Summary of Contents for Framon DBM-1
- Page 1 DBM-1 Flat Steel Key Duplicator Instruction Manual & Parts Book Framon Manufacturing Company 1201 West Chisholm Street Alpena, Michigan 49707 989-354-5623 www.framon.com...
- Page 3 CUTTING PROCEDURE FOR FRAMON DBM-1 FLAT KEY MACHINE Figure 1 All keys should be set from the tip for spacing. Insert pattern key in right hand vise with tip of blank protruding slightly beyond left side of vise (Fig #1). The reason for this position is to allow cutting of the tip guide on blank if blank tip is slightly different than pattern key.
- Page 4 Push guide shaft rearward and lock into this position by tightening locking knob (Fig. #2). This relieves spring pressure so tip setting is easier. Lift yoke and set tip of pattern key against right hand side of guide. While holding this position, insert blank and set tip of blank against right hand side of cutter (Fig.
-
Page 5: Parts List
PARTS LIST Part Number Description DBC1045 Carbide Cutter DBMS001 Spring DBMS051 Yoke Knob DBMS201 Pulley Washer DBSH101 Guide Block DBSH103 Base Plate DBSH112 Guide Shaft DBSH113 Guide DCMS251 Steel Brush DCMS401 5/16 Hex Key DCMS402 3/32 Hex Key DCMS450 Bronze Bunting DCMS451 Guard DCMS452... - Page 6 CARBIDE CUTTER CALIBRATED RING DBC1045 DCSH114 GUARD DCMS451 CUTTER GUARD DCMS452 O RING BELT GHMS601 WIRE BRUSH DCMS251 YOKE ROD DCSH107...
-
Page 7: Carton Contents
F2MT008 VISE CLAMP NUT F2SH014 VISE TOP DCSH109 VISE BOTTOM DCSH110 YOKE KNOB DBMS051 VISE BAR DCSH106 CARTON CONTENTS: DBM-1 Machine / .045 Cutter 3/32 Allen Wrench 5/32 Allen Wrench 1/8 Allen Wrench 5/16 Allen Wrench Instruction and Parts Manual... - Page 8 Check guide setting - guide must be set to same width of cutter used. The DBM-1 is supplied with one .045 width cutter. This is the best width for general work. Cutter widths of .035, .055, .066, and .088 are available if needed.
-
Page 9: Maintenance
Always use protective eye wear. WARRANTY The warranty on the Framon DBM-1 is in effect for a period of one year from date of purchase. Framon Mfg. Co. will replace all or any part of any machine proven to be defective as to material or workmanship. If any machine is returned to us in the first year, Framon Mfg. - Page 12 Framon Manufacturing Company 1201 West Chisholm Street Alpena, Michigan 49707 989-354-5623 www.framon.com...
