INSTRUCTIONS FOR USING
ATS CONTROLLER ATbS C55

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATbS C55 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BTB ATbS C55

  • Page 1 INSTRUCTIONS FOR USING ATS CONTROLLER ATbS C55...

  • Page 2: Table Of Contents

    Contents 1 OVERVIEW ................................4 2 MODEL FUNCTION COMPARISON ........................4 3 PERFORMANCE AND CHARACTERISTICS ......................5 4 SPECIFICATION ..............................6 5 MEASURED AND DISPLAYED DATA ........................7 6 OPERATING ................................8 6.1 OPERATION PANEL ............................8 6.2 INDICATOR DESCRIPTION ........................... 9 6.3 KEY FUNCTION DESCRIPTION ........................
  • Page 3 11.2 AUTO OPERATION RUNNING ........................21 11.2.1 ILLUSTRATION ..........................21 11.2.2 AUTO TRANS./RESTORE ......................... 22 11.2.3 AUTO TRANS. NONE RESTORE (ACTIVE FOR MUTUAL BACKUP) ..........23 11.2.4 AUTO TRANS. NONE RESTORE (IN ACTIVE FOR MUTUAL BACKUP) ......... 24 11.2.5 NON-OPEN TRANSFER ........................24 11.3 AUXILIARY CONTACT FEEDBACK INPUT OF SWITCH OPEN ..............

  • Page 4: Overview

    1 OVERVIEW The ATbS C55 dual power ATS controller is a comprehensive dual power transfer module equipped with configurable functions, automatic measurement capabilities, LCD display, and digital communication. It integrates digital intelligence and networking to automate measurement and control processes, thereby reducing human errors in operation.

  • Page 5: Specification

    • Communication Port: Includes 1 RS485 isolated communication port with Modbus RTU protocol, enabling remote control, measuring, communication, and adjusting functions for genset start, genset stop, and ATS close/ open operations • Compatibility: Suitable for various AC system types, including 3-phase 4-wire, single-phase 2-wire, and 2-phase 3-wire configurations •...

  • Page 6: Measured And Displayed Data

    5 MEASURED AND DISPLAYED DATA Table 4 Display Parameters Measured and Displayed Data Items A/B power phase voltage A/B power line voltage A/B power voltage phase sequence A/B power frequency Present continuous supply time Last continuous supply time A power accumulated supply time B power accumulated supply time A power accumulated close times B power accumulated close times...

  • Page 7: Indicator Description

    6.2 INDICATOR DESCRIPTION Table 5 Indicator Description Indicator Name Indicator Description Slow flashing for warning alarms ( 1 time per second); Alarm Indicator Fast flashing for fault alarms ( 5 times per second); Auto Mode Indicator Light on when current is Auto mode; Manual Mode Indicator Light on when current is Manual mode;...

  • Page 8: Lcd Display

    7 LCD DISPLAY 7.1 MAIN INTERFACE Table 7 Main Interface Display Item Display Contents A power status, B power status, generator start status, switch status; Homepage A/B power voltage and frequency; A power line voltage, phase voltage, phase sequence, frequency; Power B power line voltage, phase voltage, phase sequence, frequency;...

  • Page 9: Status Description

    7.3 STATUS DESCRIPTION Table 9 A Power Voltage Status Item Description A Available Delay for A power available detection A Unavailable Delay for A power unavailable detection Power Normal Power value is within normal range Blackout Voltage is 0 Over Volt. Voltage is above the pre-set upper limit Under Volt.
  • Page 10 Table 12 Switch Status Item Description Ready to Transfer Enter switch transfer procedure Closing A A power is experiencing close delay Opening A A power is experiencing open delay Closing B B power is experiencing close delay Opening B B power is experiencing open delay Transfer Rest The interval time for switch transfer Again close time when A power failed to open for the first time, if Again Close Delay is not...

  • Page 11: Main Menu

    Table 15 Reminder Information Item Description Press Reset Alarm The reminder for manual transfer to auto mode before alarm clear as fault alarm occurs Set it to one breaking or two breakings; reminder information for pressing A power close A Closed key as A power is closed Set it to one breaking or two breakings;...

  • Page 12: Remote Communication Start/Stop

    8.1.2 REMOTE COMMUNICATION START/STOP Through the RS485 port using the Modbus protocol, remote start/stop commands can be issued as follows: Remote Stop: This command disconnects the outputted genset start signal, effectively controlling the genset to stop. Remote Start: This command controls the output of the genset start signal, initiating the start of the genset. 8.2 AUTO START/STOP 8.2.1 START CONDITIONS 8.2.1.1 INPUT PORT START...

  • Page 13: Parameter Configuration

    9 PARAMETER CONFIGURATION 9.1 ILLUSTRATION In the first page of the main screen, press key to enter menu screen; select Parameters Set and press Confirm key to confirm and enter parameter setting password check interface. Input correct password and it will e nter parameter main interface.
  • Page 14 Item Range Default Description Switch Setting Close Delay (0.0~100.0)s Pulse time for close relay output; continuous output when it is 0 Open Delay (0.1~100.0)s Pulse time for open relay output Transfer Interval (0 ~9999)s Waiting delay time from A open to B close, or B open to A close Continuous output time of close relay after detecting closed Over Transfer Delay (0~20.0)s...
  • Page 15 Item Range Default Description Sunday Monday Tuesday Start Weekly Week Wednesday Thursday Friday Saturday Start Hours (0~23)h Time for scheduled start. Start Minutes (0~59)min Start Time (0~30000)min Lasting time for scheduled start running. Auxiliary Input Setting Aux. Input 1 (0~20) Not Used Active Type (0~1)

  • Page 16: Digital Input/Output Function Description

    9.3 DIGITAL INPUT/OUTPUT FUNCTION DESCRIPTION 9.3.1 INPUT PORT FUNCTION DESCRIPTION Table 18 Input Port Function Description Item Description Not used Invalid After the input port is active, the controller will exit the control and the closing/opening is Handle Operation operated by the switch itself. When it is active, the control will display: handle operation Remote Gen On Load Genset start outputs;...

  • Page 17: Output Port Function Description

    9.3.2 OUTPUT PORT FUNCTION DESCRIPTION Table 19 Output Port Function Description Item Description Not used Invalid Common Alarm Common alarms include fault alarm, warning alarm Common Fault Alarm Fault alarm includes switch transfer failure Warning alarms include A phase sequence wrong, B phase sequence wrong, and forced Common Warn Alarm to open Switch transfer failures include A failed to close, A failed to open, B failed to close, and B...

  • Page 18: Event Log

    10 EVENT LOG In the first page of the main interface, press key, and enter menu page. Select “Event Log”, and then select to confirm. In this way Event Log interface is entered. Each item of Event Log contents includes: Date and time;...

  • Page 19: Auto Operation Running

    11.2 AUTO OPERATION RUNNING 11.2.1 ILLUSTRATION Press manual/auto transfer key , and auto status indicator is illuminated; Controller is in auto status. In auto mode, controller will transfer switch based on the status of A power and B power, transfer priority and auto trans./restore status to ensure supply for load.

  • Page 20: Auto Trans. None Restore (Active For Mutual Backup)

    11.2.3 AUTO TRANS. NONE RESTORE (ACTIVE FOR MUTUAL BACKUP) When the “Auto Trans None-Restore” function is set, and “Mutual Backup” is active, A power acts as the master source. If A power is normal, it closes the A power switch, supplying the load. If A power becomes abnormal while B power remains normal, the controller opens the A power switch and closes the B power switch, transferring the load to B power.

  • Page 21: Auto Trans. None Restore (In Active For Mutual Backup)

    11.2.4 AUTO TRANS. NONE RESTORE (IN ACTIVE FOR MUTUAL BACKUP) When Auto Trans. None-restore and Mutual Backup is inactive, A power is master. If A power is normal, it closes. When A power is abnormal and B power is normal, A power opens and B power closes. If A power recovers to normal, the switch remains at B power close status.

  • Page 22: Auxiliary Contact Feedback Input Of Switch Open

    12 COMMUNICATION CONFIGURATION AND CONNECTION 12.1 ILLUSTRATION The ATbS C55 dual power ATS controller has an RS485 communication port and a USB communication port. The RS485 communication port allows connection to LAN of open structure. The communication port applies the Modbus communication protocol.

  • Page 23: Definition Of Connecting Terminals

    13 DEFINITION OF CONNECTING TERMINALS 13.1 DESCRIPTION OF CONNECTING TERMINALS Fig.6 Controller Back Panel Table 22 Terminal Function Description Functions Description Remark B disconnects output N Output AC power; control B power switch to disconnect, rated 8A B disconnects output L A disconnects output N Output AC power;...

  • Page 24: Description Of Controller Supply

    A(+) RS485 communication port 120Ω Resistor (for impedance matched) has been connected inside B(-) Users need to connect this terminal to Terminal 21 based on on-site RS485 impedance-matched 120Ω Resistor network arrangement; used to connect with the 120Ω resistor inside resistor the controller ASW1...

  • Page 25: Description Of Rs485 Connection

    B1 B2 AT1 AT2 BT1 BT2 16A 5A 5A 16A 9 10 11 12 16 15 14 13 Remote ATbS C55 Start Fig.9 ATS type TN Application Diagram Table 23 Related Settings Partial Parameter Setting Switch Type Setting Two breakings...
  • Page 26 A1 A2 B1 B2 16A 5A 5A 16A 9 10 11 12 16 15 14 13 Remote ATbS C55 Start Fig.10 ATS type N Application Diagram Table 24 Related Settings Partial Parameter Setting Switch Type Setting No breakings ATS type PC LOAD POWER "A"...

  • Page 27: Attached Illustration For Lo, No Connection Inside Controller

    14.2 ATTACHED ILLUSTRATION FOR LO, NO CONNECTION INSIDE CONTROLLER The ATbS C55 controller has an automatic transfer function for the ATS power supply inside. Normal ATS power supply is ensured only if one voltage of A power and B power is normal, achieved by transferring between the normally open (N/O) contact and normally closed (N/C) contact of intermediate relay 1 and intermediate relay 2.

  • Page 28: Installation

    15 INSTALLATION The controller is designed for panel installation and is secured in place using clips for installation. Unit: mm Fig.14 Overall Dimensions and Cutout 16 FAULT FINDING Table27 Fault Finding Symptom Possible Solutions Verify DC supply voltage; Controller does not respond with power Inspect DC fuse;...
  • Page 29 Designed by BTB Electric Add: Orhangazi Mah. Mimsan San. Sit. 1780 sok. No: 5 Esenyurt / İstanbul / Türkiye 4 I 2024 E-mail: sales@btb-electric.com Web: btb-electric.com F O R L I F E ELECTRIC...
