CONNECTIONS DIAGRAMS

Dual FT430/440 Displays

FT430/440
(Scaled)
Pulse
Out 1
+ +
_ _
+ +
_ _
Pulse
Out 2
(430 = Pass-Thru
440 = Scaled)

FT4XX Sensus Tranceiver Connections

FT4XX Eqipped with Sensus Board (Side View)
NOTE: A Sensus 2m (6 ft) output cable is prewired to the
Seametrics product at the factory. Longer cables are optional.
Seametrics • 253.872.0284
(Example of Bidirectional Connection)
Sensor
Input
+ +
S S
_ _
+ +
_ _
Power
24 Vdc
Power
EX-SERIES
Power
Forward Output
Reverse Output
(Option-15 only)
Red (Power/Clock)
Black (Ground)
Green (Data)
Page 11
EX800 - SERIES INSTRUCTIONS
FT430/440
(430 = Pass-Thru
440 = Scaled)
Pulse
Power
Out 2
_ _
+ +
_ _
_ _
S S
+ +
+ +
Pulse
Out 1
Sensor
(Scaled)
Input
Sensus Tranceiver
Red
Black
Green
seametrics.com
