48/ROUND
WWW.ZETR.COM.AU / CONTACT@ZETR.COM.AU
FIXED MOUNTING ASSEMBLY / 48-FMA
INSTALLATION GUIDE
48-FMA
COMPATIBLE PRODUCTS
PRODUCT
ROUND SINGLE OUTLET
ROUND SINGLE OUTLET
ROUND SINGLE OUTLET ROUND EARTH PIN
ROUND SINGLE OUTLET ROUND EARTH PIN
ROUND 1 GANG SWITCH GRID CLIPSAL SHAPE
ROUND 1 GANG SWITCH GRID CLIPSAL SHAPE
ROUND 1 GANG SWITCH GRID HPM SHAPE
ROUND 1 GANG SWITCH GRID HPM SHAPE
TOOLS
PH1 DRIVER
INSTALLATION
The safety of the device is guaranteed when the instructions and use are
in-line with those outlined. It is recommended that this manual is stored
safely and referred to throughout the life of the device.
ELECTRIC SHOCK, EXPLOSION OR ARC FLASH HAZARD
Hazardous voltage and electrical current may be present at the wire leads
of this product even when the device is switched off.
When carrying out installation or maintenance, it is essential to isolate
supply and follow the correct lock out and tag procedure at the point of
supply before accessing the device.
ȇ The device must be installed
according to the instructions
outlined in this document.
ȇ The device must be installed with
care, by a licensed electrician/
tradesman
ȇ Installation must comply with
Australian and New Zealand
standards ASNZ3000.
ȇ Pay attention to the wiring
diagrams and specifications
related to the installation.
ȇ Do not use this product for any
other purpose than specified in
this manual.
2MM FH DRIVER
48MM HOLE SAW
Get on-site help - Scan the QR code for detailed installation
instructions on this product and more.
zetr.com.au/installation
ATTENTION
DANGER
WARNING
ȇ If any part of the device is
ȇ The device must not be modified,
ȇ ZETR forfeits any liability and
INSTALLATION GUIDE 140824
SKU
48-O-FPE-B
48-O-FPE-W
48-O-RPE-B
48-O-RPE-W
48-1FC-B
48-1FC-W
48-1FH-B
48-1FH-W
ALLEN KEY [INCL.]
damaged prior to installation it
must be replaced/repaired by the
manufacturer or licensed service
agent prior to installation
or force fit. Any modification or
non-compliant installation will
jeopardise system safety and/or
result in equipment damage or
malfunction.
warranty for any modified
product and/or installation
Advertisement
Related Manuals for ZETR 48/ROUND
Summary of Contents for ZETR 48/ROUND
- Page 1 ȇ Pay attention to the wiring result in equipment damage or diagrams and specifications malfunction. related to the installation. ȇ ZETR forfeits any liability and ȇ Do not use this product for any warranty for any modified product and/or installation other purpose than specified in this manual.
- Page 2 Mark out the centre for the location where you Insert 48-FMA into the hole cut-out, drive Remove the faceplate from the outlet/switch intend to install your outlet/switch grid. self-tapping screws through the mounting grid. accessory, plasterboard and mesh to fasten. PLASTERBOARD Using a 48mm hole saw, cut a single hole, A.
- Page 3 Turn the device clockwise until the arrow is pointing directly up and the device stops rotating. Push the circlip into the provided slot and fasten with M2.5x8mm screw. Snap fit the faceplate to the device. Wipe the device with a soft damp cloth or detergent-impregnated wipes to complete installation.
