- Page 1 Gourmet Galley Range INSTALLATION & OWNER’S MANUAL Read all instructions and warnings before operating. Force 10 Manufacturing Corporation Unit A – 19169 21 Surrey, BC V3S 3M3 Tel: 604.536.0379 Fax: 604.535.1210 Website: www.force10.com...
-
Page 2: Safety And Precautions
Any recommendation or advice given by Force 10 Manufacturing or any of its employees is solely an accommodation to the customer, and should not be relied upon by the customer without an independent verification of its applicability to the customer’s particular situation. -
Page 3: Gas Pressure
Note: This appliance is designed to operate from low pressure (30mbar) Propane. Exposure to high pressure can damage the unit Connect your Galley Range to a properly installed low pressure propane system. Force 10 Manufacturing recommends that your propane system meet the regulations specified in the American Boat and Yacht Council Standard A-1. - Page 4 Gimbal Installation Cutout Dimensions: Model Description 22” 19” 23 ¼” 2” 2 ⅜” 5” 5⅛” 6 ⅜” 63251 2 - Burner NA Standard 22” 19” 21” 2” 2 ⅜” 5” 5⅛” 6 ⅜” 63253 2 - Burner NA Compact 18½”...
- Page 5 Make sure the stove swings freely at least 15 degrees. Check to ensure the gimbal lock pins slide into the hole. Built-in Installation Cutout Dimensions: Model Description 73251 2 - Burner NA Standard 20¾” (527mm) 16” (407mm) 22 ¼” (565mm) 73253 20¾”...
-
Page 6: Operation
1” (25mm) diameter holes on each side of the bottom of the cutout. OPERATION Features Your Force 10 Gourmet Galley Range has a number of features to make your unit easier to use. Electronic Spark Ignition – Your unit is equipped with an electronic spark ignition system. - Page 7 To install: To replace the grill simply reverse the procedure. Make sure that the clasps are open, then while holding the rear of the grill up slide the frame hooks over the top of the spools. Push down the clasps so that they engage the spool center groove. Check the alignment of the grill with the stove body, it should be square and feel secure and be able to rotate freely upward.
- Page 8 Oven/Broiler Operation The oven and broiler are controlled by the same valve. The oven and broiler can not be operated at the same time. The oven temperature is controlled by a mechanical thermostat. The oven burner will provide full output until it reaches the set point at which time it will go into a maintenance mode.
-
Page 9: Cleaning And Maintenance
Broiler: To light the broiler push in the oven control knob and turn clockwise. If your unit is equipped with an integrated spark system the burner will light automatically, or continue to hold in the control knob and push the ignition button located on the left side of the control panel. - Page 10 Inside the body is a shaft that may also be dirty. Using a pair of tweezers, remove the shaft. Remember its orientation inside the valve. Carefully clean the valve stem and shaft using warm water or alcohol. Replace the shaft back in the valve, ensuring it is in the proper position.
- Page 11 Removal of the oven burner orifice: Unscrew the oven burner bracket from the back of the stove. Rotate the burner 180 degrees to gain access to the orifice. Remove the orifice from the orifice holder with a 7mm wrench. ...
- Page 12 Replacing a Thermocouple Tools Required: Phillips Head screwdriver 8mm open wrench Top Burners 1. Remove the top Grill 2. Remove the top tray Remove all the burner caps Remove the flame spreaders Un-screw the burner cup from the top tray by removing the (2) screws on each burner cup.
-
Page 13: Troubleshooting Guide
TROUBLE SHOOTING GUIDE PROBLEM CAUSE Solution______________ Burner will not stay lit Thermocouple is not in the See Low Flame flame Thermocouple has failed Replace thermocouple Solenoid in the valve has Replace solenoid failed Supply tank is empty Re-fill tank Burner will not light (No gas) Shut-off valve is closed Open valve... -
Page 14: Assembly Diagrams
Assembly Diagrams Control Knob Control Valve Top Tray Grill Back Top Grill Control Panel Grill Frame Left Stove Side Right Stove Side Oven Rack Oven Heat plate Handle Door Assembly Cross Bar Assembly Slider Blocks Back Door Rod Side Door Rod Front Door Rod Page 13 of 15 ENG 0019.14 Part # 93030... - Page 15 Gas and Electrical Circuits Page 14 of 15 ENG 0019.14 Part # 93030...
-
Page 16: Specifications
The buyer shall be responsible for shipping and insurance charges, if any, on the products returned for repair under the terms of this warranty. Force 10 Manufacturing will pay shipping of products returned to the buyer.
