JAZZY
CARBON ULTRA-LITE
Formatted: Centred
POWER CHAIR
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CARBON ULTRA-LITE and is the answer not in the manual?

Questions and answers

Related Manuals for Jazzy CARBON ULTRA-LITE

Summary of Contents for Jazzy CARBON ULTRA-LITE

  • Page 1 JAZZY CARBON ULTRA-LITE Formatted: Centred POWER CHAIR OWNER'S MANUAL...

  • Page 2: Table Of Contents

    [include pg numbers] TABLE OF CONTENTS 1. LETTER TO USERS 2. ATTENTION 3. PRODUCT DESCRIPTION 4. INSTALLATION & ADJUSTMENT 5. OPERATING INSTRUCTIONS 6. BATTERY AND CHARGER 7. DAILY CHECKS & MAINTENANCE [fix section header Deleted: CHECKING 8. WARRANTY 9. BASIC TROUBLESHOOTING 10.

  • Page 3: Letter To Users

    1. LETTER TO USERS This product is designed and produced by Kunshan Hi-Fortune Health Products Co., Ltd on behalf of Pride Mobility Products UK, Ltd. This Owner's Manual is part of the product specifications; please ensure it accompanies every Deleted: product sold and it is read thoroughly and understood before operating or driving the powerchair.

  • Page 4: Attention

    2.ATTENTION 2.1 UNPACKING INSPECTION Deleted: the powerchair and Please use the Parts List provided to check whether parts or components damaged or Deleted: (according to the Parts List provided with the missing If there is any damage or missing parts, contact your dealer or distributor immediately.
  • Page 5 2 ATTENTION Note: When using your power chair on streets or footpaths, local laws and regulations apply. GENERAL SAFETY–WARNINGS FOR SAFE USE MANDATORY ! This complete user’s manual should be read and fully understood before using and driving the powerchair. WARNING! Disobeying the instructions described in this manual may result in damage to the power- chair or which are Deleted:...
  • Page 6 2 ATTENTION 2.4 INTENDED USE This powerchair incorporates manufacturer’s own designs and can be used in confined spaces both indoors and outdoors by the occupant and it is intended to comfortably transport adult people only excluding goods but user’s weight should be limited 125kg (275 lbs).
  • Page 7 2 ATTENTION POSSIBLE SOURCES OF RADIATION INCLUDE: Portable receiver and transmitter installations (receiver and transmitter with fixed antenna mounted directly on the transmitting unit) Transmitting and receiving sets ● Cell phones or "walkie talkie" ● portable TV, radio and navigation devices ●...

  • Page 8: Product Description

    3 PRODUCT DESCRIPTION 3.1-A PRODUCT FEATURES (HP200) 3.1.1 This product consists of frame, wheels, seat, armrest, lithium battery, motor and controller with a Deleted: lightweight and compact design. The whole wheelchair can be folded by one button and it can be easily carried or rolled Deleted: It has the...
  • Page 9 3 PRODUCT DESCRIPTION 3.1-B PRODUCT FEATURES (HP205) 3.1.1 This product consists of frame, wheels, seat, armrest, lithium battery, motor and controller. It has the lightweight and compact design. The wheelchair can be folded by one button and it can be easily pulled Deleted: whole after folding.
  • Page 10 3 PRODUCT DESCRIPTION 3.3 CIRCUIT DIAGRAM Control box The right motor The left motor MOTOR MOTOR RIGHT LEFT BATTER Battery pack Joystick...
  • Page 11 3 PRODUCT DESCRIPTION 3.4 TECHNICAL PARAMETERS Technical models HP200 HP205 Frame Carbon fibre (Carbon fibre + aluminum alloy) Weight (W/T Battery) 14.5KG 16.5KG Max. load 125kg 125kg Motor (Rated output power) 24V 170W 24V 170W 24V 20Ah/10.4Ah Li-ion battery 24V 20Ah/10.4Ah Li-ion battery Battery (optional) (optional)

  • Page 12: Installation & Adjustment

    4.INSTALLATION & ADJUSTMENT 4.1 CONTROLLER INSTALLATION/REMOVAL Insert the upper bracket of the joystick into Upper bracket the fixed tube of the armrest as shown in the Joystick diagram then tighten it with the knob. Operate oppositely if operated with left hand.
  • Page 13 4.INSTALLATION & ADJUSTMENT 4.3 BATTERY BOX INSTALLATION, REMOVAL Deleted: OR REPLACEMENT 4.3.1 Installation: Push the battery box forward along the U-shaped fixing strip and align it with U-shaped the front terminal until it clicks in place. fixing strip Battery U-shaped fixing strip Completed Installation Diagram 4.3.2 Removal or replacement: Remove the...
  • Page 14 4.INSTALLATION & ADJUSTMENT 4.4 SEAT BELT REMOVAL AND INSTALLATION 1. Hold the buckle on the seat belt and press together to unbuckle the seat belt. 2. Align the buckle with the insert, press down until you hear the "click" sound. ①...
  • Page 15 4.INSTALLATION & ADJUSTMENT 4.6 UNFOLDING THE POWERCHAIR 4.6.1 Hold the backrest frame with your left Footrest hand and open the footrest with your right hand as shown in the right diagram. Backrest frame 4.6.2 Before opening the powerchair, place the whole vehicle flat; ①...
  • Page 16 4.INSTALLATION & ADJUSTMENT 4.6.3 When the backrest frame is opened, the Hook wheelchair is fully opened when you hear the "click" sound and the hook snaps in place. Backrest Seat frame 4.6.4 The wheelchair is fully opened.
  • Page 17 4.INSTALLATION & ADJUSTMENT 4.7 FOLDING THE WHEELCHAIR Hook Backrest frame Attention: Please remove the cushion, so that the wheelchair can be easily folded. 4.7.1 Step down the foldable lock handle with your right foot, and at the same time, hold the backrest frame with your right hand and push it forward until the hooks on both sides of the wheelchair are released as shown in the right...
  • Page 18 4. INSTALLATION & ADJUSTMENT 4.7.4 Once folded, flip the footrest inward again and put it together as shown in the right diagram. Footrest 4.8 STANDING THE FOLDED WHEELCHAIR After the wheelchair is folded, it can be stored vertically to save storage space. WARNING 1.

  • Page 19: Operating Instructions

    5. OPERATING INSTRUCTIONS 5. OPERATION – DRIVING THE POWERCHAIR 5.1 JOYSTICK 1. Low Speed Button 5. Horn Button 2. On/off Button High Speed Button 3. Battery Gauge 7. Joystick lever 4. Speed Indicator LOW SPEED BUTTON: Press to slow the speed. 2.
  • Page 20 5. OPERATING INSTRUCTIONS 5.2 BEFOR SITTING ON YOUR POWERCHAIR ● Make sure the battery box switch is in the ‘On’ position. ● Make sure the Freewheel levers are in the ‘Lock’ position (see 4.2 Manual Freewheel lever). ● Make sure that the battery is fully charged. ●...

  • Page 21: Battery And Charger

    6. BATTERY AND CHARGER 6.1 GENERAL INFORMATON & INSTRUCTIONS ON CHARGING Your powerchair requires a lithium battery that is sealed and maintenance free. The bat- tery is recharged by the supplied off-board charging system. ● Fully charge your powerchair’s battery for at least 10 to 12 hours prior to using it for the first time.
  • Page 22 6. BATTERY AND CHARGER 6.2 CHARGING YOUR BATTERIES ● Make sure you read and understand the battery charger’s user manual, if supplied, as well as the safety notes on the charger. ● Turn off the powerchair. ● Decide on which charging socket to use.
  • Page 23 6. BATTERY AND CHARGER WARNING:Turn on the switch on the battery box prior to charging. Deleted: battary Deleted: ● Put the charger plug into the outlet point. ● Do not switch on the battery charger until all the plugs are in position. ●...
  • Page 24 6. BATTERY AND CHARGER WARNING! Risk of short circuit and electric shock if the battery charger has been damaged. Never use the charger if it has been dropped or damaged. WARNING! Risk of electric shock and damage to the batteries-Never attempt to recharge the batteries by attaching cables directly to the battery terminals.
  • Page 25 7. DAILY CHECKING & MAINTENANCE Protect your power chair by having it checked regularly. We strongly advise you to have your powerchair checked at least once a year by a qualified dealer, who will only use the Deleted: correct spare parts. This periodic inspection will ensure you that the powerchair will func- tion safely for years.

  • Page 26: Warranty

    8 WARRANTY WARRANTY POLICY: LIMITED WARRANTY. IMPORTANT NOTICE-TO ENSURE THIS WARRANTY IS VALIDATED IT HAS TO BE COMPLETED AND RETURNED TO DEALER WITHIN 14 DAYS OF PURCHASE 8.1 ONE-YEAR LIMITED WARRANTY: For one (1) year from the date of delivery, we will replace at our discretion to the original purchaser, free of charge, any part or electronic component found upon examination by an authorized representative of Manufacturer to be faulty.
  • Page 27 8 WARRANTY 8.5 NOTICES TO CONSUMER There are no other express warranties. To the extent permitted by law, any implied warranty (including a warranty of merchantability or fitness for a particular purpose) is limited to: 1. One (1) year from the day of purchase. 2..

  • Page 28: Basic Troubleshooting

    9 BASIC TROUBLESHOOTING 9.1 FLASH CODE TROUBLE SHOOTING Fault Codes If a system trip occurs, you can find out what has happened by counting the number of flashes on the Joystick Module BDI. Below is a list of self-help actions. Try to use this list before you contact your service agent. Go to the number in the list which matches the number of flashes on the BDI and follow the instructions.

  • Page 29: Transportation And Storage

    10 TRANSPORTATION AND STORAGE 10.1 TRANSPORTATION AND STORAGE a）Ambient temperature range：-25℃—50℃ / -13°F—122°F； b) Relative humidity：≤80% c) Atmospheric pressure range: 86kPa～106kPa; d) Can be transported in general transportation. 10.2 Operation a）Ambient temperature range：-5℃—40℃ / 23°F-104°F； b) Relative humidity：≤85% c) Atmospheric pressure range: 86kPa～106kPa;...
  • Page 30 Manufacturer information: Kunshan Hi-Fortune Health Products Co., Ltd No.625 Juxiang Road zhangpu town , Kunshan City Jiangsu Province, China TEL:+86 512 55195100. FAX: +86 512 55199300 www.hi-fortune.net UK Responsible Person/Northern Ireland Authorised Representative Information: SUNGO Certification Company Limited 3rd Floor, 70 Gracechurch Street EC3V 0HR London, England, United Kingdom...
