Huem
Universal IR Remote Control
1
Light
Voice Control
360º Coverage
Set Timer
Smart Scene
Set-Top Box
Air Conditioner
DIY Learning
Share Devices
Audio
Smart Home
TV
Wi-Fi
Infrared
Infrared
Measure
Measure
Item Code
Input
Standard
Frequency
Range
Range
Accuracy
Kg
2.4GHz
0ºC ~ 60 ºC
0.29
MS-IR101-BK
DC 5V/1A
38KHz
<10 Meters
+1C +5% RH
IEEE 802.11 b/g/n
0% RH ~ 99% RH
Communication
Power
Wi-Fi
Input
Operating
Material
Color
IP Rate
Watt
Method
Source
Frequency
voltage
Temperature
2.4GHz
ABS
Black
20
5W
-20°C~40°C
Wi-Fi
Adaptor
DC5V 1A
802.11 b/g/n Only
Dimensions in mm
60mm
20mm
page 1 of 9
Advertisement
Summary of Contents for huem MS-IR101-BK
- Page 1 Infrared Measure Measure Item Code Input Standard Frequency Range Range Accuracy 2.4GHz 0ºC ~ 60 ºC 0.29 MS-IR101-BK DC 5V/1A 38KHz <10 Meters +1C +5% RH IEEE 802.11 b/g/n 0% RH ~ 99% RH Communication Power Wi-Fi Input Operating Material...
-
Page 2: Product Presentation
If the numbers of devices connected to the Wi-Fi router reach the limit, you can try to disable a device to cavate the channel or try with another Wi-Fi router. Download Huem App 1. Search the App “Huem“ from Apple Store or Google Play. 2. Scan the QR code from the label or user manual. Android iOS 10.0... -
Page 3: Connection And Operation
Connection and Operation Connect your mobile to your Wi-Fi router , supply power to the remote control with Micro charging cable, click“+” in the upper right corner of homepage or click “Add Device”. Add Device Home Turn on the bluetooth in mobile The app will ask you to turn on the bluetooth in your mobile, then you choose the device to add. - Page 4 If your Wi-Fi router open both 2.4GHz and 5GHz with the same name, enter Wi-Fi password, please select “AP Mode”, hold the reset button for about 5 seconds till LED indicator blink slowly, connect your mobile to the device’s hotspot: “Huem-XXXX” , then click to return to App interface, it will connect to Wi-Fi router automatically, configuration complete.
- Page 5 Tap “Smart IR”, then click ”Add ”, select the device and its brand you need control, you can click “Quick Match” or “ Manual Mode” to match the buttons, please match at least 3 buttons to check if the device reacts properly, if yes, then match completed, you can control the device.
- Page 6 If you can not find the brand of the device in the brand list, you can choose “DIY” to learn the buttons of other brands’ remote control, so you can also control the device. Step 1 Step 2 Step 3 Step 4 Step 5 Step 6...
- Page 7 Functions Customize Scenario Create smart scenario for IR devices, click ” Smart ”page, then click” +” at the upper right corner to set conditions and tasks. Smart Intelligent Linkage When the ambient environment change, you can execute intelligent linkage. For example, when the room temperature surpass 30ºC, the air-conditioner will open automatically, or when the humidity...
- Page 8 Monitor Temperature & Humidity You can real-time monitor the temperature and humidity on the App, and take actions to make some adjustments if necessary. Third-party Voice Control Works with amazon alexa and google assistant. page 8 of 9...
- Page 9 What devices can be controlled with IR remote? You can control TV, Air-conditioner, Fan, DVD, TV box, Light, Set-top box, Projector, Audio, Camera, Water Heater, Air purifer, etc. What should I do when i cannot control the device with the IR remote? Make sure your mobile device and the IR remote is close and connected to the same network, assure the IR remote is always being power supplied.
