- Page 1 KONKA Please thoroughly read this user manual before use. Refrigerator User's Manual Model KRF-314W & KRF-3145S Instruction Guide Page 1 of 18...
- Page 2 WARNING This appliance is designed for household and similar applications, including staff kitchen areas in shops, offices, and other working environments; farmhouses; hotels; motels; bed and breakfast establishments; catering facilities; and similar non-retail applications. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons to avoid hazards.
- Page 3 DANGER: - Risk of child entrapment. Before disposing of your old refrigerator or freezer, remove the doors and leave the shelves in place to prevent children from easily climbing inside. The refrigerator must be disconnected from the electrical supply before attempting to install accessories.
-
Page 4: Correct Disposal Of This Product
The instructions should include the following guidelines to avoid food contamination: - Avoid keeping the door open for extended periods to prevent a significant increase in compartment temperatures. - Regularly clean surfaces that may come in contact with food and accessible drainage systems. - Page 5 PRODUCT FIGURE CHARACTERISTICS PLEASE NOTE: This image is for reference purposes only; please refer to your actual product. Page 5 of 18...
- Page 6 INSTALLATION METHOD • Before powering on the refrigerator, ensure that all packing materials are removed. • Allow a clearance of 30cm above the refrigerator, as well as 10cm on both sides and at the back, to ensure proper air circulation. Failure to do so may result in improper air circulation, reduced freezing effect, and increased energy consumption.
- Page 7 PRODUCT TECHNOLOGY PARAMETER CORRECT USAGE OF ELECTRICITY POWER • When using a three-pin plug, ensure that the grounding wire is connected properly. Attention: If the environment is very wet, it is essential to install an electricity leakage protector in addition to the grounding wire. Avoid connecting the grounding wire to water or gas pipes.
-
Page 8: Notes For Using
• You should pull out the power plug under the following conditions: - Before cleaning or repairing the refrigerator. - Before changing the lamp of the refrigerator, it is essential to pull out the power plug first to ensure safety. - If the electricity shuts off while the refrigerator is operating, you should also pull out the power plug. - Page 9 USAGE OF FRIDGE COMPARTMENT - In the fridge compartment, the temperature typically ranges from 2-9°C, ideal for storing vegetables, fruits, and beverages. Near the crisper, the temperature is the lowest, while it increases towards the upper areas. Different foods can be placed in different areas based on their temperature requirements.
- Page 10 The tips of storing vegetable and fruit: - Avoid storing vegetables in the direction of their growth, as this can prolong their freshness. - Tropical fruits such as bananas, pineapples, and melons are not suitable for refrigerator storage as they tend to ripen quickly at low temperatures. - Remove the leaves from radishes and fruit vegetables before storing them.
- Page 11 REFRIGERATOR & FREEZER STORAGE CHART The freshness longevity depends on temperature and exposure to moisture. Since product dates aren't a guide for safe use of a product, consult this chart and follow these tips. …CONTINUED ON PAGE 12 Page 11 of 18...
-
Page 12: Function Key Introduction
INTRODUCTION TO DISPLAY PANEL Here's an introduction to the icons: - " " represents the energy-saving symbol. - " " in the fridge area indicates the symbol for fast cooling. - " " in the freezer area signifies the symbol for fast freezing. - "... - Page 13 Freezer compartment temperature adjustment: -You can adjust the freezer compartment temperature between -15 degrees to -24 degrees. Simply press the "freezing adjusting button," and the number indicating the freezer compartment temperature will increase by 1. When the number reaches its maximum value, pressing the button again will automatically reset the temperature to the minimum.
- Page 14 Quick freezing: To rapidly freeze additional food, press and hold the freezing adjusting button to activate the quick-freezing mode for the freezer compartment. Subsequently, the symbol will appear on the freezing digital display. The temperature in the freezer compartment will be set to -30°C. The quick- freezing feature will automatically deactivate after running continuously for a period.
-
Page 15: Maintenance
Maintenance: Regular maintenance can extend the life of your refrigerator. Always unplug the power cord before performing any maintenance for safety. Use a soft cloth with warm water to wipe the refrigerator. If there are stubborn stains, use a mild detergent first, then wipe clean with a dry cloth. Pay special attention to cleaning the door gasket, as dirt can cause it to age and lead to cold air leaks. - Page 16 SIMPLE FIXES FOR FAILURES When there is an issue with the refrigerator, please check the following before contacting our company's local customer service department: Cannot cool down: - Is the power cord plug in good condition? - Is there a power outage? Check the fuse or circuit breaker. - Is the temperature controller set to a proper temperature? Freezing temperature is insufficient: - Have you placed too much food inside?
- Page 17 Heat on Freezer Compartment Frame and Side Panels: The freezer compartment frame contains anti-concreting-dew tubes, while the condenser tubes are located in the side panels. It is normal for these components to emit heat during refrigerator operation. Hot Compressor: During operation, the compressor may become very hot, with temperatures reaching up to 90°C.
- Page 18 The parts listed in the following table can be obtained through the service provider channel: For refrigerating appliances classified by climate class: - Extended temperate: This refrigerating appliance is designed for use in ambient temperatures ranging from 10°C to 32°C. - Temperate: This refrigerating appliance is designed for use in ambient temperatures ranging from 16°C to 32°C.
