VCA IPE1100M Quick Installation Manual

Quick Installation Guide Quick Installation Guide Quick Installation Guide Quick Installation Guide
This manual has been designed to guide you through basic settings of your IP devices, such as installation and
configuration for using them.
Step1. Connect cables to IP device
Connect each cable to the device. To see the correct positions of all connectors, refer to the following image
below.
* Models herein and their
appearance are subject to change
without any prior notice.
RESET Button
LAN
C C W
Step2. Set up network environment
The default IP address of your IP device is 192.168.XXX.XXX. You can find the available IP address from the
MAC address of your device. Please make sure the device and your PC are on the same network segment
before running the installation. If the network segment was different between your PC and the device, change
your PC's settings as below.
IP address : 192.168.xxx.xxx
Subnet mask: 255.255.0.0
C W
SET SC R EW
-
+
+ -
RED
Make sure the polarity is correct. Incorrect
!
connection may cause malfunction or
Caution
damage to the IP device.
1
DC 12V
Power Adaptor Connector (DC 12V)
