Ikon ENDURO POWERLITE IK2PCS User Manual

Folding carbon fibre electric wheelchair
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M O B I L I T Y
REDGUM Brand
ENDURO
POWERLITE
FOLDING CARBON FIBRE ELECTRIC WHEELCHAIR
IK2PCS
USER MANUAL
Please read and keep these instructions
ikonmobility.com.au
ASK FOR THE BRAND

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENDURO POWERLITE IK2PCS and is the answer not in the manual?

Questions and answers

Summary of Contents for Ikon ENDURO POWERLITE IK2PCS

  • Page 1 M O B I L I T Y REDGUM Brand ENDURO POWERLITE FOLDING CARBON FIBRE ELECTRIC WHEELCHAIR IK2PCS USER MANUAL Please read and keep these instructions ikonmobility.com.au ASK FOR THE BRAND...
  • Page 2 IKON Mobility owns the copyright to the ENDURO POWERLITE Wheelchair user manual. Any information contained in this user manual shall not be photocopied, reproduced or translated into any other languages without the prior written consent of IKON Mobility. IKON Mobility strives to provide the highest quality products possible.

  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION FEATURES SPECIFICATIONS SAFETY ADVICE SAFETY ADVICE (Continued) EMI WARNING EMI WARNING (Continued) UNPACK and INSPECT SUPPLIED PARTS UNFOLD WHEELCHAIR UNFOLD BACKREST LOWER LEGRESTS FIT OVERLAYS FIT ONBOARD CONTROLLER RAISE ARMRESTS BATTERY CHARGING ONBOARD BATTERY CHARGING DIRECT BATTERY CHARGING FREEWHEELING ONBOARD CONTROLLER REMOTE CONTROLLER...

  • Page 4: Introduction

    INTRODUCTION Thank you for purchasing this IKON Mobility product. Please read this user manual prior to using the wheelchair for the first time. If you have any issues or questions about the ENDURO POWERLITE Wheelchair please contact your supplier or IKON Mobility direct: T: +61 8 9248 4180 E: orders@for-de.com.au...

  • Page 5: Features

    FEATURES AIRLINE - Carbon fibre frame TRAVEL - Folds up for transport and storage READY - Safe to take on an aeroplane - Comfortable padded seat and backrest - Fold down backrest - Lift up armrests - Onboard controller with LCD display - Remote controller - Fingertip controls - Battery power indicator...

  • Page 6: Specifications

    * Maximum range is based on an ambient temperate of 20°C, 75kg user, brand new fully charged battery and constant driving speed of 5km/h on flat level ground. Please contact IKON Mobility if you would like any further information on the ENDURO POWERLITE Wheelchair.

  • Page 7: Safety Advice

    SAFETY ADVICE For your own safety, please read this user manual before using the ENDURO POWERLITE Wheelchair. Failure to follow these guidelines may result in damage to the product and put the user at risk. If in any doubt, contact your supplier directly for advice.

  • Page 8: Safety Advice (Continued)

    Doing so may also void your warranty. - Ensure the wheelchair is serviced every 12 months by an authorised IKON Mobility service provider to ensure it remains in safe working order. Failure to do so may cause catastrophic failure with possible injury and damage to surrounding property.

  • Page 9: Emi Warning

    EMI WARNING Power wheelchairs may be susceptible to electromagnetic interference (EMI), which is a kind of interfering electromagnetic energy (EM) emitted from sources such as radio stations,TV stations, amateur radio (HAM) transmitters, two-way radio and mobile phones. The interference (from radio wave sources) can cause the wheelchair to release its brakes, move by itself, or move in unintended directions.

  • Page 10: Emi Warning (Continued)

    EMI WARNING (CONTINUED) WARNINGS 1. Do not operate hand-held transceivers (transmitters-receivers), such as citizens band (CB) radios, or turn ON personal communication devices, such as mobile phones, while the wheelchair is turned ON. 2. Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming close to them.

  • Page 11: Unpack And Inspect Supplied Parts

    UNPACK and INSPECT SUPPLIED PARTS We recommend that you thoroughly inspect all the supplied parts prior to assembling product. REMOTE CONTROL FOLDED (not to scale) WHEELCHAIR (BATTERY FITTED) ONBOARD CONTROLLER (not to scale) BACKREST OVERLAY SEAT OVERLAY BATTERY CHARGER (not to scale) BELT POWER CABLE...

  • Page 12: Unfold Wheelchair

    UNFOLD WHEELCHAIR Please follow these instructions to unfold the wheelchair: 1. Pull OUT on both of the armrests at the same time to open out the wheelchair. 2. Push down on the outside edges of seat to ensure wheelchair has been fully unfolded.

  • Page 13: Unfold Backrest

    UNFOLD BACKREST Please follow these instructions to unfold the backrest: 1. Place your hand on the armrest. 2. Rotate up each backrest handle until it locks into position. Important note: Check to ensure both backrest handles have locked into position prior to use. (Loud ‘CLICK’...

  • Page 14: Lower Legrests

    LOWER LEGRESTS Please follow these instructions to lower the legrests and footplates on the wheelchair. 1. Rotate the legrest down until they locate into clip. 2. Lower both footplates down. Important Note: Always have your feet on the footplates when the wheelchair is in motion. Swing the footplates up when getting on and off the wheelchair.

  • Page 15: Fit Overlays

    FIT OVERLAYS Please follow these instructions 1. Unfold the flaps and identify the to fit the seat and backrest overlays correct overlay for the seat and backrest. onto the wheelchair. BACKREST SEAT 2. Place the seat overlay onto the wheelchair with the flap to the front and facing down. Fold the flap over and attach to the underside of the seat as shown.

  • Page 16: Fit Onboard Controller

    FIT ONBOARD CONTROLLER Please follow these instructions to fit the onboard controller onto the armrest. Mount arm Handwheel 1. Determine which armrest the controller will be mounted to. Handwheel may need to be repositioned to suit. 2. Slide the mount arm into the opening on the end of the armrest.

  • Page 17: Raise Armrests

    RAISE ARMRESTS Please follow these instructions to raise the armrests on the wheelchair. 1. Press the button on the outside of the armrest in and at the same time rotate the armrest up. Important Note: Always keep the armrests down when the wheelchair is in use.

  • Page 18: Battery Charging

    BATTERY CHARGING Please follow these instructions to charge the battery used on the wheelchair. The ENDURO POWERLITE Wheelchair is supplied with a rechargeable maintenance free Lithium-Ion battery which MUST BE charged using the supplied battery charger. WARNING! FAILURE TO USE CORRECT AND SPECIFIED CHARGER MAY RESULT IN DEATH, DAMAGE OR CANCELLATION OF WARRANTY AND STATUTORY PROTECTIONS.

  • Page 19: Onboard Battery Charging

    ONBOARD BATTERY CHARGING Please follow these instructions to charge the battery whilst it is STILL CONNECTED TO THE WHEELCHAIR. 1: Raise the armrest with the controller attached. 2. Align the pins on the battery charge cable with the holes in the charging port and firmly push together.

  • Page 20: Direct Battery Charging

    DIRECT BATTERY CHARGING Please follow these instructions to remove the battery from the wheelchair and charge directly. 1: To remove the battery from the wheelchair: - Press the button in, - Lift the battery up and pull away from the wheelchair. 2.

  • Page 21: Freewheeling

    FREEWHEELING Please follow these instructions to disengage the drive motors on the wheelchair so it can be pushed around if required. IMPORTANT NOTE When the motors on the wheelchair are disengaged the braking system is also disengaged. 1: Turn the power off on the wheelchair.

  • Page 22: Onboard Controller

    ONBOARD CONTROLLER The ENDURO POWERLITE Wheelchair comes with a interactive onboard controller that can be used by the occupant to operate the wheelchair. Ensure that you familiarise yourself with the controller prior to operating the wheelchair. Refer to page 21 for information on how to operate the wheelchair in a safe manner.

  • Page 23: Remote Controller

    REMOTE CONTROLLER The ENDURO POWERLITE Wheelchair also comes with an interactive remote controller that can be used by an attendant who controls the wheelchair for the occupant. Ensure that you familiarise yourself with the controller prior to operating the wheelchair. Refer to page 21 for information on how to operate the wheelchair in a safe manner.

  • Page 24: Operating The Wheelchair

    OPERATING WHEELCHAIR Getting Started - Select a level area with plenty of space. - Check the battery charge remaining before operating the unit to ensure you have sufficient power for your journey. Getting on or out of the wheelchair - Before getting off the wheelchair ensure that controller has been turned off to prevent any accidental movement.

  • Page 25: Troubleshooting

    - Drive motors has been engaged. (not freewheeling) If these troubleshooting tips do not fix the issue with the wheelchair please contact your supplier or IKON Mobility direct for support. Do not attempt to unless you are a certified technician and have been trained to service the ENDURO POWERLITE Wheelchair.

  • Page 26: Inspect / Maintain / Service

    Failure to do so may cause catastrophic failure with possible injury and damage to surrounding property. Regular servicing will ensure trouble free operation. If you have any questions about the inspecting, maintaining or service requirements of the ENDURO POWERLITE Wheelchair please contact your supplier or IKON Mobility direct. ikonmobility.com.au ASK FOR THE BRAND...

  • Page 27: Cleaning The Wheelchair

    - DO NOT IMMERSE IN ANY LIQUID - DISPOSE OF BATTERY APPROPRIATELY If you have any questions about the cleaning or disposal of the ENDURO POWERLITE Wheelchair please contact your supplier or IKON Mobility direct. ikonmobility.com.au ASK FOR THE BRAND...

  • Page 28: Warranty (Continued)

    (12) months from the date of purchase by the original customer. IKON Mobility will repair or replace, at our option free of charge any part found on examination by IKON Mobility to be defective in material and or workmanship within the warranty period.
  • Page 29 - All transportation cost associated with the submission and return of the repair or replacement under warranty (as determined by IKON Mobility) are the responsibility of the original customer. During the guarantee period, if the company is satisfied there is a genuine fault, we will repair or replace the product at our earliest convenience.

  • Page 30: Redgum Brand Range

    REDGUM BRAND RANGE REDGUM Brand offer a comprehensive range of products including: Seat Walkers Side Folding Seat Walkers Walking Frames Wheelchairs Walking Sticks + Quad Sticks Crutches Reachers Shower / Bathroom products Toilet products Cushions: Air / Foam Electric Lift Chairs Electric Beds Aluminium Ramps Pedal Exercisers...

  • Page 31: Notes

    NOTES ikonmobility.com.au ASK FOR THE BRAND...
  • Page 32 DISTRIBUTOR: M O B I L I T Y REDGUM Brand ikonmobility.com.au ASK FOR THE BRAND...
