D1000 / D1010 Series
Quick Start Guide
1 Getting started
2 Using the phone
3 Help
This Quick Start Guide provides all the information you need to get you
started. If you need more detailed instructions, a full user guide is available
to download in PDF format from:
www.motorola.com/cordless-phones
Please consider the environment before printing.
Digital cordless phone D1000
Digital cordless phone with answering machine D1010
Getting started
Step 3. Charge the handset
• When the handset is fully
charged, plug the telephone line
• Insert the 2 x AAA NiMH
cord into the socket marked
batteries supplied into the
on the underside of the base
handset and slide the battery
and plug the other end into the
compartment into place.
telephone wall socket.
• Place the handset on the
charger and charge for at least
Warning!
24 hours. When the handset is
Use only rechargeable batteries.
fully charged, the icon is
If non-rechargeable batteries
displayed.
are used WARNING BATT will
be displayed and charging will
be stopped. Please replace with
rechargable batteries.
REGISTERING WITH BASE
1. Go To Advance Settings
2. Then Go To Registration
3. Then Go To Search Base
4. And Keep Hold Of The Page Button On The Main Unit
( You May Have To Do This Several Times)
5. The Screen A Should Display PIN
6. Enter The PIN Which Is 0000 (Unless Changed)
7. REGISTRATION COMPLETE
Box Contents
D1001/D1011 D1001 base or D1011 base
handset
Mains power Telephone line cord
adaptor for the base
with clear connector
D1000 / D1010 Series
Quick Start Guide
1 Getting started
2 Using the phone
3 Help
This Quick Start Guide provides all the information you need to get you
started. If you need more detailed instructions, a full user guide is available
to download in PDF format from:
www.motorola.com/eu/radios/technicaldocumentation.
Please consider the environment before printing.
Digital cordless phone D1001
Digital cordless phone with answering machine D1011
2 x AAA NiMH Screws and Quick Start
rechargeable wall plugs for Guide
batteries wall mounting
Step 4. Select country Step 5. Set Date and Time
• After charging your phone, the
• Press and scroll
Welcome screen appears.
CLOCK/ALARM.
• WELCOME is displayed and
• Press . Display shows DATE
scrolls in different languages.
& TIME, then press
.
• Press . A list of countries is
• Enter the date using the format
shown on the display.
DD/MM.
• Scroll or to • Press and enter the
your country and press . time using the 24 hour format
HH:MM.
• Press to confi rm.
• Press to confi rm.
The handset and base will be reset
to load the correct settings and the
NOTE
standby screen is displayed.
If you have subscribed to your
network's Caller Display service, the
date and time is set automatically
for all handsets every time a call is
received.
Your phone is now ready for
use.
If you have purchased a multiple Important
pack you will also have the
Only use the telephone line cord
following additional items:
supplied. This equipment is not
designed for making emergency
D1002/D1012
telephone calls when the power
• 1 x Additional handset and
fails. Alternative arrangements
charger
should be made for access to
emergency services.
• 2 x AAA NiMH rechargeable
batteries
• 1 x Mains power adaptor for
Warning!
charger with red connector.
Use only rechargeable batteries.
D1003/D1013
• 2 x Additional handsets and
chargers
• 4 x AAA NiMH rechargeable
batteries
• 2 x Mains power adaptors for
charger with red connector.
D1004/D1014
• 3 x Additional handsets and
chargers
• 6 x AAA NiMH rechargeable
batteries
• 3 x Mains power adaptors for
charger with red connector.
Handset
Earpiece
to
Display
Menu key
Enter the main menu.
Select the option displayed on
screen.
Confi rm menu option - OK is
displayed on screen.
Talk / Recall
Make or answer calls
Use recall (R) functions
Navigator glow ring
lluminates when the phone is
in use. Flashes to indicate new
event, eg. missed call.
*
/ Keypad Lock
Press and hold to lock/unlock
the keypad.
During a call, press and hold to
switch from pulse dialling to tone
dialling.
Dial a star
Handsfree key
Activate and deactivate the
loudspeaker during a call.
Intercom (at least 2
handsets needed)
In standby mode, use to make an
internal call.
During a call, use to transfer an
external call to another handset.
Getting started
Step 1. Set up the base
• Plug the mains power cable
(with a clear connector) into
the socket marked on the
underside of the base and plug
the other end into the mains
power wall socket.
• Switch on the power supply
Tip
Position the base at least 1
metre away from other electrical
appliances to avoid interference.
Putting it as high as possible
ensures the best signal.
Display icons
Call Log / Scroll up /
On when the line is in use.
Volume up
Flashes when there is an incoming call.
Open the calls log.
Scroll up through lists and settings.
Flashes when you have new voicemail messages.
Increase the earpiece volume
Off when you have no voicemail messages.
during a call.
Redial / Scroll right / Clear
Flashes when you have missed calls and new number(s) in the
/ Mute
Calls list.
Open the redial list. Scroll to
the right.
Phonebook is open.
Delete characters on screen when
entering names and numbers.
The alarm clock has been set.
Mute/unmute the microphone
during a call.
Handsfree mode.
Go back to previous menu level
BACK is displayed.
Handset ringer is off.
Phonebook / Scroll down /
Volume down
Answering machine On. Off when answering machine is off.
Open the phonebook.
Flashes when you have new messages. Flashes fast when the
Scroll down through lists and
memory is full. (For D1010 series only)
menus.
Decrease the earpiece volume.
Steady when the handset is registered and within range of the
End / Exit / Switch handset
base. Flashes when the handset is out of range or searching for
on/off End a call.
base.
When in a menu, go back to
standby mode.
The approximate power levels of your battery are indicated as below:
Press and hold to switch handset
off (when in standby) or on.
Battery is fully charged.
# / Ringer Off / Pause
Battery is partially charged.
Press and hold to switch handset
ringer on and off.
Battery is running low.
When dialling or storing a
number, press and hold to enter
Flashes when battery is almost discharged. The handset will emit
a pause (P).
a warning beep during a call every 60 seconds.
Dial a #.
Important
The base station must be plugged
into the mains power at all times.
Do not connect the telephone line
cord into the wall socket until the
handset is fully charged. Only use
the power and telephone cables
supplied with the product.
Step 2. Connect the charger
(Multi-pack only)
• Plug the mains power cable
(with a red colour connector)
into the socket marked on
the underside of the charger
and plug the other end into the
mains power wall socket.
• Switch on the power supply.
