Liquid Crystal Display
LCD-80
Instruction Manual
Document 15037
F
04/25/2008
Rev:
P/N 15037:F
ECN 08-364

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOTIFIER LCD-80 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Honeywell NOTIFIER LCD-80

  • Page 1 Liquid Crystal Display LCD-80 Instruction Manual Document 15037 04/25/2008 Rev: P/N 15037:F ECN 08-364...
  • Page 2 Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! An automatic fire alarm system—typically made up bed, and violent explosions (caused by escaping gas, of smoke detectors, heat detectors, manual pull sta- improper storage of flammable materials, etc.).
  • Page 3 Microsoft Corporation. LEXAN® is a registered trademark of GE Plastics, a subsidiary of General Electric Company. ©2008 by Honeywell International Inc. All rights reserved. Unauthorized use of this document is strictly prohibited. LCD-80 Instruction Manual — P/N 15037:F 04/25/2008...
  • Page 4 • Brief description of content you think should be improved or corrected • Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services.

  • Page 5: Table Of Contents

    Table of Contents Section 1: Product Overview ..........7 1.1: UL Compliance..................7 1.1.1: UL Standards ................7 1.1.2: Products Subject to AHJ Approval ..........7 1.1.3: Programming Features Subject to AHJ Approval ......8 1.2: Common Features................8 1.3: ACS Mode ...................8 1.4: TERMINAL Mode ................9 Section 2: The LCD-80 and ACS Mode ......
  • Page 6 Table of Contents Appendix A: EIA-485 Shield Terminations ......41 Appendix B: AIM-200 Point Annunciation......43 LCD-80 Instruction Manual — P/N 15037:F 04/25/2008...

  • Page 7: Section 1: Product Overview

    Section 1: Product Overview The LCD-80 alphanumeric display module is an ancillary device used by Notifier fire alarm control panels including AFP-200, AFP-300, AFP-400, AM2020/AFP1010, NCA, NCA-2, NFS-320, NFS-640, NFS2-640, NFS- 3030, NFS2-3030, System 5000, and System 500. The product has two basic modes of operation: ACS, where it acts as an alphanumeric annunciator, and Terminal, where it acts as a Display Interface.

  • Page 8: 3: Programming Features Subject To Ahj Approval

    Product Overview Common Features 1.1.3 Programming Features Subject to AHJ Approval This product incorporates field-programmable software. The features and/or options listed below must be approved by the local AHJ. This product incorporates field-programmable software. In order for the product to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options must be limited to specific values or not used at all as indicated below.

  • Page 9: Terminal Mode

    TERMINAL Mode Product Overview AM2020/AFP1010, NFS-3030(optional) & NFS2-3030(optional) Note: Security points must have “Security” as part of its custom label on the LCD-80 to differentiate between a fire alarm and a security alarm condition. NOTE:The LCD-80 should not be used as a primary display in Canada. NOTE:The LCD-80 should not be used as a primary display for releasing service.
  • Page 10 Product Overview TERMINAL Mode Address Switch (ACS Mode only) A rotary decimal switch (SW2) and a DIP switch (SW3) are provided for setting the LCD-80 “start SW1 DIP Switch Settings address” when the LCD-80 is set for ACS Mode. Refer to Figure 2.3 (ACS The address may be set from 01 to 32;...

  • Page 11: Section 2: The Lcd-80 And Acs Mode

    Section 2: The LCD-80 and ACS Mode System 5000/System 500: Use of the LCD-80 with Remote Command Inputs is not recommended. AM2020/AFP1010, NFS-3030(optional) & NFS2-3030(optional): Security points must have “security” as part of its custom label on the LCD-80 to differentiate between a fire alarm and a security alarm condition.
  • Page 12 The LCD-80 and ACS Mode 8-position DIP switch (SW1) SW1-1)Set “ON” for Receive Only SW1-5) Size (see Table 2.1 below). operation (for LCD-80s in addition to SW1-6) Size (see Table 2.1 below). those that occupy available addresses). SW1-7) Set “OFF” in this mode. SW1-2)Set “ON”...

  • Page 13: Setting The Lcd-80 Address For Acs Mode

    Setting the LCD-80 Address for ACS Mode The LCD-80 and ACS Mode DIP Switch Size of EIA-485 Number LCD-80s LCD-80s display addresses of points labels system* AFP-200 40 characters 40 characters 20 characters four 20 characters * Max LCD-80s per system doesn't restrict the number of LCD-80s that can be set for “Receive Only”...
  • Page 14 The LCD-80 and ACS Mode Setting the LCD-80 Address for ACS Mode DIP SW3-1 DIP SW3-2 Rotary SW2 Start Address 01-09 01-09 0-09 19-19 0-09 20-29 0-02 30-32 03-09 Table 2.2 Setting the LCD-80 Address in ACS Mode Alternately, the address could be determined by: Example: Set the LCD-80 for a size of two addresses with start addresses of “01.”...
  • Page 15 Setting the LCD-80 Address for ACS Mode The LCD-80 and ACS Mode EIA-485 To EIA-485 terminals on Cabinet Observe the following requirements when connecting the EIA-485 circuit: • The LCD-80 requires operating power! Connect 24 VDC power to TB1 terminal 3(+) and TB1 terminal 4 (-).

  • Page 16: Remote Printer Connections (Acs Mode)

    The LCD-80 and ACS Mode Remote Printer Connections (ACS Mode) TB5-1 EIA-485 (+) AFP-200 TB5-2 EIA-485 (-) TB4 (+) left pin EIA-485 (+) AFP-300, AFP-400 TB4 (-) right pin EIA-485 (-) TB3 (+) top pin EIA-485 (+) TB3 (-) bottom pin EIA-485 (-) NCA-2, NFS-3030, TB7 (+)
  • Page 17 Remote Printer Connections (ACS Mode) The LCD-80 and ACS Mode Shield (connect to chassis common on printer - no connection at LCD-80 ) Twisted shielded pair Plug this DB-25 connector into the EIA-232 port of the printer. See Section 2.3 “Printer Configuration”...

  • Page 18: Printer Configuration

    The LCD-80 and ACS Mode Printer Configuration 2.3 Printer Configuration Refer to the documentation supplied with the PRN for instructions on the printer’s menu controls. Set the printer’s options as follows: L/R ADJUST: FONT: HS DRAFT LPI: 6 CPI ESC CHARACTER: BIDIRECTIONAL COPY: CG-TAB: GRAPHIC...

  • Page 19: Power Connections

    Power Connections The LCD-80 and ACS Mode 2.4 Power Connections The LCD-80 can be powered by a +24 VDC power supply UL 864 9th Edition listed for fire protective applications, as well as FACPs with integral power supplies. CAUTION:Risk of Equipment Damage! Do not power the LCD-80 from any unfiltered power source designed for powering NAC devices.

  • Page 20: Operating The Lcd-80 In Acs Mode

    The LCD-80 and ACS Mode Operating the LCD-80 in ACS Mode 24 VDC (+) Common (-) FCPS-24S6/8 TB4-9 TB4-10 TB10 Nonresettable TB10 Nonresettable 24VDC- NFS-320, NFS2-640 24VDC+ NFS-3030, TB6+ TB6- NFS2-3030, NCA-2 MPS-24A TB3-3 TB3-4 MPS-24B TB2-1 TB2-2 AFP-200 TB1-3 TB1-4 AFP-300, TB2-1...
  • Page 21 Operating the LCD-80 in ACS Mode The LCD-80 and ACS Mode 2. Annunciator Backbox model ABF-1B or ABS-1TB with AKS-1B key switch option. Acknowledge Switch* When the ACKNOWLEDGE switch is activated on the front panel, the LCD-80 sends an acknowledge command to the control panel over the EIA-485 interface, using the first switch position on the start annunciator address.

  • Page 22: Display Patterns

    The LCD-80 and ACS Mode Display Patterns Once the TIME SELECT switch has been pressed, the TIME SET switch can be used to step through all possible values for that field. The new value is stored into the clock chip upon depression of either the Select or Display switch.

  • Page 23: 2: Alarm Message

    Display Patterns The LCD-80 and ACS Mode 2.6.2 Alarm Message When one or more alarms are reported to the LCD-80, the following display format is used. If more than one alarm occurs, the LCD-80 shows the first alarm that occurred in time. 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 R O W 1 <...

  • Page 24: 4: Trouble Messages

    The LCD-80 and ACS Mode Display Patterns Where “FIRST POINT LABEL” is the 20-character user-defined label for the first point to go into alarm. “LAST POINT LABEL” is the last alarm to occur in time. If there is only one alarm, row 3 is blank. The default label format is: “ZONE NNN (AXXPYY)”...

  • Page 25: 7: Display Illumination

    Display Patterns The LCD-80 and ACS Mode 2. The alarm/trouble count field (line 4 in alarm or trouble display messages) is replaced with the time and date field (line 4 in the System Normal message). 3. If a point returns from alarm to normal or from trouble to normal, this change of status will be printed.

  • Page 26: Interface Operation

    The LCD-80 and ACS Mode Interface Operation 2.7 Interface Operation 2.7.1 EIA-485 Interface The EIA-485 interface generally emulates from one to four ACM-16AT annunciators, each with three expanders (64 points each). ACM-24AT, ACM-48, and their expanders should be set to 64-point operation. For compatibility with System 5000 and System 500, the first eight points on an LCD-80 set for address 01 are used for the following functions: LCD-80...

  • Page 27: 4: Programming From The Crt Display Monitor

    Interface Operation The LCD-80 and ACS Mode Programming outline: • Remove 24 VDC power. • Remove the LCD-80 from its mounting. • Connect the EIA-232 interface to a CRT or personal computer. • Reconnect 24 VDC power. • Insert the PK-1 Programming Key onto connector P6. •...
  • Page 28 The LCD-80 and ACS Mode Interface Operation • Enter Setup Mode by pressing simultaneously. • Press Function Keys F1 through F13 to view the 13 separate groups of parameters. Use the arrow keys to move through each parameter within a group and use the space bar to view and select the options for each parameter.

  • Page 29: 6: Programming From An Ibm-Compatible Computer

    Interface Operation The LCD-80 and ACS Mode 2.7.6 Programming from an IBM-Compatible Computer Programming the LCD-80 from an IBM-compatible computer requires a custom cable (P/N 75267); this cable provides a 9-pin female connector for connection to a serial port. If using a computer with a DB-25 connector, use DB9M-to-DB25F adapter (P/N 46029).

  • Page 30: Default Messages And Point Labels

    The LCD-80 and ACS Mode Default Messages and Point Labels PC Communications software used to program the LCD-80 must be used in “direct connect” or terminal mode and set for the following options: • 2400 Baud. • 7 Data Bits. •...

  • Page 31: Entering Custom Messages

    Entering Custom Messages The LCD-80 and ACS Mode NOTE:When the LCD-80 is used in conjunction with a combination fire and security panel, the “FIRE” in default messages 1 and 4 must be removed. To restore default messages: • If in Program Mode, remove the Programming Key. •...

  • Page 32: Entering Custom Point Labels

    The LCD-80 and ACS Mode Entering Custom Point Labels Any one of the nine custom messages may be programmed by pressing the respective number followed by ENTER on the keyboard. The LCD-80 screen and the display monitor will display either a default message or whatever message was last stored in the unit.
  • Page 33 Entering Custom Point Labels The LCD-80 and ACS Mode NOTE: System 5000 is limited to 128 points. AFP-200 uses Zones 1 to 99 only. Once a point number has been entered, the LCD-80 screen will display either the custom zone message (illustrated below) or the last stored point message.
  • Page 34 The LCD-80 and ACS Mode Entering Custom Point Labels Continue to enter point label information or press ESC to return to the initial programming prompt: ENTER 1 to 9 FOR 9 CUSTOM MESSAGES OR 0 FOR CUSTOM POINT LABEL: Once all programming of the LCD-80 has been completed, remove the Programming Key.

  • Page 35: Section 3: The Lcd-80 & Terminal Mode

    Section 3: The LCD-80 & Terminal Mode The LCD-80 set for Terminal Mode operates like a CRT terminal without full keyboard capability, but with the advantages of 24 VDC power, wall mount, and multiple terminal location with Acknowledge, Signal Silence and Reset.
  • Page 36 The LCD-80 & Terminal Mode • The EIA-485 terminal interface does not support the use of RPT-485 repeaters. The RPT-485 repeater can only be used to extend the ACS EIA-485 circuit. 8-position DIP switch (SW1) 1)Not used. 2)Not used. 3)Set “ON” to disable Piezo. 4)Set “ON”...

  • Page 37: Operating The Lcd-80 In Terminal Mode

    Operating the LCD-80 in Terminal Mode The LCD-80 & Terminal Mode 3.1 Operating the LCD-80 in Terminal Mode 3.1.1 Display Patterns The LCD-80 displays directly the information from the FACP terminal interface without alteration. Note: The ALARMS PENDING, TROUBLES PENDING, Alarm Count and Trouble Count information will not be displayed on the LCD-80.

  • Page 38: 3: Terminal Mode Eia-485 Connection Requirements

    The LCD-80 & Terminal Mode Operating the LCD-80 in Terminal Mode Silence Switch When the SILENCE switch is pressed on the front panel, the LCD-80 sends a Signal Silence command to the control panel, emulating the CRT terminal. System Reset Switch When the System Reset switch is pressed on the front panel, the LCD-80 sends a Reset command to the control panel, emulating the CRT terminal.
  • Page 39 Operating the LCD-80 in Terminal Mode The LCD-80 & Terminal Mode First LCD-80 R-120 resistors are required (set DIP Switch across In and Out circuits on SW3-1 and SW3-2 each LCD-80. “Off” on all LCD-80s See notes in the preceding except last one) text.
  • Page 40 The LCD-80 & Terminal Mode Operating the LCD-80 in Terminal Mode EIA-485 Connections on OUT(-) RET(-) OUT(+) RET(+) LCD-80 CCM-1 P3-4 P3-3 P3-2 P3-1 (AM2020/AFP1010) TB1-4 TB1-3 TB1-2 TB1-1 (AM2020/AFP1010) AFP-200 TB5-2 TB5-4 TB5-1 TB5-3 AFP-300, AFP-400 TB3-4 TB3-2 TB3-3 TB3-1 NFS-640 TB12...
  • Page 41 Appendix A: EIA-485 Shield Terminations The EIA-485 circuit must be wired using a twisted-shielded pair cable having a Characteristic Impedance of 120 ohms, +/- 20%. Do not run cable adjacent to, or in the same conduit as, 120-volt AC service, noisy electrical circuits that are powering mechanical bells or horns, audio circuits above 25 Vrms, motor control circuits, or SCR power circuits.
  • Page 42 EIA-485 Shield Terminations LCD-80s can only occur at the receiving end—the end connected to LCD- 80 P1 Terminals 2 and 4. AM2020/AFP1010 Note: For the first LCD-80 on the loop, let the shield coming in from the CCM-1 or DIA float. LCD-80 Instruction Manual —...
  • Page 43 Appendix B: AIM-200 Point Annunciation The CPU-5000 can be programmed for an alternate method of annunciating the AIM-200. Up to 192 intelligent devices can be annunciated on a single LCD-80 annunciator. The System 5000 annunciates the AIM-200 installed directly to the right of the CPU-5000. Note that an annunciator cannot be used to execute manual ON/OFF control of intelligent AIM-200 points only standard System 5000 zones.
  • Page 44 AIM-200 Point Annunciation Annunciator Address 4 Intelligent Detectors, addressed 65-96, followed by Addressable Modules, addressed 65-96, on the AIM-200 installed next to the CPU-5000. The System 5000 Programming Manual, Document 15584, provides programming instructions for this option. Refer to program choice “AIM(256).”...
  • Page 45 This warranty is void if the product is altered or repaired by anyone other than Honeywell International Inc. or as expressly authorized by Honeywell International Inc. in writing, or is serviced by anyone other than Honeywell International Inc.
  • Page 46 World Headquarters 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 fax 203-484-7118 www.notifier.com...
