SNAP CIRCUITS EASTER EGG LIGHT Quick Start Manual

UNLEASH YOUR CREATIVITY!
PARTS LIST
QTY. ID NAME
r 2
1 Single Snap
r 1
B3B Battery Holder
r 1
D12 Color2 LED
r 3
Egg
r 4
Basket Pattern
IMPORTANT:
If any parts are missing or damaged,
DO NOT RETURN TO RETAILER.
e-mail us at: support@elenco.com.
You may order additional / replacement parts:
elenco.com/replacement-parts
Assembly:
Light it up
• Snap both single snaps on the battery holder.
• Snap the COLOR2 LED on the single snaps.
Place the LED '+' facing the same direction as
the battery holder '+'.
• Place one of the eggs on top of the LED and watch
it slowly change colors. For best effects, place the
parts in a dimly lit room.
• Unsnap one side of the COLOR2 LED to turn off.
What is an LED? How does it work?
An LED (Light Emitting Diode) is a semiconductor device that emits light when
activated. They act as a one-way valve that allows electricity to flow in only ONE
direction. When positioned in the circuit, if the + side is facing the + terminal of
the source, then electricity will flow through it. If they face opposite sides, the LED
stops all flow of electricity. LEDs are commonly used as indicator lights and often for
home lighting because they are more energy efficient than incandescent light bulbs.
EggLight-Manual2023_Final.indd 1 EggLight-Manual2023_Final.indd 1
Part #
6SC01
6SCB3B
6SCD12
6SCEGG
6SCBASK
SC-EGGLIGHT_V1
Build your Egg Light
STEP 1
Model SC-EGGLIGHT
Installing batteries:
• Remove the safety cover from the battery holder (if your holder
has one) with a Phillips head screwdriver.
• Insert three (3) 1.5V AA batteries (not included) in the holder.
Be sure to orient the battery "+" as marked in the holder.
• Replace the cover (if your holder has one). When installing a
battery, be sure the spring is compressed straight back, and
not bent up, down, or to one side.
• Battery installation should be supervised by an adult.
STEP 2
Batteries: X3
Install three (3) "AA" batteries
(Full battery installation and warnings
located within this manual)
