ProofVision Bathroom TV Instructions

BATHROOM
WEBOS SMART TV
PLEASE READ THESE INSTRUCTIONS FULLY
BEFORE INSTALLATION.
WARNINGS:
• Installation must be completed by a
technically competent person. If in doubt
contact a qualified electrician or AV
professional.
• Warranty may become void if failure is as
a result of the installation.
• The front screen on this TV is glass and must
be handled with care
Size Size
19" Bathroom TV
24" Bathroom TV
27" Bathroom TV
32" Bathroom TV
43" Bathroom TV
Inputs
DC 12V RJ45 IN
R L
Pre-Installation
• Make sure that all accessories in contents
listing are present - See User Guide
booklet, page 9.
• We recommend setting up the TV before
installing, to test all required functions are
working properly.
• The wall chosen for install is level.
Bathroom TVs use magnets to attach
the TV to the back-mounting plate. It is
therefore essential the wall is flat.
• Decide on the height of your TV. We
recommend as close to eye level as
possible to ensure maximum visibility.
• Avoid locations in direct sunlight, as this
may cause screen glare.
• ProofVision Bathroom TVs must be
recessed into the wall and must be sealed
to the surrounding wall using a bathroom
silicone sealant.
Dimensions of Front Screen Dimensions of Front Screen
490mm x 335mm x 5mm
594mm x 396mm x 5mm
658mm x 454mm x 5mm
775mm x 508mm x 5mm
1031mm x 661mm x 5mm
HDMI 2 HDMI 1
VIDEO
(eARC) (UART)
USB 1 OPTICAL DVB-S2
OUT
USB 2
• While Wi-Fi is available, the receivers
are at the back of the TV and will be
inside the wall. To maximize connectivity
and prevent streaming issues, we highly
recommend either a wired internet
connection or installing a Wi-Fi booster
nearby.
Testing the TV prior to install
1. Carefully lift the TV from the box, leaving
the protective endcaps on the TV. Place
the TV on a flat surface.
2. One side at a time, remove the foam
endcaps and remove the protective
plastic bags.
3. Remove the back-mounting box from the
back of the TV. Be aware It's secured with
magnets.
4. Place the 2 endcaps on the flat surface
and lay the TV face down on these
endcaps to protect the glass front of the
TV.
Mounting Plate Mounting Plate
473mm x 318mm x 51mm
577mm x 379mm x 51mm
642mm x 438mm x 54mm
760mm x 492mm x 57mm
1006mm x 635mm x 61mm
DVB-T2/C
CI
3.5MM AUDIO
OUT
