Summary of Contents for Zorlu VESTEL TRM 65 EK
- Page 1 ELECTRICAL WATER HEATER USER MANUAL TRM 65 EK / TRM 80 EK...
- Page 2 Dear Customer, First of all, congratulations for choosing a nature and technol- ogy friendly VESTEL product. Aspiring to present products above and beyond your expecta- tions, which is manufactured meticulously at VESTEL’ s mod- ern plants and rigorously quality-controlled, into your use. This operating manual will guide you through the use of your appli- ance.
-
Page 3: Table Of Contents
Contents Safety Warnings ������������������������������������������������������������� 4 Safety Information on the Installation of the Appliance ����� 4 Safety Information on the Use of the Appliance �������������� 5 Safety Information to Take into Consideration During Cleaning and Maintenance ����������������������������������������� 8 Safety Information to Take into Consideration During Han- dling and Transportation ��������������������������������������������... -
Page 4: Safety Warnings
Safety Warnings WARNING: Do not operate Safety Information on your water heater without making sure that it is filled the Installation of the Appliance with full of water. If water is WARNING: Using voltage of flowing when you open the hot your water heater is 230 Volt. -
Page 5: Safety Information On The Use Of The Appliance
Safety Information on the thorized service staff in order Use of the Appliance to avoid a dangerous situa- WARNING: The limiting ther- tion. • Installation and repairs mostat will disable the resist- should always be done by ance in case of excessive tem- Authorized Service. - Page 6 operated with intervals in knowledge, provided that order to prevent limescale they are given supervision accumulation and confirm and instruction about safe- that it is not blocked. ly use of the appliance and • While connecting the safe- that the hazards caused by ty valve to the appliance, the appliance are under- make sure that the drain-...
- Page 7 Never use your appliance dren. under the following condi- • Before use, check the func- tions: tions of your appliance ac- curately. • If the appliance or the pow- • The appliance should be er cable is damaged, used only if it is plugged in •...
-
Page 8: Safety Information To Take Into Consideration During
risk of electric shock occurs health problems may oc- when electrical connec- cur. tions within the appliance • If the appliance will be re- are touched and when the mounted at a new location, mechanical structure of the contact with the author- appliance is changed. -
Page 9: Safety Information To Take Into Consideration During Han
Safety Information to cale that may form on the Take into Consideration resistance due to the wa- During Handling and ter hardness and the high Transportation temperatures should be re- moved in every two years While handling the appliance, regularly by the Authorized make sure that all electrical Service. -
Page 10: Choosing The Mounting Position
Liability Limitation Choosing the Mounting Position All technical information, in- • Do not install the appliance structions for use, operating in non-ventilated and hu- and maintenance of the appli- mid areas. ance included in this manual • Do not place the appliance are the most up to date in- to areas that are under di- formation on your appliance. -
Page 11: Technical Specifications
Technical Specifications TRM 65 EK TRM 80 EK Model Capacity Water Temperature °C 25-75 25-75 Setting Range Voltage 220-240 220-240 Current Resistance Power 2000 2000 The Highest Operating Pressure of Safety 10(-0.5,+0) 10(-0.5,+0) Valve Water Connection Inch Protection Class IP24 IP24 Enameled Interior Drum and Magnesium Anti-Corrosive System... -
Page 12: Installation Distances
Installation Distances The distances specified in the chart below should be applied in the installation of the appliance. Min 50mm Min 50mm Min 1100mm Circuit Diagram DISPLAY RL I COM NO BROWN BLUE INPUT YELLOW/GREEN BLUE GRAY : LIMIT THERMOSTAT : THERMISTOR RESISTANCE : DISPLAY... -
Page 13: General View
General View The images in the user manual are for informational purposes only about the parts of the device. Parts may differ de- pending on the device model. Pictures are representative. 1� ON/OFF and temperature setting button 2� Status indicators Controls and Indicators 1�... -
Page 14: Functions And Features Of The Water Heater
Functions and Features V Automated Switch You can switch ON and OFF the ther- of the water heater mostat using the V-Automated switch. Strength against V - Automated Switch acts as a safety corrosion device. It will disconnect the product from the mains in case of an electrical The inner drum of your water heater, short circuit or the product is switched including the water input and output... -
Page 15: Low Voltage Safety
Operation that it is filled with water reconnect to the mains supply, the water heater will After your water heater is installed and commence its normal operation. made ready for use by the authorised service, you can switch it on by turning Low Voltage Safety the temperature adjustment knob on If voltage is dropped to level harmful... -
Page 16: Practical And Useful Information
Practical and Useful level 4 degrees below the set tem- perature, the resistance will be Information activated again and the water is • The sediments and limescale ac- heated to the set temperature. cumulated at the below section • When the set temperature is be- of the water heater will prevent low 25ºC, water heater will be direct contact between the water... -
Page 17: Suggestions For Operation
Suggestions for Opera- limescale that my form on the re- sistance due to the water hardness tion and the high temperatures should • Do not place items that are vulner- be removed regularly by the Au- able to water beneath the water thorized Service. -
Page 18: Troubleshooting
Troubleshooting Before calling the service ensure that the failure is not related with a temporary electrical black out or water cut. In case you observe an abnormality in your appliance, you may try to solve the problem according to the instructions below. If your appliance does not still op- erate properly, contact the Call Center. - Page 19 MANUFACTURING FIRM: The lifetime of your product (the duration of keeping the necessary replacement parts for the appliance to continue functioning) as estab- Vestel Beyaz Eşya San. ve Tic. A.Ş. Manisa Şubesi lished and declared by Republic of Turkey Ministry of Customs and Trade Manisa OSB III.
