Summary of Contents for MEVOLT MK21 Single
- Page 1 Installation instructions for the systems WALLBOX CARRIER MK21 Single / MK22 Duplex MK23 Delta / MK24 Quattro [Enter here] [Enter here] [Enter here]...
-
Page 2: Table Of Contents
Construction: General assembly steps Construction: How to install the WALLBOX CARRIER MK21 SINGLE / MK22 DUPLEX – CAP & ROOF 14 How to install the WALLBOX CARRIER MK23 DELTA – CAP & ROOF How to install the WALLBOX CARRIER MK24 QUATTRO – CAP & ROOF... -
Page 3: General Information
Hint Always observe the locally applicable regulations for electrical installations. Ensure that only persons who have read these installation instructions have Caution access to the stele. MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24... -
Page 4: Warranty And Liability, Support
The respective manufacturer / installer is responsible for the foundation used, wall boxes installed on WALLBOX CARRIER, a built-in distributor and all other components installed in addition to the WALLBOX CARRIER. MEVOLT does not assume any warranty or liability for these components. All earthing measures must be carried out, measured, and recorded accordingly by trained electricians in order to achieve a suitable protective effect according to the ambient conditions. - Page 5 Disclaimer of liability All rights reserved. No part of this publication may be reproduced or published without the prior written consent of MEVOLT. This guide has been prepared with the greatest possible care. Despite everything, we cannot guarantee the correctness of the.
-
Page 6: Overview Of Wallbox Carrier Models And Components
Overview of WALLBOX CARRIER models and components WALLBOX CARRIER WALLBOX CARRIER WALLBOX CARRIER WALLBOX CARRIER MK21 SINGLE MK22 DUPLEX MK23 DELTA MK24 QUATTRO ROOF ROOF ROOF ROOF MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24... - Page 7 MEVOLT - WALLBOX CARRIER Installation Guide page 7 of 28 __________________________________________________________________________________ lid / CAP WALL BOX WALL BOX EXCHANGEABLE PLATE EXCHANGEABLE PLATE service flap WALLBOX CARRIER element WALLBOX CARRIER element MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 8 Exchangeable Exchangeable Exchangeable Exchangeable Intercha Multi- Intercha plate plate plate plate ngeable ngeable Carrier Plate Plate ROOF 2 Interchan Interchan geable geable plate plate ROOF 1 MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 9 5 element 3 TOP 3 CAP 3 TOP 4 CAP 4 exchangeable exchangeable plate plate 1x ROOF 2 2x ROOF 2 MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
-
Page 10: Required Tools
Marking spray / pen tighten the nuts wrench SW8 tighten the nuts wrench SW13 tighten the nuts allen key L-wrench size 4 attaching the screws MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24... -
Page 11: Construction: General Assembly Steps
Fasten the WALLBOX CARRIER elements at both fixing points using suitable fixing material (min. M8) at both fixing points. Drilling pattern Professional installation of the earthing at all earthing points spring washer washer ring eyelet washer toothed washer MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24... - Page 12 Install the distribution board while the back of the WALLBOX CARRIER is still on the floor. Compatible with SPELSBERG distributors AK 12, AK 24, AK-F 42, AK-F 56 MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 13 The lid can then be swivelled in completely. MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 14 MEVOLT - WALLBOX CARRIER Installation Guide page 14 of 28 __________________________________________________________________________________ How to install the MK21 SINGLE / MK22 DUPLEX Assembly of basic element 1 (MK21) Assembly exchangeable Plate/ Multi Carrier or supplementary element 2 (MK22) Optional: Assembly distributor (see...
- Page 15 Screws S1 for mounting cap / top must be greased with copper paste for better Hint protection. (Copper paste not included in the scope of delivery) MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 16 (Copper paste not included) WALLBOX CARRIER WALLBOX CARRIER WALLBOX CARRIER WALLBOX CARRIER MK21 SINGLE – CAP MK21 SINGLE – ROOF MK22 DUPLEX – CAP MK22 DUPLEX – ROOF MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 17 Assembly WALLBOX EXCHANGEABLE PLATE / Multi Carrier Fastening the basic element to the Tip: Attach the wall box to foundation is required. the carrier before installation MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 18 MEVOLT - WALLBOX CARRIER Installation Guide page 18 of 28 __________________________________________________________________________________ Assembly supplementary element 4 Fastening of the supplementary element to the foundation is required. Assembly supplementary element 3 MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 19 MEVOLT - WALLBOX CARRIER Installation Guide page 19 of 28 __________________________________________________________________________________ Assembly basic element Fastening the basic element to the foundation is required. Assembly WALLBOX EXCHANGABLE PLATE / Multi Carrier MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 20 Screws S1 for installation Maintenance covers must be greased with copper paste Hint for better protection. (Copper paste not included) WALLBOX CARRIER WALLBOX CARRIER MK23 DELTA – CAP MK23 DELTA – ROOF MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 21 Assembly of supplementary element 2 Optional: Assembly distributor see page 1 Assembly the WALLBOX EXCHANGEABLE PLATE / Multi Carrier Tip: Fastening the wall box to the carrier before installation. MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 22 Assembly of supplementary element 5 Tip: Fastening supplementary element to the foundation. Assembly WALLBOX EXCHANGEABLE PLATE / Multi Carrier Tip: Attach the wall box to the carrier before installation. MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 23 Fastening of the additional element to the foundation. .required Assembly WALLBOX EXCHANGEABLE PLATE / Multi Carrier Tip: Attach the wall box to the carrier before installation. MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 24 Fastening the basic element to the foundation required. Assembly the WALLBOX EXCHANGEABLE PLATE / Multi Carrier Tip: Attach the wall box to the carrier before installation. MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 25 Screws S1 for installation Maintenance covers must be greased with copper paste Hint for better protection. (Copper paste not included) WALLBOX CARRIER WALLBOX CARRIER MK24 QUATTRO – CAP MK24 QUATTRO - ROOF MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
-
Page 26: How To Install The Wallbox Carrier Mk21 Single / Mk22 Duplex - Cap & Roof
Product: The metal components can be disposed of as scrap metal. Electrical components should be disposed of as electrical waste in accordance with the manufacturer's instructions. All disposal operations are subject to the currently applicable country-specific guidelines, regulations, and laws! MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24... - Page 27 MEVOLT - WALLBOX CARRIER Installation Guide page 27 of 28 __________________________________________________________________________________ Notes MEVOLT GmbH - Justus-von-Liebig-Straße 14 – D - 86899 Landsberg/Lech Rev. 02 | 08.05.24...
- Page 28 MEVOLT - WALLBOX CARRIER Installation Guide page 28 of 28 __________________________________________________________________________________ MEVOLT GmbH | Justus-von-Liebig-Straße | D - 86899 Landsberg am Lech / Bavaria Phone +49 8191 96 36 00 | https://www.mevolt.de info@mevolt.de Rev. 02 | 08.05.24 | Subject to change | MEVOLT GmbH - Justus-von-Liebig-Straße 14 –...
