Summary of Contents for HDL MQLRT6-12.10
- Page 1 DALI Constant Current Driver (DT6 Dimming) Instruction Manual MQLRT6-12.10 Before using this product, please read this manual carefully and keep it properly！ Document Version：C...
- Page 2 ◇◆ Overview DALI Constant Current Driver(DT6 Dimming) (Model: MQLRT6-12.10 hereinafter referred to as "the product" or "the device") is a DT6 dimming, voltage 6-42V, current 100-700mA, maximum output power 12W DALI-2 drive. Note: The pictures and illustrations provided in this instruction manual are for reference purposes only, and the actual product may differ.
-
Page 3: Technical Data
Figure 1 ◇◆ Technical Data LED Channel DC Voltage 6-42V 100-700mA via NFC tool; Min.current gear lower to 0.1mA, Output Current default 300mA Current Accuracy +3%(±1%@Certain full load) @ full load Rated Power Max.12W Voltage Range 220-240VAC/220-240VDC Absolute Voltage Range 196-264VAC/196-264VDC Frequency Range 0/50/60Hz... -
Page 4: Specifications
Dimming Curve Linear/ Logarithmic (default) Short Circuit Yes, remove the fault conditions and re-power the device. Protection Over Current Yes, remove the fault conditions and re-power the device. Over Temperature Yes, remove the fault conditions and re-power the device. Working Temp. -25℃... -
Page 5: Safety Precaution
The device can be placed on a flat surface or mounted with screws. HDL will not be responsible for any consequence caused by the inexpert or faulty installation and wiring methods, which are not in accordance with the instructions contained in this datasheet. - Page 6 Before performing any maintenance or cleaning procedures on the device, it is imperative to disconnect the device from all voltage sources. This precautionary measure is necessary in order to prevent electric leakage and the risk of electric shock. Physical connection cables: special cables for electricians. For DALI connection, a hand-in-hand connection is recommended.
-
Page 7: Installation
AC Push Function 1) Click the button to switch ON/OFF 2) Press and hold down the button to increase or decrease light intensity to desired level and release it, then repeat the operation to adjust light intensity to opposite direction. The dimming range is from 1% to 100%. ◇◆... -
Page 8: Packing List
Note: After unpacking, please check if the product and the parts are complete. ◇◆ Copyright Statement HDL has all the intellectual property rights to this document and contents thereof. Reproduction or distribution for third parties are prohibited without written authorization from HDL. Any infringement of HDL’s intellectual property rights will be investigated the legal liability. -
Page 9: Troubleshooting
◇◆ Troubleshooting E-mail: hdltickets@hdlautomation.com Website: https://www.hdlautomation.com ◇◆ Technical Support E-mail: hdltickets@hdlautomation.com Website: https://www.hdlautomation.com...
