Gemtech FT003 V1 Quick Start Manual

Remote Kit – Inbuilt USB/BT/FM
16x2 Display – Version 2.0
Gem Tech
Recommended board Operating Condition:0,+12VDC,2A
❖ Independent digital volume control of 5.1 channels: 0 to -
99 dB(50 Steps, 2dB per step)
❖ Independent Gain Control(Input Gain & Output Gain) of
5.1 channels. 0 to +14 dB (7steps, 2dB per step)
❖ Tone Control for Bass/Treble. -14 to +14dB. (14 steps, 2dB
per step)
❖ Default 3 L/R input & one 5.1 Input. Additional Boards of
Opt/Coax/HDMI can add according the version update.
❖ Default 5.1 Audio out for the above all inputs. Remote
Option given for 2.1 Audio out.
❖ One time 5.1 Input settings in "Admin Settings" for
Market Boards like HD Audio Rush, Etc.
❖ Last Memory of Volume, Gain recalls & Welcome Name
automatically.
❖ Mute/Pause/LCD Back Light off, will be released
automatically once you click Volume button.
❖ Stand-by/Pause will be released by First Click(Press) of
Rotary Encoder.
❖ "Test Tone" provided on long press of "Gain" button.
Before do it, play any one song by USB/BT/FM.
❖ According to the input Remote button few will work, few
will not work.
❖ Normal Re-set & Factory Re-set provided.
❖ Supported Audio file formats: mp3, Wav, FLAC, WMA,
DTS(stereo only)
❖ Lyrical display on 16x2 LCD
❖ Song Selection can be by number. Provided song
selection: Next, Previous, Next Folder, Previous Folder.
❖ Play/Pause, Mute. Play File option given (Single,
Random, All etc.). Supports Equalizer (6 Type).
❖ Press "Play/Pause" button for Auto Tune. Once it
completed you can Select Next/Prev Channels.
❖ FM TUNE Single Freq. adjustment:- /+ button given. The
same button for USB too for Next/Previous Folder.
❖ Version 5.0
❖ Name "GEM TECH" auto detects on mobile to connect.
❖ Remote control for audio : Next, Previous, Play/Pause.
❖ Audio AC3, AAC Supported.
USB
FM
BLUETOOTH
FT003 FT003
Default
V1 V2
5.1 OPT OPT
COAX COAX
ARC ARC
AUX
STANDBY
Opt/Coax
HDMI
CURRENT
INPUT &
ALL
VOLUME
INFO.
Use Gem Tech's
Power Converter Board
to avoid
Humming & Display issues.
A. Rush Ayino DA51A
OPT-1 ARC OPT
OPT-2 HDMI ARC
COAX OPT COAX
AUX COAX
BT
PC
USB
Aux-1
Aux-2
mp5
USB: NEXT
FOLDER
FM: NEXT
FREQUENCY
USB: PREV
FOLDER
FM: PREV
FREQUENCY
