CROMTECH™ GENERATORS
OPERATION & INSTRUCTION MANUAL
Thank you for your selection of a CROMTECH™ Generator.
This Operation Manual explains its use, installation, checking and
maintenance. We suggest that you retain this manual for ready reference
regarding proper handling of CROMTECH™ Generator.
Spare Parts & Service
Phone: 1300 554 524
Freecall Fax: 1800 636 281
spareparts@crommelins.com.au
www.crommelins.com.au
WA Metro 9350 5588
East Coast 1300 650 659
WA Regional 1800 655 588
email@crommelins.com.au
Advertisement
Table of Contents
Related Manuals for Crommelins CROMTECH GEN4-3200
Summary of Contents for Crommelins CROMTECH GEN4-3200
- Page 1 We suggest that you retain this manual for ready reference regarding proper handling of CROMTECH™ Generator. Spare Parts & Service Phone: 1300 554 524 Freecall Fax: 1800 636 281 spareparts@crommelins.com.au www.crommelins.com.au WA Metro 9350 5588 East Coast 1300 650 659 WA Regional 1800 655 588...
- Page 2 Thank you very much for purchasing a CROMTECH™ Generator. This manual covers operation and maintenance of the CROMTECH™ Generator. This CROMTECH™ Generator can be used in the trade, agricultural, general purpose and recreational industries. Never use this generator for any other purpose. Please take a moment to familiarise yourself with the proper operation and maintenance procedures to maximise the safe and efficient use of this product.
-
Page 3: Table Of Contents
1. INDEX Safety Precautions Symbols and Meanings Pre-operation Checks Operating Procedures 8 - 9 Wattage Information Specifications Petrol Models Standard Generator & Trade Pack Options Maintenance Schedule How –to Maintenance Periodic Operation and Inspection Transporting Preparation for Storage Troubleshooting 3 CROMTECH™GENERATOR Operation & Instruction Manual... -
Page 4: Safety Precautions
2. SAFETY PRECAUTIONS Please make sure you review each precaution carefully. Pay special attention to statement preceded by the following words. “WARNING” indicates a strong possibility of severe personal injury or loss of life if instructions are not followed. “CAUTION” indicates a possibility of personal injury or equipment damage if instructions are not followed. - Page 5 If wet, wipe and dry it well before starting. Do not pour water directly over the generator, nor wash it with water. Ensure all necessary electrical grounding procedures are followed during each and every use. Failure to do so can be fatal. Do not contact the generator to a commercial power line as connection may short circuit the generator and ruin it or cause electric shock hazard.
-
Page 6: Symbols And Meanings
6 CROMTECH™GENERATOR Operation & Instruction Manual... -
Page 7: Pre-Operation Checks
3. PRE-OEPERATION CHECKS 1. CHECK ENGINE OIL Before checking or refilling oil, be sure generator is located on stable and level surface with engine stopped. Remove oil filler cap and check the engine oil level. • • If oil level is below the lower level line, refill with suitable oil to upper level line. •... -
Page 8: Operating Procedures
6. GROUNDING THE GENERATOR (if applicable) • Theses Generators are ground to earth via the frame. • If grounding to Earth via an Earth spike/stake is required, follow below instructions. o To ground the generator to the earth, connect the grounding lug of the generator to the grounding spike driven into the earth or to the conductor which has been already grounded to the earth. -
Page 9: Wattage Information
3. OIL SENSOR a) The oil sensor detects the fall in oil level in the crankcase and automatically stops the engine when the oil level falls below a predetermined level. b) When engine has stopped automatically, switch off generator’s AC circuit breaker, and check the oil level. -
Page 10: Specifications Petrol Models
6. SPECIFICATIONS GENERATOR MODEL GEN4-3200 GEN6-5000 GEN8-7000 GEN10-8000 Power Factor (max.) 4.0kw 6.0kw 8.5kw 10.0kw Wattage - Maximum Output 3200w 5000w 7000w 8000w Wattage - Continous Output 3000w 4700w 6400w 7500w Mecc Alte Alternator (Brushless) S15W-150/2 S16W-15/2 S20W-110/2 Type Single Phase, 2 Pole Voltage regulating system Capacitor AC Output... -
Page 11: Maintenance Schedule
8. MAINTENANCE SCHEDULE • Check oil level DAILY Check all components according to “PRE-OPERATION CHECKS.” • EVERY • Wash air-cleaner element (more often if used in dirty/dusty environments). 50 HOURS Check spark plug, clean if necessary. • EVERY • Change engine oil. *- more often if used in dirty/dusty environments. 100 HOURS Clean spark arrestor. -
Page 12: How -To Maintenance
9. “HOW-TO” MAINTENANCE CAUTION Make sure the engine is stopped before starting any maintenance, servicing or repair. NOTE It is recommended to use ear protection when performing operation, maintenance and repair of the generator set. 1. ENGINE OIL CHANGE (refer to engine manual for full details) a) Change engine oil every 100 hours. -
Page 13: Periodic Operation And Inspection
10. PERIODIC OPERATION AND INSPECTION When generator is used as an emergency electrical power source, periodic operation and inspection is required to ensure machine will operate when needed. Fuel (gasoline/diesel) and engine oil will deteriorate overtime, and this may cause the engine to be difficult to start and will result in improper engine operation and fault. -
Page 14: Preparation For Storage
12. PREPARATION FOR STORAGE The following procedures should be followed prior to storage of your generator for periods of 6 months or longer. • Drain fuel from fuel tank carefully by disconnecting the fuel line. Gasoline/diesel left in the fuel tank will eventually deteriorate making engine starting difficult. •... -
Page 15: Troubleshooting
If your generator still fails to start or generate electricity, contact your nearest SUBARU engine dealer or service agent for further information or corrective procedures. To locate your nearest service agent, go to www.crommelins.com.au. When Engine Fails to Start: Check if choke lever is in its proper position. - Page 16 CROMTECH™ GENERATORS OPERATION & INSTRUCTION MANUAL Spare Parts & Service Phone: 1300 554 524 Freecall Fax: 1800 636 281 spareparts@crommelins.com.au www.crommelins.com.au WA Metro 9350 5588 East Coast 1300 650 659 email@crommelins.com.au 16 CROMTECH™GENERATOR Operation & Instruction Manual...
