Ocean WL T1 Series Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Washing Machine
WL T1 SERIES
SERVICE MANUAL
Specifications are subject to possible modifications without prior notice.
Les présentes spécifications sont susceptibles d'être modifiées sans préavis.
Las especificaciones estàn sujetas a cambios sin previo aviso
Pictures are only sketches which may be different from your equipment.
Les images sont seulement de croquis qui peuvent être différentes du design de votre équipement.
Las imágenes son sólo los bosquejos que pueden ser diferentes de su equipo.
... someone to rely on

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WL T1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ocean WL T1 Series

Summary of Contents for Ocean WL T1 Series

  • Page 1 Washing Machine WL T1 SERIES SERVICE MANUAL Specifications are subject to possible modifications without prior notice. Les présentes spécifications sont susceptibles d'être modifiées sans préavis. Las especificaciones estàn sujetas a cambios sin previo aviso Pictures are only sketches which may be different from your equipment.

  • Page 2: Product Specifications

    Specifications 1.1. Product Specifications 42 lt 44 lt 49 lt 50 lt 54 lt 55 lt 60 lt 59 lt 61 lt 62 lt Product Type Front Loader Capacity 5 kg 6 kg 7 kg 8 kg 9 kg 10 kg Max Spin Speed (r/min) 800 - 1000 - 1200 - 1400 1200 -1400...

  • Page 3: Installation Instructions

    Installation Instructions 2.1. Moving and Installing 2.1.1. Removal of Transportation Screw Transportation screws, which are located at the back The holes where the transport screws have been side of the machine, must be removed before running removed should be covered with the plastic transport the machine.
  • Page 4 2.1.4. Water Supply Connection After connection is complete, check for leakage by Washing machine is supplied with a single (cold) water turning on tap completely. inlet. Make sure that water inlet hoses can not become folded, To prevent leakage from the connection joints, a rubber damaged, stretched or crushed when the washing washer is included in the hose packing.

  • Page 5: Lcd Screen, Function Buttons & Knobs

    Operating Instructions 3.1. LCD Screen, Function Buttons & Knobs SW4 SW3 SW2 SW1 ON/OFF Start / Pause Option Selection Spin Speed Selection Temperature Selection Start / Pause Led Option Led Double dot led Led of “1” 7-segment display 1 7-segment display 2 7-segment display 3 3.2.

  • Page 6: Child Lock

    3.3. Child lock during selection: Child Lock Machine does not respond to any pressing of buttons or changing position of program knob. CL at 7 segment display will Activation make fast blink for 2 sec to indicate child lock is activated. Press the SW2 and SW3 buttons simultaneously for 3 sec.
  • Page 7 Test Mode Step6: The option 1 button is pushed 4.1. Autotest The EV1 and EV2 are activated concurrently until it reaches pressure sensor's first level frequency ( Hz ) for 5 seconds. * This test is for quick checking of the product. You can not see the failure codes.
  • Page 8 Flow chart of the autotest: During test “AU” is visualized on display, at the end of the test “--” is visualized and door is unlocked. During test, pressing other buttons makes no change on display.
  • Page 9 Service Mode 5.1. Service Autotest End users can only see E1-E2-E3-E4. During service autotest, other failures can be seen. To activate service autotest, Press SW3 button and simultaneously position program knob to 1. After 3 sec, door will be locked, and machine enters service autotest mode. Release SW3 button. In T0 "SA"...

  • Page 10: Failure Codes

    5.2. Failure Codes Indication For User Indication For Service Error Indication Error Number Yes/No Yes/No Door is not locked Door is unlocked during programme Lack of water Pump failure Overflow NTC or Heater Failure Motor Failure - 1 (Tachometer open-short circuit or motor connector is disconnected) Configuration Failure Motor Triac Failure...
  • Page 11 Water tap is closed. Open water tap. The water inlet hose may be bent. Check the water inlet hose. The water inlet hose is obstructed. Clean the filters of water inlet hose. Machine does not receive water. The water inlet filter is obstructed. Clean the valve inlet filters.

  • Page 12: Top Plate

    Disassembly and Assembly Instructions 7.1. Top Plate Pull the door up. Remove two screws that fix the top-plate at the back. Push the top-plate back and pull it up. Remove screws that fix the door group. 7.2. Door Put the door outside plastic with helping screwdriver as it is Remove two screws that fix the door.
  • Page 13 Remove the door inside plastic as it is shown in the picture. Remove the door handle pim as it is shown in the picture. Remove six screws that fix the door hinge as it is shown in the picture. Remove the door handle as it is shown in the picture.

  • Page 14: Tub Bellows Seal

    7.3. Tub Bellows Seal First remove the spring wire fixing the tub bellows seal by using the small size screw driver. Pull the tub bellows seal as it is shown in the picture. 7.5. Control Panel Remove the screw which fix the control panel to the front Remove the tub bellows seal-body fixing spring.
  • Page 15 Pull the control panel up. Remove electronic card as it is shown in the picture. Release the cable group as shown in the picture. Remove the cable group as it is shown in the picture. Remove the cable from display card, remove the display Remove electronic card cover as it is shown in the picture by card and digit part as it is shown in the picture by using small using small screw driver.

  • Page 16: Front Panel

    7.6. Front Panel Remove the pomp cover as it is shown in the picture. Remove selection button as it is shown in the Picture.
  • Page 17 Remove two screws fixing bottom the front panel. Remove two screws fixing the body group at the front as it is shown in the picture. Lift upper support braket up slightly it it ishown in the picture. Remove two screws fixing upper the front panel. Remove the pump cover housing as it is shown in the Remove two screws fixing door lock it is shown in the picture.

  • Page 18: Detergent Drawer Housing

    7.7. Detergent Drawer Housing Remove detergent drawer group clips from the upper support bracket as it is shown in the picture. Remove the front panel as it is shown in the picture. Remove the tub seal clamp by using the pliers, which is attached to the detergent drawer housing.

  • Page 19: Electronic Pressure Switch (Eps)

    Turn the feed valve counter clockwise slightly to remove. Remove two screws fixing the parasite filter. Pull the power cable group up as it is shown in the picture. Remove the detergent drawer screw. Remove parasite fitler fixing body group as it is shown in the Remove the detergent drawer housing assembly.

  • Page 20: Pump Motor

    Pull the EPS upward to remove as it is shown in the picture. Remove pipe clip fixing the tub outlet hose. Remove the eps hose handcuffs and eps hose as it is shown Remove the connector that is connected to the pump motor. in the picture.

  • Page 21: Twinjet System

    Pull the counterweight back 7.14. Twinjet System* *(If product has TJ System) 1. Remove the clamps with the help of screwdriver, pull the hose upwards and remove it from the nozzle. 7.13. Heater Remove the four connectors that is connected to the heater. 2.

  • Page 22: Transport Screw

    5. Remove the pump socket. 7.16. Transport Screw Remove four transport screws (box wrench size 10 mm) 6. The clamps on the pump are slid with the help of pliers and the hoses are pulled out. Hold the transport screw and pull it out. 7.15.

  • Page 23: Upper Counterweight

    7.17. Upper Counterweight Remove two screws fixing the upper counterweight by using box wrench size 13 mm. Remove the four screws fixing the spring hanger sheet iron. Remove the upper counterweight Remove the washing group as it is shown in the picture. 7.18.

  • Page 24: Driven Pulley

    7.20. Belt 7.22. Motor Remove the belt as it is shown the picture. Remove the four screws fastening the motor under the tub by using T40 7.21. Driven Pulley Pull the motor up for disassembly. Remove the screw fixing driven pulley it is shown the picture (By using T40).

  • Page 25: Pressure Switch Hose Group

    7.24. Pressure Switch Hose Group 7.25. Remove screw fixing the pressure switch water reservoir. Remove twenty four screws fixing tub using box wrench size 8 mm. 7.26. Drum Remove the tub exit with bellow hose with ball by using box wrench size 10 mm.

  • Page 26: Component Specifications

    Component Specifications 8.1. Drain Pump Drain pump is both a mechanical and elektrical component which is used to drain water inside the washing machine. It has an synchronous motor inside. For better performance maintanance, pump filter should be cleaned regularly. 8.1.1.
  • Page 27 8.2. Resistance Heating element (Resistance) is a component which is desingned to regulate temperature of water inside the drum. It has three connections: Phase, notral and ground connections. 8.2.1. Technical Features Kind of heating Tubular heating element with NTC – sensor Nominal voltage 230 V Nominal power...
  • Page 28 8.3. Component which sends signals to PCB about the water temperature inside the tub. The Resistance (Ohm) value of the NTC decreases as the temperature increases. 8.3.1. Technical Features Tem (°C) R min (kΩ) R max (kΩ) 54,9 62,6 43,0 48,6 33,9 38,1...
  • Page 29 8.4. Valve Valve is an electrical and mechanical component which is designed to take water from the network system into the washine machine. It is operated by PCB card. 8.4.1. Technical Features Nominal voltage 220 – 240 V Nominal power 8 VA Frequency 50-60 Hz...
  • Page 30 8.5. Electronic Pressure Switch (EPS) 8.5.1. Technical Features Electromagnetic field occurs as a result of the vibration of the membrane which is under pressure in the coil. The nucleus part is moved up and down by the electromagnetic field. The water level is regulated by the frequency which is controlled by the PCB and changes according to the movement of the nucleus part.
  • Page 31 8.6. Motor The washing machine has an asynchronous motor. It is controlled by the PCB. It is essential to check the motor for correct diagnosis and quick servicing. In the below picture, socket points on the motor is shown to measure with multimeter. Tacho Socket Terminal...
  • Page 32 Tacho and stator (full field-half field) ohm resistance values for the motor types are listed in the below table. STATOR AUXILIARY WINDING TAKO MOTOR CODE SUPPLIER Resistance Resistance Resistance 32016268 WELLING 2,00 ± %7 Ω 66,6± %7 Ω 32030654 G&J 1,86-2,14 Ω...
  • Page 33 8.7. Door Lock Door lock is activated at the beginning of the program in order to prevent the door from opening. It can be unlocked approximately after 2 minutes of the program end. This time delay is caused by the PTC which is assambled in the door lock. 8.7.1.
