OPERATION AND MAINTENANCE MANUAL
(TRANSLATION OF THE ORIGINAL INSTRUCTIONS)
SEMI-AUTOMATIC
THERMOSEALING MACHINE
WITH DIE-CUT
Mod: TSS102-F
– Via G.Carminati 30 – Loc. Brembilla – 24012 Val Brembilla (BG) – Italy –
Ph. +39 035/4521184 Fax. +39 035/4528260
Website:
www.jpack.it
Email:
info@jpack.it
JM095_ENG_TSS102-F_02 (10.09.2023)
Page 1 of 28
Advertisement
Table of Contents
Summary of Contents for Jpack TSS102-F
- Page 1 OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) SEMI-AUTOMATIC THERMOSEALING MACHINE WITH DIE-CUT Mod: TSS102-F – Via G.Carminati 30 – Loc. Brembilla – 24012 Val Brembilla (BG) – Italy – Ph. +39 035/4521184 Fax. +39 035/4528260 Website: www.jpack.it Email: info@jpack.it...
-
Page 2: Foreword
Jpack S.r.l. thanks you for your choice and welcomes you among our numerous customers, hoping that operating this machine will give you complete satisfaction. This manual can be used for the models TSS102-F and has been designed to enable you to work on the various parts and to perform a correct maintenance and troubleshooting. -
Page 3: Table Of Contents
OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) TABLE OF CONTENTS FOREWORD ..................................2 MAIN MACHINE COMPONENTS..........................4 GENERAL RULES AND WARNINGS ........................5 1.1 INFORMATION PROPERTY ..........................5 1.2 HOW TO READ AND USE THIS MANUAL ......................5 1.2.1 STORING THE MANUAL .......................... -
Page 4: Main Machine Components
OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) MAIN MACHINE COMPONENTS Fig. 1 1. CONTROL PANEL 2. FILM CENTRING RINGS 3. FILM REEL SUPPORT ROLLER 4. FILM PRESSER 5. MOULD OPENING HANDLE 6. POWER CORD 7. FUSE 8. POWER SUPPLY SOCKET / MAIN SWITCH 0/1 9. -
Page 5: General Rules And Warnings
1.2.3. UPDATE METHODOLOGY IN CASES OF CHANGES TO THE MACHINE The descriptions and illustrations in this manual are not binding. Jpack S.r.l. reserves its right - without prejudice to the basic characteristics - to perform changes to the aforementioned machines at any time, for the purpose of functional, commercial and aesthetic improvement, without the obligation to update previous manuals and productions, except in exceptional cases. -
Page 6: Safety Information
• Do not install the machine in explosive or inflammable environments. • Do not tamper with, remove or modify the safety devices of the machine; in such cases Jpack S.r.l. declines all liability regarding machine safety. • Do not alter machine parts to adapt other devices without prior authorization from Jpack S.r.l.; in case of unauthorised alterations, Jpack S.r.l. - Page 7 OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) WARNING! The operator, maintenance/cleaning personnel, etc. have to strictly comply both with the accident prevention regulations and the safety provisions in force in the country and in the factory of use, in addition to the instructions, warnings and safety rules contained in this manual.
-
Page 8: Information About The Machine
OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) 2. INFORMATION ABOUT THE MACHINE 2.1 TECHNICAL SPECIFICATIONS MACHINE, TRAYS AND REEL DIMENSIONS Length 450mm Width 295mm Height 555mm Length with tray holder removed 800mm Overall weight 25Kg Max. tray size 235x180 h 135 mm 200mm Max. -
Page 9: Machine Identification
All data herein are to be referred to the manufacturer if any problems arise. Make sure that the plate is always intact and attached to the machine. Otherwise contact JPack S.r.l. to request another one by paying the purchase price set by the manufacturer. -
Page 10: Intended Use
Removing the packed trays. La TSS102-F is entirely made up of stainless steel and aluminium. The sealing plate and the film cutting unit are positioned inside the machine; they lower, by means of an electric motor, and sealing and film cutting around the trays’... -
Page 11: Unintended Use (Forbidden)
In case of fire, promptly disconnect the power supply by unplugging the plug and use a “powder-type” extinguisher (NEVER USE WATER). WARNING! The accident prevention devices and safety devices should not be removed or tampered with. JPack S.r.l. will not be held liable for any damage due to an incorrect use of the machine. JM095G_ENG_TSS102-F_02 (10.09.2023) -
Page 12: Improper Use
WARNING! Do not tamper with, remove or modify the safety devices of the machine; in such cases Jpack S.r.l. declines all responsibility for the safety of the machine. -
Page 13: Residual Risk Management
JPACK recommends you to always check the machine condition before and constantly during operations.If the check is unsuccessful, JPACK recommends you to operate onto the machine when power supply has been disconnected, contacting a qualified maintenance technician as soon as possible. -
Page 14: Transport And Storage
In particular, check that the following parts are in good condition: • External parts of the machine. • Electrical cables. The carrier shall be liable for any damage occurring during transport, that should be reported immediately to JPack S.r.l. Fig. 4 JM095G_ENG_TSS102-F_02 (10.09.2023) -
Page 15: Storage
OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) 3.2 STORAGE The instructions given in this section should be observed if the machine is to be stored, even temporarily. STORAGE SPECIFICATIONS • Allowed temperature range: -15°C - +55°C. • Allowed humidity range: 30 – 90%. •... -
Page 16: Machine Positioning
OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) 3.3 MACHINE POSITIONING In addition to the overall dimensions of the machine that will be shown below, the following conditions are to be met: • The power supply sources should be arranged near the installation area, according to the machine data. •... -
Page 17: Installation
Before carrying out ordinary and continuous operations onto the machine, check machine performance, running at least ten packaging operation cycles. If problems occur during the test, contact JPack S.r.l. Customer service immediately. In these cases whatever dismantling, fixing or set-up operations may be very dangerous. -
Page 18: Film Positioning
OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) 4.4 FILM POSITIONING Fig. 7 When positioning the film reel, the power supply should be disconnected and the trayholder pulled out (pos.1 Fig. 7). Position the film reel (pos.2 Fig. 7) onto the roller (pos.3 Fig. 7) and centre it by means of the corresponding centering rings (pos.4 Fig. -
Page 19: Machine Operation
CHOICE OF PACKAGING PROGRAMS The TSS102-F thermosealing machine can store up to nine different sealing programs. To select the program to carry out operations, press the RESET (pos. 10 Fig. 8) and the program currently operating will be displayed. Pressing the RESET button and buttons 8 or 9 simultaneously changes the program. -
Page 20: On-Screen Alarms And Warnings
OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) 5.4 ON-SCREEN ALARMS AND WARNINGS WARNING The display shows STA = The machine has been switched on with the mould inserted, remove the mould to start processing. The display shows ALS and the red LED is on = Thermal probe faulty or disconnected. The display shows HOT and the red LED is on = Temperature out of control. -
Page 21: Mould Usage
Turn off the electric power. Wear protective gloves against cuts and burns. The thermosealer TSS102-F is equipped with a die-cut. The sealing plate and the blades on the mould upper part and the lower trayholder are shaped and suitable for the packaging of a single format of trays. The film is cut around the border. -
Page 22: Maintenance And Cleaning
7.1. ROUTINE CLEANING The TSS102-F thermosealing machine is manufactured in full compliance with current regulations, with a degree of protection making it highly resistant to external agents. Nonetheless, it should be used with care, as the IP20 rating provides protection against splashing, but not against great masses of water. -
Page 23: Unscheduled Maintenance
WARNING! The user should never dismantle any parts of the machine. In case of need for extraordinary maintenance, contact JPack S.r.l. In the event of a fault, unscheduled maintenance should be carried out by a specialised technician, contacting the service department. -
Page 24: Dismantling
OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) 8. DISMANTLING WARNING! All machine dismantling operations should be carried out by qualified and authorised personnel. SCRAPPING OF THE EQUIPMENT Once the end of the machine’s technical and operational life has been reached, the machine is to be scraped. Even when the machine is decommissioned and no longer used for the purposes for which it was designed and manufactured, reusing the raw materials making it up should be possible. -
Page 25: Ec Declaration Of Conformity
UNI EN ISO 14120 : 2015 UNI EN ISO 14119 : 2013 The technical manufacturing file of the machine has been designed by: Name Salvi Pierbattista JPack Issued in [place] Via G. Carminati 30 24012 Val Brembilla (BG) ITALY Date 01.09.2023... - Page 26 OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) Note: _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________...
- Page 27 OPERATION AND MAINTENANCE MANUAL (TRANSLATION OF THE ORIGINAL INSTRUCTIONS) _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________...
- Page 28 To ensure a safe and perfect performance of your machine, always use ORIGINAL SPARE PARTS – Via G.Carminati – Località Brembilla - 24012 Val Brembilla (BG) – Italy – Ph. +39 035/4521184 Fax. +39 035/4528260 Website: www.jpack.it Email: info@jpack.it JM095G_ENG_TSS102-F_02 (10.09.2023) Page 28 of 28...
