SERVICE MANUAL
Chromaster 5420 UV-VIS Detector
 Before using the instrument, read the safety instructions and
precautions carefully.
 Be sure to observe the safety instructions in this manual and
the WARNING/CAUTION labels on the instrument.
 Keep this manual in a safe place nearby so it can be referred
to whenever needed.
24-14, Nishi-Shimbashi 1-chome,Minato-ku Tokyo, Japan
FOR
Part No. 892-9551 HT-HH (**-HMS)
