OPERATING MANUAL
CCN64
Collated Connector Nailer
WARNING
BEFORE OPERATING THE TOOL, ALL OPERATORS SHOULD STUDY
THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY
WARNINGS AND INSTRUCTIONS. KEEP THIS MANUAL WITH THE TOOL
FOR FUTURE REFERENCE. IF YOU HAVE ANY QUESTIONS, CONTACT
YOUR SIMPSON STRONG-TIE REPSENTATIVE OR DISTRIBUTOR.
Scan the QR Code
to be taken to the
CCN64 webpage
Rev: 10/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Strong-Tie CCN64 and is the answer not in the manual?

Questions and answers

Related Manuals for Simpson Strong-Tie CCN64

Summary of Contents for Simpson Strong-Tie CCN64

  • Page 1 THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THIS MANUAL WITH THE TOOL FOR FUTURE REFERENCE. IF YOU HAVE ANY QUESTIONS, CONTACT YOUR SIMPSON STRONG-TIE REPSENTATIVE OR DISTRIBUTOR. Scan the QR Code to be taken to the...

  • Page 2: Table Of Contents

    Keep these instructions with the tool for future reference. Contact your local Simpson Strong-Tie representative if you have any questions. READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THE TOOL. Please note that additional safety measures may be required because of your particular application.

  • Page 3: Tool & Fastener Specifications

    Need loose connector fasteners? Visit your local Simpson Strong-Tie website to see our full range. TOOL AIR FITTINGS This tool uses 3/8 inch N.P.T. male fitting. The fitting must relieve...

  • Page 4: Safety Instructions

    UNLOADING THE TOOL specifications may be required in some • Use only nails work environments with head and recommended by Simpson Strong-Tie for use in the CCN64 tool. foot hazards. Dress appropriately. • Disconnect air supply before loading and unloading.
  • Page 5 Always disconnect the tool from air – When moving to new work area. pressure before performing maintenance. • Use only Simpson Strong-Tie recommended fasteners and parts. • Clean the tool after each day of use or after driving 1,000 fasteners.

  • Page 6: Schematic & Parts

    PROTECTING HOOD COVER 1130S-0724701-2 STOP NAIL PLATE 11363-0724703-1 PUSHER 1131D-0460001-1 URETHANE RETAINER 220* 11372-0720002-2 SPRING 2040102-02040-0 HALF ROUND HD.HEX.BOLT 11318-0834701-1 TRIGGER PIVOT PIN 11390-0724704-1 PROTECTING HOOD COVER 1136F-0374701-1 SPRING 11396-0724702-1 STEEL CHANNEL 1134E-0370001-1 MAGNET T-C-CCN64AU18 © 2018 Simpson Strong-Tie Company Inc.
  • Page 7 FOR THE CCN64 TOOL Nose Grip Magazine Male hose connector (that DOES NOT hold air pressure) T-C-CCN64AU18 © 2018 Simpson Strong-Tie Company Inc.

  • Page 8: Loading The Tool

    LOADING THE TOOL WARNING • Use only nails recommended by Simpson Strong-Tie for use in the CCN64 tool. • Disconnect air supply before loading and unloading. • Always handle the tool with care. • Never point the tool at yourself or another person.

  • Page 9: Unloading The Tool

    UNLOADING THE TOOL Disconnect air supply before loading and unloading. 5. Hold the tool upright. 6. Depress the pusher tab (to disengage from nail strip) and slide the pusher towards the front of the magazine. 7. To release the nail strip from the magazine, press down on the stopper.

  • Page 10: Tool Operation

    TOOL OPERATION WARNING • Keep hands and body away from discharge area of the tool. • Never point the tool at yourself or others. • Use at 90-degree angle on clean dry surfaces. • The tool is activated by compressing the nose/ magazine on on any surface or material.

  • Page 11: Troubleshooting

    TROUBLE SHOOTING SYMPTOM CAUSE SOLUTION Check air pressure to ensure the Excessive air pressure recommended air pressure is being used; 6.2 – 8.3 bar (90 – 120 psi) Base material Ensure correct timber is being used. Over driving fasteners Nails too small Use correctly sized nails.

  • Page 12: Warranty

    Warranty does not provide a remedy for normal wear and tear or any Product that was: (1) purchased other than If Simpson agrees that you have a valid claim under from an authorised Simpson Strong-Tie Australia/Simpson this warranty, depending on the circumstances, Strong-Tie New Zealand dealer, retailer or distributor;...
