The Brainstorm Workbench
Assembly Instructions
Parts:
8 Brace Plates
4 Legs
32 Screws 1/4-20 x 20mm serrated
4 Threaded Casters
Brace Plates
1) Remove shrink wrap and unbox product, being careful not to scratch or dent the
the butcher block.
2) Lay the butcher block top upside down on a padded surface so as not to damage it.
The frame comes attached to the top and should be snug, but not too tight. This is
to ensure all legs, once secure, will tighten properly and straight.
Legs & Screws
Casters
Advertisement
Related Manuals for cef Brainstorm Workbench
Summary of Contents for cef Brainstorm Workbench
- Page 1 The Brainstorm Workbench Assembly Instructions Parts: 8 Brace Plates 4 Legs 32 Screws 1/4-20 x 20mm serrated 4 Threaded Casters Legs & Screws Casters Brace Plates 1) Remove shrink wrap and unbox product, being careful not to scratch or dent the the butcher block.
- Page 2 3) Take legs as shown and turn until the inserts align with the holes in the frame. Use the 1/4-20 x 20mm serrated screws to bolt the leg to the frame (hand tighten). Repeat with each of the four corners until all legs are attached.
- Page 3 6) Work around frame tightening all bolts and ensure legs are square. 7) Attach a threaded caster to each leg insert. Tighten with a 3/4" wrench until secure. Assembly is complete!
