Quick Start Guide
Product model: OH_Prod0001
ATTENTION! Make sure to read the Instructions for Use before using
this product. It contains important safety information. Do not only
read this Quick Start Guide.
ATTENTION! The Vertica
intimate medical treatment at home. The device left our factory
clean and ready for use. The device will be considered as "used" after
removing or damaging the tamper-evident seal on the device.
device is designed for personal and
Ⓡ
These are the original English instructions
February 2024 | OH_Misc0021_RevD
Advertisement
Table of Contents
Related Manuals for Ohh-Med Medical vertica OH Prod0001
Summary of Contents for Ohh-Med Medical vertica OH Prod0001
- Page 1 Quick Start Guide Product model: OH_Prod0001 ATTENTION! Make sure to read the Instructions for Use before using this product. It contains important safety information. Do not only read this Quick Start Guide. ATTENTION! The Vertica device is designed for personal and Ⓡ...
-
Page 2: Table Of Contents
Quick Start Guide CONTENTS 1 Important Notes 2 Contraindications 3 Description of the user 4 Product elements The Vertica device and pad The control panel 5 Safety instructions 6 Learning the basic operation of the Vertica device Setting the device to on and off Setting the energy level Activating and deactivating the treatment mode 6.3.1... -
Page 3: Important Notes
1 IMPORTANT NOTES Congratulations on your new Vertica device. For your safety Ⓡ and the success of treatments: • Read and understand the entire Instructions for Use before using your Vertica device. Keep the Instructions for Use and Quick Start Guide for future reference. •... -
Page 4: Description Of The User
Quick Start Guide 3 DESCRIPTION OF THE USER • This document is intended for the home-user of the Vertica device. • The Vertica device is intended for adults only. 4 PRODUCT ELEMENTS 4.1 THE VERTICA DEVICE AND PAD Name Name Control panel Pad plug (magnetic) RF electrodes (metal domes) -
Page 5: The Control Panel
4.2 THE CONTROL PANEL RING RING+PAD Function Power/mode button To set the device to on or off and select the RING mode or RING+PAD mode RING mode indicator To indicate the RING mode is selected Energy level button (-) To decrease the energy level Energy level button (+) To increase the energy level Energy button button... -
Page 6: Safety Instructions
Quick Start Guide 5 SAFETY INSTRUCTIONS WARNING! Read and understand the Instructions for Use and its safety instructions before using this device. Failure to observe the safety instructions can result in physical injury, damage, or harm to the environment. The manufacturer accepts no liability for injury or damage resulting from failure to observe the safety instructions. -
Page 7: Activating And Deactivating The Treatment Mode
To set the energy level: 1. Push the energy level button (-) to decrease the energy level. 2. Push the energy level button (+) to increase the energy level. The energy level indicator shows the following conditions, based on the set energy level: Energy level indicator Energy level... - Page 8 Quick Start Guide What happens in the treatment mode: 1. The device automatically checks for contact with the penile shaft. 2. Only when contact with the penile shaft is detected, the RF energy indicator comes on and RF energy is delivered (the erectile tissue is receiving treatment).
-
Page 9: Let's Get Started With The Treatment
7 LET’S GET STARTED WITH THE TREATMENT! WARNING! • Make sure you have read the safety instructions. • Make sure the Vertica device is fully charged. See Charging the Vertica device for instructions. • Do not do the treatment while standing. Make sure you are in a comfortable seated position to do the treatment. -
Page 10: Preparation
Quick Start Guide 7.1 PREPARATION It is recommended to • make sure you are in a comfortable seated position, for example on a chair or the edge of the bed • make sure you have enough gel for the full treatment •... -
Page 11: First Part Of The Treatment (Ring Mode)
7.2.1 FIRST PART OF THE TREATMENT (RING MODE) 1. Apply a three to five millimeter thick layer of gel (ultrasound or RF conductive gel) on the penis shaft. Make sure to cover the full surface of the penis shaft. To achieve optimal treatment, the domes of the RF electrodes on the ring need to be covered by the gel. - Page 12 Quick Start Guide 4. Push the ring handle to the left to open the ring and insert the penis through the ring. Slide the Vertica device as close to the body as possible. The device should make contact with your pelvic area. 5.
- Page 13 6. Select the desired energy level with the energy level buttons (+/-). The energy level indicator shows the set energy level. It is recommended to start every treatment at level one for at least 1 minute and increase based on the sensation of heat that you desire.
- Page 14 Quick Start Guide 8. Wait 30 seconds or wait until the RF energy indicator is off for at least 3 seconds and move the device about one centimeter toward the glans (dome of the penis). Always move the device toward the glans (dome of the penis) and not toward the body.
- Page 15 13. Gently release the ring handle to let the ring make a comfortable and tight contact of all the RF electrodes with the penile shaft. 14. Repeat steps 7 to 13 until a total treatment time of 15 minutes is achieved. The device will vibrate multiple times and the RING mode and RING+PAD mode indicators will blink to indicate the treatment is finished.
-
Page 16: Second Part Of The Treatment (Ring+Pad Mode)
Quick Start Guide 15. Push the ring handle to open the ring and slide the device off the penis. 16. Press the power/treatment mode button to continue to the RING+PAD mode. 7.2.2 SECOND PART OF THE TREATMENT (RING+PAD 3-5 mm MODE) 1. - Page 17 2. Connect the pad plug to the pad port. The magnetic pad plug attaches only in one direction. Change the position of the pad plug if it does not connect. 3. Curve the cable of the pad under the device so the RF electrodes point up.
- Page 18 Quick Start Guide 4. Make sure RING+PAD mode is selected: a. When the device is off: Push the power/treatment mode button to set the device to on. The device is in standby mode. The RING mode indicator comes on and the energy level indicator shows energy level one.
- Page 19 Push the power/ treatment mode button to select the RING+PAD mode. The RING+PAD mode indicator comes on and the RING mode is off. b. When the device is on and the RING mode indicator is on: Push the power/ treatment mode button to select the RING+PAD mode.
-
Page 20: Cleaning The Vertica Device
Quick Start Guide 8 CLEANING THE VERTICA DEVICE WARNING! • Set the device to off before you do any cleaning tasks. • Do not immerse the device in water! Only rinse the device. The device is water-resistant at the area of the RF electrodes, but the device can not be immersed. - Page 21 2. Clean the device and the pad with a moist cloth or a water based wet-wipe. 3. Flush the RF electrodes on the ring and pad with running tap water and fully remove all gel residue. If necessary, use warm water to dissolve the gel better. WARNING! Do not immerse the device in water.
- Page 22 Quick Start Guide 4. Make sure all gel residue is fully removed and fully dry the device and the pad with a clean dry cloth.
- Page 23 G&D&Y Tolstraat 112, 1077 EL Amsterdam, The Netherlands Copyright © 2023 Ohh-Med Medical® Ltd. Vertica® is a trademark of Ohh-Med Medical® Ltd. All rights reserved. Patented technology. FOR MORE INFORMATION SCAN THE QR CODE Issue Date: February 2024 | OH_Misc0021_RevD...
