supply Network port HUB board left and right mounting Receiving screws card 500*500 cabinet front picture...
  • Page 14 Upper and lower mounting screws Receiving card Power supply Network left and right mounting HUB board Flat cable HUB board port screws 750*500 cabinet front picture...

  • Page 15: Thin Cabient Product Specification Sheet

    2.5 Thin Cabient Product Specification Sheet Product T1.9 T2.5 T2.6 Pixel pitch(mm)： 1.95 Pixel density(dot/m²)： 262144 160000 147456 Led lamp SMD1212 SMD1515 SMD2121 Module size (mm * mm)： 250*250 250*250 250*250 Module weight (kg)： 0.46 0.46 0.46 Module resolution(PX* PX)： 128x128 100x100 96x96...
  • Page 16 Cabinet size (mm * mm)： 1000x500/750x500/500x500/1000x250/750x250/500x250 Cabinet weight (KG/SQM)： Cabinet thickness(mm)： 33.4 Working voltage (V)： 110-220 range of working temperature(℃)： -20~ +55 range of working temperature 10%~95% （RH）： Storage temperature range(℃)： -40~ +80 Storage temperature range(RH)： 10%~90% Dustproof and waterproof level IP20 户内...

  • Page 17: Installation

    3. Installation 3.1 Installation accessories and tools Connection plate (For installation and use during front maintenance of the cabinet) Top connection plate (For installation and fixation of cabinet and suspension beams) Screws (M6*55) (For use in fixing suspension beams and connection plate) Front maintenance connection plate screws...
  • Page 18 Locking tab tool (Hexagonal wrench M6, M8) Pre-module maintenance tools (P2.97.P3.91,P4.81 only) PA5*25 self-tapping screws (for installation on wooden walls) M10*80 expansion screw (For installation on concrete walls)
  • Page 19 1 meter long mounting wall (for wall-mounted installation) 0.5 meter long mounting wall (for wall-mounted installation) Wall mounted hook (for wall-mounted installation) 1 meter hanging bar (for hoist use) ）...
  • Page 20 0.5m hanging beam (for hoisting use) Allen wrench Laser level Spirit level...

  • Page 21: Installation Method

    3.2 Installation method 3.2.1 Install directly on the wooden wall Check whether the on-site wooden wall meets the construction conditions and whether the materials are standard. Use a laser level to check the installation surface of the wooden board and check whether the wall surface is flat.
  • Page 22 After the bottom row of cabinet is installed, they can be installed upwards one by one, locking the upper and lower connecting screws and the left and right connecting screws between the cabinets until the entire screen is installed.
  • Page 23 Step 3: Follow the connection diagram provided by our company to indicate the connecting wires, to be consistent with the drawings, and connect all wires. Cable Power cord...
  • Page 24 Step 4: Turn on the power and check whether all the cabinetses are powered on normally, whether there is a signal from the receiving card, and whether the indicator light flashes normally. Indicator Colour Status Comments Power indicator Always on Power input is normal Indicator Colour...
  • Page 25 Step 5: Install the module. First hang the module safety rope on the cabinets. body corresponding to the installation location, and then put the module back in sequence. The display surface must be ensured to be flat and there must be no front-to-back dislocation.
  • Page 26 ARTIAL INSTALLATION DIAGRAM...

  • Page 27: Install Directly On Concrete Wall

    3.2.2 Install directly on concrete wall Check whether the on-site concrete wall meets the construction conditions and whether the materials are standard. Use a laser level to check the installation surface and check whether the wall is flat. Step 1: Take out the cabinet and remove the module from the cabinet. If the module is not installed in the arrival cabinets, it can be installed directly, and this step can be skipped.
  • Page 28 When installing, you can first install the bottom row of cabinet and lock the left and right connecting screws of the cabinets. After the bottom row of cabinet is installed, it can be installed upwards one by one, locking the upper and lower connecting screws and the left and right connecting screws between the cabinet until the entire screen is installed.
  • Page 29 Step 3: Follow the connection diagram instructions provided by our company to connect the wires so that they are consistent with the drawings and complete all wire connected. Cable Power cord...
  • Page 30 Step 4: Turn on the power and check whether all the cabinetses are powered on normally, whether there is a signal from the receiving card, and whether the indicator light flashes normally. Indicator Colour Status Comments Power indicator Always on Power input is normal Indicator Colour...
  • Page 31 Step 5: Install the module. First, hang the module safety rope at the corresponding installation location of the cabinet, and then put the module back in sequence. The display surface must be ensured to be flat and there must be no front-to-back dislocation.
  • Page 32 Schematic diagram of partial installation...

  • Page 33: Wall Mounting Installation

    3.3 Wall mounting installation Check whether the on-site wall meets the construction conditions and whether the materials are standard. Use a laser level to check whether the concrete installation surface is flat. Preparation before installation: For a screen composed of multiple cabinetses, all modules can be removed first to facilitate cabinets wiring and installation connections.
  • Page 34 Step 4: Follow the above steps to install other cabinets one by one. During installation, lock the upper and lower connecting screws and the left and right connecting screws between the cabinetses. After the installation is completed, check whether the installation is smooth. Installation Diagram...
  • Page 35 Step 5: Follow the connection diagram provided by our company to connect the wires to make them consistent with the drawings, connect all the wires, and install the modules. Cable Power cord...
  • Page 36 Step 6: Turn on the power and check whether all the cabinets are powered on normally, whether there is a signal from the receiving card, whether the indicator light flashes normally, and whether the display cabinet is flush. Indicator Colour Status Comments Power indicator...
  • Page 37 Step 7: Install the module. First hang the module safety rope on the cabinets. body corresponding to the installation location, and then put the module back in sequence. The display surface must be ensured to be flat and there must be no front-to-back dislocation.
  • Page 38 ARTIAL INSTALLATION DIAGRAM...

  • Page 39: Hoist Installation

    3.4 Hoist Installation Check whether the site meets the lifting construction conditions and whether the lifting points, lifting ropes, etc. meet the installation standards. Preparation before installation: For screens with a large number of cabinets, remove all modules first to facilitate cabinet wiring and installation connections. After installing all the cabinets, follow the connection diagram provided by our company to connect the wires and install the screen module.
  • Page 40 Step 2: Install the second suspension beam and cabinet using the same method as the previous step, and lock the left and right connecting screws between the cabinet. Step 3: Install the other remaining cabinet in the same way as above, lock the left and right connecting screws and the upper and lower connecting screws between the cabinet install the corresponding connecting pieces, and adjust the flatness.
  • Page 41 Hanging bar Connect plate M6*55 Screw M6*16 Screw M6*16 Screws Cabinet connect plate Cabinet side view of the hoist...
  • Page 42 Step 4: Connect the power cord and network cable according to the drawings provided by our company. Turn on the power and check whether all the cabinetses are powered on normally, whether there is a signal from the receiving card, and whether the indicator light flashes normally. Cable Power cord...
  • Page 43 Indicator Colour Status Comments Power indicator Always on Power input is normal Indicator Colour Status Comments Running indicator Green Flash on every 1 second Receiving card is working properly, data connection is working, with video input Flash on every 3 seconds Data connection is abnormal Flash 3 times with an interval of 0.5s Data connection is normal, no video input...
  • Page 44 Step 5: Install the module. First hang the module safety rope on the cabinet. body corresponding to the installation location, and then put the module back in sequence. The display surface must be ensured to be flat and there must be no front-to-back dislocation.

  • Page 45: Steel Structure Installation

    3.5 Steel Structure Installation Preparation before installation: Check whether the on-site steel structure is consistent with the dimensions of the drawing, whether the steel structure is welded firmly, and whether the materials are standard. Use a laser level to check the steel structure installation surface and whether the square tube that fixes the screen is on a vertical surface.
  • Page 46 piece, and lock the left and right connecting screws of the cabinet.
  • Page 47 Step 2: After installing the bottom row of cabinet in the same way, install the upper cabinet in sequence, lock the connecting pieces, and lock the connecting screws between the cabinets. Step 3: Repeat the above steps 1 and 2 until the entire screen installation is completed.
  • Page 48 Step 4: Connect the power cord and network cable according to the drawings provided by our company. Turn on the power and check whether all the cabinet are powered on normally, whether there is a signal from the receiving card, and whether the indicator light flashes normally. Cable.
  • Page 49 Indicator Colour Status Comments Power indicator Always on Power input is normal Indicator Colour Status Comments Running indicator Green Flash on every 1 second Receiving card is working properly, data connection is working, with video input Flash on every 3 seconds Data connection is abnormal Flash 3 times with an interval of 0.5s Data connection is normal, no video input...
  • Page 50 Step 5: Install the module. First hang the module safety rope on the cabinet. body corresponding to the installation location, and then put the module back in sequence. The display surface must be ensured to be flat and there must be no front-to-back dislocation.

  • Page 51: Maintenance Methods

    4. Maintenance Methods 4.1 Maintenance Method Note: To ensure safety, all maintenance and installation operations need to be performed during a power outage. ） Module Maintenance （1 ◆ Hold the electric vacuum tool and press the button to remove the module. ◆...
  • Page 52 （3） Maintenance of receiving cards Turn off the power and remove the 4 screws holding the receiving card in place with a screwdriver. Replace the receiving card with a new one, install the set screws that were removed earlier. Tip: Please assemble in the direction indicated by the arrows. Indicator Colour Status...

  • Page 53: Troubleshooting

    4.2 Troubleshooting Fault status Failure Solution analysis 1. Make sure the screen power supply is correct. 1. The monitor has no power supply. 2. Check whether the DVI cable and other 2. The signal transmission cables are well connected. Set your transmission cable is computer's graphics card to copy or extend mode.
  • Page 54 1. The power cord is 1. Check whether the power supply of the cabinet is Black screen or duplicate Display number of pictures damaged correct. 2. The receiving card 2. Check whether the receiving card is working is damaged normally (red light is on) and transmitting signal (green light is flashing).
  • Page 55 Fault status Failure Solution analysis 1. Check whether the power supply voltage of the 1. The power supply is module is normal. abnormal. 2. Reinsert the winding displacement. The winding connecting 3. Replace the input winding displacement of this this module is loose. module.
  • Page 56 1. The graphics card Unable to connect to control settings are 1. Check whether the graphics card settings are system incorrect. correct. 2. The USB of the 2. Check whether the USB control cable is well control system is not connected or the USB driver software is properly inserted correctly or installed.

  • Page 57: Packaging

    5. Packaging Standard packaging: Cabinet and module are packing seperately Cabinet : 8pcs in one wooden case Module: 64pcs in one cabinet...
