THREE POINT HITCH CHIPPER
MODELS BX42S
ASSEMBLY INSTRUCTION MANUAL
Please review and understand the
operators manual before attempting
to operate this machinery.
EMB MANUFACTURING INC.
4144 BOOMER LINE
ST. CLEMENTS, ON
N0B 2M0 CANADA
PH: (519) 699-9283
FAX: (519) 699-4146
PRINTED IN CANADA
Rev 260213
PART NUMBER: Z97514

Advertisement

loading
Need help?

Need help?

Do you have a question about the Wallenstein BX42S and is the answer not in the manual?

Questions and answers

Summary of Contents for EMB MFG Wallenstein BX42S

  • Page 1 THREE POINT HITCH CHIPPER MODELS BX42S ASSEMBLY INSTRUCTION MANUAL Please review and understand the operators manual before attempting to operate this machinery. EMB MANUFACTURING INC. 4144 BOOMER LINE ST. CLEMENTS, ON N0B 2M0 CANADA PH: (519) 699-9283 FAX: (519) 699-4146 PRINTED IN CANADA Rev 260213 PART NUMBER: Z97514...
  • Page 2: Assembly Safety

    ASSEMBLY SAFETY 1. Read and understand the Assembly Manual and all safety signs before starting. 2. Follow good safety practices: Keep service area clean and dry. Be sure electrical outlets and tools are properly grounded. Use adequate light for the job at hand. 3.
  • Page 3 ASSEMBLY This assembly manual is for all trailer model wood processors. The BX42 is used as an example but generally applies to all wood processor models. Model specific instruc- tions are identified in the manual. The machine is shipped from the factory in a partially disassembled configuration and attached to a pallet that provides easy moving and handling. Always use tools, equip- ment and fork lifts of appropriate size and capacity for the job. Inspect for damage from shipping, immediately contact the shipping company if damage is found.
  • Page 4 Uncrating the BX42Wood Chipper 1. Remove all screws securing upper part of crate to lower skid. There are two (2) screws located at each of four (4) corners around the bottom of crate. Photo 1 Photo 1 2. Enlisting a second pair of hands, remove the upper portion of crate. Photo 2 Photo 2...
  • Page 5 3. Visually inspect Wood Chipper for damage. Photo 3 Photo 3 4. Remove fasteners from metal shipping bracket securing Discharge Chute to top of Wood Chipper. Photo 4 Remove Discharge Chute to a clean work surface. Proceed carefully. Hold on to Discharge Chute to prevent from falling to floor. Photo 4...
  • Page 6 5. Completley remove shipping bracket from Discharge Chute and discard. Photos 5 Photo 5 6. Remove single fastener securing half of the Spacer Rings to the Discharge Chute and set aside. Photo 6 Leave other half of Spacer Rings installed as is (with Hood Latch Assembly attached).
  • Page 7 7. Remove all hardware securing the Self-Feed hopper to the metal shipping bracket Photo 7 Photo7 8. Separate the Self-Feed Hopper from the rest of the Wood Chipper. Photo 8 Photo 8...
  • Page 8 9. Remove all hardware securing metal shipping bracket to the Wood Chipper and dis- card bracket. Photo 9 Photo 9 10. Attach the Self-Feed Hopper to the Wood Chipper and secure at the two locations shown. Secure with (2) Hex Bolt 1/2NC x 1-1/4 & (2) Hex Lock Nut, 1/2NC. Photo 10 &...
  • Page 9 Photo 11 11. Locate and install (2) Flange Nut 3/8NC to the threaded studs located at the bottom of the Self-Feed Hopper. Photos 12 & (13 on following page). Photo 12...
  • Page 10 Photo 13 12. Locate Manual Tube 3-1/2 Short and remove (1) Implement Pin 7/8x5-1/2. Photo 14 The BX42 comes shipped with (1) Implement Pin already installed. Photo 14...
  • Page 11 13. Remove Nut & Lockwasher from Implement Pin and install Pin to Wood Chipper Photo 15 Photo 15 14. Locate PTO Shield and raise up to install PTO Shaft Assembly. Photo 16 Photo 16...
  • Page 12 15. Locate PTO Shaft and refer to decal for attachment orientation. Photos 17 & 18 Photo 17 Photo 18...
  • Page 13 16. Attach the PTO Shaft to the Wood Chipper by aligning the splines and depressing the spring loaded button on the PTO. Slide the PTO on to shaft until button snaps back up in position. Photos 19 & 20 Photo 19 Photo 20...
  • Page 14 17. Place the PTO Guard back to the lowered position. Photo 21 Photo 21 18. Apply some Multi-purpose Wheel Bearing/Chasis Lubricant to the top of the Upper Rotor Housing (around the perimeter of the stack opening). Photo 22 Photo 22...
  • Page 15 19. Place the Discharge Chute to the top of the Upper Rotor Housing. Slide the installed Spacer Ring beneath the slotted lip of the Upper Rotor Housing. Photo 23 Photo 23 20. Install second half of Spacer Rings. Slide the lower portion Ring beneath the slotted lip of the Upper Rotor Housing while at the same time aligning the holes of the upper Ring with the holes in the Discharge Chute.
  • Page 16 21. Secure Rings to Discharge Chute with the remaining Hex Bolt 1/4NC x 1 & Hex Lock Nut 1/4NC. Photo 25 & 26 Photo 25 Photo 26...
  • Page 17 22. Remove single fastener from Discharge Chute Hood Latch area. Swing Hood Latch over and reinstall fastener.Photo 27 & 28 Photo 27 Photo 28...
  • Page 18 23. Secure all hardware at Discharge Chute and swivel chute to test operation. Photo 29 Photo 29 24 . Remove final screws securing the Wood Chippr to the shipping skid. Photo 30 Photo 29...
