- Page 1 OWNER’S MANUAL PurePro2000 TEAMBMPRO.COM...
-
Page 2: Safety Precautions
REV 1.0 DISCLAIMER: BMPRO accepts no liability for any loss or damage which may occur from the improper or unsafe use of its products. Warranty is only valid if the unit has not been modified... -
Page 3: Table Of Contents
DESCRIPTION OF PARTS..... . 5 PUREPRO2000 ......5 LCD SCREEN . -
Page 4: About The Purepro
ABOUT THE PUREPRO The PurePro is a pure sine wave inverter designed to allow you to access reliable AC power wherever you are. Thanks to PurePro, RV travellers can enjoy comforts of 220-240V appliances and electrical devices, including air conditioning, microwave, hairdryer, power tools, laptops, coffee machines, CPAP machines, and more, when on the road and camping off grid. -
Page 5: Description Of Parts
DESCRIPTION OF PARTS PUREPRO2000 PurePro2000 DC Input Side PurePro2000 AC Output Side Chassis Ground AC Socket 1 Negative Input Terminal On/Off Switch Cooling Fan 1 Residual Current Device AC Transfer Switch Input Remote Port Cooling Fan 2 USB Port Positive Input Terminal... -
Page 6: Lcd Screen
LCD SCREEN ECO/UPS Functions Setting Options Parameters Display Battery Status Indicator Fault Icons Button Control... -
Page 7: Remote
2. Power Indicator 3. Power Button Hold the power button for 3 seconds to turn the PurePro2000 on or off. When the PurePro2000 is on, a short press of the power button will enter sleep mode for the remote panel. The inverter will remain powered on. -
Page 8: Installing The Purepro
30mm away from any surrounding objects. MODEL DC INPUT WIRE SIZE DC INPUT FUSE MAXIMUM LENGTH PurePro2000 50mm2 250A 1500mm The cable must be stranded. It is recommended a disconnect switch is installed with a rating the same or higher than the rating of the fuse. -
Page 9: Automatic Transfer Switch
The PurePro2000 has a maximum combined output of 2000VA. WARNING If you are using the PurePro2000 with a power management system, do not connect the 220-240V AC output to the power management system. 240V power for a power management system CANNOT be powered from the PurePro2000 outputs. -
Page 10: Rcd Safety Switch
The minimum wire size for the automatic transfer switch mains input is 2.5mm2 with 7 strands. When the AC Transfer Switch is activated and passing through AC power from the Mains Input connection, the AC supply must provide the safety device for the connected loads. -
Page 11: Wiring Diagram
WIRING DIAGRAM... -
Page 12: Wiring Diagram With Power Management System
WIRING DIAGRAM WITH POWER MANAGEMENT SYSTEM... -
Page 13: Installing The Remote
Align the mounting holes on the corners of main body with the pre-drilled screw holes. Fix the main body with included screws. Re-attach the front plate to the main body. Connect the other end of the included RJ-type cable into the remote port on the side of the PurePro2000. -
Page 14: Using The Purepro
USING THE PUREPRO To turn the PurePro on, use the On/Off switch. If a 10.5V to 15.5V DC input voltage is available, a 240V AC pure sine wave output will be active within 5 seconds. This output is continuous until the PurePro is turned off or it loses its DC input. USING THE LCD SCREEN The LCD screen is used to operate the PurePro. -
Page 15: Purepro Settings
ECO MODE You can enter or exit ECO mode by pressing the ECO button on either the PurePro2000 or the remote. When ECO mode is on, the “ECO” icon will be displayed on the screen. If a remote is connected, the ECO Mode Indicator on the remote will turn on. -
Page 16: Protective Features
60°C, then restart the PurePro >60°C manually. Unplug and check the connected appliances, 4 Load LEDs Overload then restart your the PurePro manually. Restart the PurePro. If the PurePro still 5 Load LEDs Internal fault fails to work after several attempts, contact BMPRO. -
Page 17: Faqs And Troubleshooting
FAQS AND TROUBLESHOOTING Need more help troubleshooting your PurePro? Contact our customer service team online at teambmpro.com/technical- support My PurePro does not appear to be working? The PurePro can be affected by outside interference. The PurePro is affected by strong electromagnetic waves, such as nearby motors, power inverters, strong magnetic fields, etc. - Page 18 Why isn’t the PurePro switching to mains supply when mains input is available? If the PurePro doesn’t appear to be switching to mains input, check the following: 9 The mains input cable is connected properly and is in good condition. ...
-
Page 20: Specifications
SPECIFICATIONS INVERTER Continuous: <2000VA (<2000W) Power Peak Power: 4000VA (4000W) DC Input 12VDC, 200A (10.5-15.5V) AC Output 220-240VAC, 50Hz, 8.33A USB Output USB-A 5VDC/2A No Load Current Normal <1.3Ah, ECO <0.2A Total Harmonic Distortion <3% Efficiency >89% AC Transfer Switch Input 2300W (10A) Power AC Transfer Switch... - Page 21 REMOTE Input Voltage Range 7-18VDC Working Current 10mA Shutdown Current Sleeping Current Cable RJ12 interface, 5m Temperature 0-50°C Dimensions 86x86x22.5mm Weight IP Rating IP22...
-
Page 22: Warranty Terms And Conditions
The warranty period of the product is two years. If, before the warranty period has ended, a fault occurs with the product and BMPRO finds the product is defective in materials or workmanship, BMPRO at its discretion will subject to further rights accorded by the Australian Consumer Law to either: • ... - Page 23 (k) the fault is a result of common wear & tear. LIMITATIONS No express warranties or representations are made by BMPRO other than what is set out in this warranty. The absolute limit of BMPRO’s liability under this express warranty is the repair or replacement of the product or part of the product.
- Page 24 BMPRO TEAM customerservice@teambmpro.com BMPRO 19 Henderson Rd, Knoxfield VIC 3180 Australia Unit 1, 821 E Windsor Ave, Elkhart IN 46514 USA .COM teambmpro.com...
