ASUS ProArt StudioBook Pro16
Repair Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProArt StudioBook Pro16 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asus ProArt StudioBook Pro16

Summary of Contents for Asus ProArt StudioBook Pro16

  • Page 1 ASUS ProArt StudioBook Pro16 Repair Manual...

  • Page 3: Service Overview

    Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
  • Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
  • Page 5 ASUS ProArt StudioBook Pro16 Overview Top View Bottom View ❶ Array microphones ❶ Air vents ❷ Camera indicator ❷ Audio speakers ❸ Webcam shield ❹ Camera (IR Camera) ❺ Display panel ❻ Air vents ❼ Microphones indicator ❽ Keyboard ❾ Capital lock indicator ❿...
  • Page 6 Components Top View ♦ FP POWER BUTTON ♦ KEYBOARD MODULE ♦ LCD COVER ♦ CMOS BOARD ♦ HINGE ♦ FPC_CAM ♦ COMS CABLE R IMR L IMR ♦ LCD BEZEL ♦ MAIN BOARD ♦ EDP CABLE ♦ LED BOARD ♦ ENCODER FFC ♦...
  • Page 7 Components Bottom View ♦ KEYBOARD MODULE ♦ LCD COVER ♦ THERMAL LCD COVER TAPE ♦ LCD BEZEL ♦ BOTTOM CASE ♦ CMOS BOARD LCD BEZEL ADHESIVE ♦ MAIN BOARD ♦ LED BOARD ♦ 16.0' LCD PANEL ♦ IO BOARD ♦ ENCODER SWITCH H9.8 W/O LED Back...
  • Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. ♦ Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
  • Page 9 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the H5600QM_QR notebook. ♦ Screwdriver ♦ Alcohol 95% ♦ Glove ♦ Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. ♦ Plastic Blade ♦...

  • Page 10: Bottom Case

    BOTTOM CASE Assembly Notice Disassembly Notice For BOTTOM CASE assembly Step 1 : Remove screws *10pcs. Sky side Step 2 : Use plastic blade to pry the Bottom case. Screws Spec Torque (kgf-cm) SCREW M2*4.5L(4,0.8) (K) #1 2±0.2 SCREW M2*9L(4,0.75) (K) 3±0.2 Ground side Start...
  • Page 11 SPEAKER Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Disconnect the battery connector. Step 2 : Disconnect the SPEAKER connector.
  • Page 12 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Remove screws *4pcs. Torque(kgf-cm) Screws Spec...
  • Page 13 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screws *2pcs and remove the SSD *2pcs (red mark). Step 2 : Remove THM SSD AL FOIL and SSD GS from the SSD. Screws Spec Torque (kgf-cm)
  • Page 14 MEMORY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the MEMORY *2pcs (red mark). Step 2 : Remove the ABSORBER from the MEMORY . Remove 2pcs Remove Assembly Notice For MEMORY assembly, When you replace a new MEMORY please remember to paste the ABSORBER.
  • Page 15 ENCODER SWITCH ASSY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the ENCODER SWITCH FFC from the MB (red mark). Screws Spec Torque (kgf-cm) Step 2 : Remove the screws *4pcs and remove the ENCODER SWITCH ASSY. SCREW M2*9.2L(3.6,0.5) (K) #1 2.0±0.2 Step 3 : Disconnect the ENCODER SWITCH FFC from the ENCODER SWITCH ASSY.
  • Page 16 THERMAL MODULE(with FAN) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the FPC_LAN and FPC_USB (red mark). Screws Spec Torque (kgf-cm) Step 2 : Disconnect the EDP CABLE (purple mark) and COMS CABLE (pink mark) and FAN connector SCREW M2*4.5L(4,0.8) (K) #1 2.0±0.2 (yellow mark) from MB.
  • Page 17 MAIN BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect (yellow mark) connector *5pcs from MB. Screws Spec Torque (kgf-cm) Step 2 : Disconnect WIFI ANTENNA connector(red mark). SCREW M2*4.5L(4,0.8) (K) #1 2.0±0.2 Step 3 : Remove screws *3pcs.
  • Page 18 MAIN BOARD Mainboard connector placement FP FFC FFC_LAN FFC_USB FFC_USB EDP CABLE FFC_LAN SPEAKER EDP CABLE BL FPC BATTERY TP FFC K/B FPC Back...
  • Page 19 MAIN BOARD Materials on mainboard H5600QM CPU CAPTON H5600QM GPU CAPTON G531GW PCB DIMM MYLAR H5600QM MB SSD MYLAR H5600QM MB EDP CABLE MYLAR H5600QM MB USB3 ABSORBER H5600QM MB IO CONN MYLAR L H5600QM MB IO CONN MYLAR R H5600QM USB BLACK CONDUCTIVE TAPE Back...
  • Page 20 MAIN BOARD Materials on mainboard H5600QM MB TOP FILM MYLAR H5600QM MB ABSORBER COMBINE UX533FD TOP L COMPOSITE UX305LA DDR TRACE ABSORBER Back...
  • Page 21 WIFI MAIN ANTENNA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove WIFI ANTENNA. Assembly Notice For WIFI MAIN ANTENNA assembly, please follow the mark below to tidy cable Remove Back...
  • Page 22 IO BOARD and LED BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *6pcs on the hinge and screws *2pcs on the IO BOARD. Screws Spec Torque (kgf-cm) Step 2 : Remove IO BOARD. Step 3 : Disconnect and remove all FFC *2pcs (yellow mark).
  • Page 23 FP POWER BUTTON Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect and remove the FP FFC. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *2pcs on the FP POWER BUTTON。 Step 3 : Remove the FP POWER BUTTON.

  • Page 24: Keyboard Module

    KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the KEYBOARD MODULE. Assembly Notice For the new KEYBOARD MODULE, there is no sponge (yellow mark) and do not post it in the future (ECN change).

  • Page 25: Lcd Bezel

    LCD BEZEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove LCD BEZEL. Remove Step 2-4 Due to some tapes behind the lower edge of bezel, please using plastic blade to teardown the bezel .(Just for IPS Panel SKU, the bezel has a BEZEL ADHESIVE TOP D) Please follow the direction shown in the red arrow, to move plastic blade from left to right and peel the bezel away slowly.

  • Page 26: Lcd Panel

    LCD PANEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Remove the screws*8pcs then remove the hinges*2pcs. Step 2 : Pull out LCD adhesive *2pcs. SCREW M2.5*2.5L(7.5,0.6)(K) #1 3.0±0.2 Step 3 : Remove LCD PANEL.
  • Page 27 LCD PANEL Assembly Notice Please be sure to pull out adapter and disconnect the battery. When reuse the LCD PANEL: Please use the fingertip to clean the residual glue on PANEL or BEZEL. When reuse the LCD COVER: Please paste new PANEL ADHESIVE *2pcs. (New LCD COVER already contains PANEL ADHESIVE *2pcs) PANEL ADHESIVE Back...
  • Page 28 CMOS BOARD and CAMERA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect all connector *4pcs(red mark) from the CMOS BOARD and remove the CMOS BOARD and COMS CABLE. Step 2 : Remove FPC_CAM and DIGITAL MICROPHONE *2pcs. Step 3 : Remove the camera.
