VENT HOOD
(FOR OUTDOOR USE ONLY)
MODELS: VH36-2/VH42-2/VH48-2/VH60-2
INSTALLATION INSTRUCTIONS
IMPORTANT: READ THESE INSTRUCTIONS BEFORE
STARTING INSTALLATION OR USE.
WARNING
• AMD Vent Hoods are for residential use only!
• For general ventilation use only. Do not use to exhaust
hazardous or explosive materials or vapors
• Use this unit only in the manner intended by the
manufacturer.
• Before servicing or cleaning this unit, switch power off
at service panel and lock the panel to prevent power
from being switched on by accident. If the service panel
cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
WARNING
TO REDUCE THE RISK OF GRILL TOP
GREASE FIRE, PLEASE OBSERVE THE
FOLLOWING:
1. Never leave surface units unattended at high settings.
2. Oil-overs can cause smoking and may ignite. Heat oils
slowly on low heat.
3. Always turn hood ON five minutes prior to cooking to
begin airflow.
4. Clean ventilation filters frequently. DO NOT ALLOW
GREASE TO ACCUMULATE ON FAN OR FILTER.
5. Use proper pan size. Always use cookware appropriate
for the size of the burner or element.
NOTE TO THE INSTALLER
To avoid damage that will not be covered under warranty
make sure blowers are free from obstructions (packing and
debris) prior to running the blowers. Test run blowers before
finalizing installation. Check with manufacturer before
attempting to use blower systems other than AMD blower
systems.
WARNING
IN THE EVENT OF GRILL TOP GREASE FIRE,
OBSERVE THE FOLLOWING:
1. Smother the flames with a close-fitting lid, cooking
sheet or other metal tray, and then turn off the burner.
BE CAREFUL TO PREVENT BURNS. If the flames do
not go out immediately, EVACUATE AND CALL THE
FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN.
3. MAKE SURE YOUR VENTILATION SYSTEM IS
COMPLETELY TURNED OFF. DO NOT TURN HOOD
ON TO TRY AND EVACUATE SMOKE.
4. DO NOT USE WATER, including wet dish cloths or
towels - a violent steam explosion may result.
USE AN EXTINGUISHER ONLY IF:
• You know you have a class ABC extinguisher and you
already know how to operate it.
• The fire is small and contained in the area where it
started.
• The fire department is being called.
HANDLING PRECAUTIONS
• Remove all rings, watches, belt buckles, jewelry and
any clothing with metal buttons or snaps to prevent
damage to hood.
• DO NOT REMOVE HOOD FROM ITS ORIGINAL
CARTON UNTIL YOU ARE READY TO INSTALL IT.
• When you are ready to begin the installation process,
remove the hood from its carton and place it on a clean
soft blanket.
• Inspect the hood carefully for any damage or
imperfections before you begin to install the hood. If
any damage or imperfections exist, re-carton the hood
and call your dealer IMMEDIATELY. Do not install a
damaged hood.
• It is highly recommended that rubber gloves be used to
prevent scratches on the hood and to provide you with
a firm grip.
• When removing the hood from the carton, locate the
filters. The filters are not pre-installed in the hood. The
filters are in a box marked filters inside the hood carton.
• AMD model hood series can be ducted to the top or the
rear. Check product guide for additional transitions, wall
caps and roof caps.
• All AMD ventilation hoods have a variable speed
control blower switch
1
90514 Rev A 5/24
