- Page 1 ANLEITUNG ZUM GEBRAUCH - INSTRUCTION BOOKLET GASHERDE GAS COOKERS JGS 1000 JGS 1010 JGS 3010 JGS 5010 JGS 5110...
- Page 2 The typeplate can be seen after opening of the oven door at the right side. The present instruction for use is valid only for countries the abbreviation of which is shown on the front page of the instructions as well as on the appliance.
-
Page 3: Table Of Contents
Page 48 Open burners Page 39 Connection to the mains Page 50 Oven Page 40 Conversion to other type of gas Page 51 Use of the electric grill Page 42 What to do, if ... Page 56 After-sales-service and spareparts... -
Page 4: Control Panel
Knob for front left open burner - standard burner Knob for front right open burner - cooking burner Knob for rear right open burner - standard burner (except for models JGS 1000) Knob for oven burner (and electric grill in model JGS 5010) Indicator lamp (with model JGS 5010, only) MOD. -
Page 5: Technical Data
Protective Protective screen for screen for knobs knobs The gas hob is registered acc. to German Standard DIN-DVGW. CATEGORY II 2 ELL 3 B/P This appliance corresponds to the following E.E.C. regulations: 73/23 - 90/683 (low voltage guideline): 89/336 (EMC guideline):... -
Page 6: Instructions For Use
Because of pushing the ignition knob an ignition spark will jump over to the burner and ignite it. After ignition of the flame keep the rotary knob pushed in for about 5 seconds; this time is required to heat up the „tempera- ture sensor“... -
Page 7: Oven
The Prepare the glasses in the usual manner. Make use of pot size must be chosen in a way that the flames will not commercial preserving glasses with rubber ring and exceed the pot rim. - Page 8 The oven burner is ignited with the door opened. Turn the oven control knob to the left in porition 10, push in against stop, and ignite the gas flowing out. After ignition keep the control knob pushed in for about 5 more seconds until the temperature sensor is sufficiently heated and the flame remains stable.
-
Page 9: Use Of The Electric Grill
FO 2124 Fig. 8 INDICATOR LAMP FOR ELECTRIC GRILL This lamp is located at the right of the control panel and comes on when the electric grill is switched on. In case of models with gas oven and during grill operation leave the oven door open a crack and mount the protective strip for the knobs (Fig. - Page 10 5 minutes. After the baking have the cake stand in the tin for 5 to 10 minutes. Afterwards loosen from the tin or from the sheet and have it cool down on a cake grid.
- Page 11 Poultry can be prepared in a big roasting vessel, on the wire shelf, or direct in the drip pan. Have fat roasts cook on the wire shelf in order to enable the fat to drip off. At PRESERVING IN THE OVEN first pour about ˚...
-
Page 12: Chart With Cooking Times
Pork cutlet 10 min per Side Beef cutlet 20 min per Side Merguez-sausages 10 - 15 min 10 - 15 min acc. to size or thickness Fish 3 - 4 Chicken portions 20 min per Side Hot dishes 5 - 10 min... -
Page 13: Fig. 10
- For cleaning do not make use of scouring agents, caustic cleaners and hard objects. - Do not scratch off burnt-in residues, instead soak them with a wet cloth or with hot water resp. and remove with a little cleanser additives. OPEN BURNERS For the cleaning of pot rests, hob unit and open burner sections use hot water with a little cleanser additive;... - Page 14 Unscrew the glass cover in anticlockwise direction and replace the bulb (socket E 14, 230V, 25 W, 300 C). Afterwards screw down the glass cover again. The replacement of the oven lamp is not covered by the guarantee.
-
Page 15: Installation Instructions
The gas connection must be accessible and provided with a shutoff device. Prior to any action stop the feed of gas to the cooker The minimum distance between gas cooker and cooker hood must correspond to the instructions given by the manufacturer of the hood. - Page 16 Recommended is a safety gas socket. Same should be located at the right or left, outside the radiation area. The connection can be carried out rigid or by the use of a DVGW-approved safety gas hose with socket acc. to DIN 3383, page 1.
-
Page 17: Connection To The Mains
The power supply cable is to be installed in a way that no position will reach a temperature exceeding 50 C above room temperature. If there is need to replace the power supply cable, do please make use of cable type H05RR-F with a cross- section designed for the load of the appliance. -
Page 18: Conversion To Other Type Of Gas
CONVERSION TO OTHER TYPE OF GAS When converting to a different type of gas there is need for an additional setting of the amount of gas or for a replacement of jets resp. (see charts I to VII). CONNECTION TO LPG... - Page 19 REPLACEMENT OF OVEN JET Pull out the oven bottom sheet. Unscrew the fastening screw and remove the oven oven burner burner Turn out the burner jet and insert the jet suitable for type acc. charts I to VII. Re-install in reverse sequence.
- Page 20 Marking of jets The term „marking of jets“ is referring to the jet diameter in hundredth of mm. In case of jets marked with „E“ the nominal values for thermal load and for throughput of gas are achieved by the setting of jets.
- Page 21 With conversion to a different type of gas fix a corresponding label. When setting to natural gas E the high-burner fixed jet, the low-burner setting jet as well as the primary air setting sleeve will have to be sealed-in again.
- Page 22 I screw down acc. to chart I. the setting jet for LPG until stop. With conversion to a different type of gas fix a corresponding label! Chart VII Conversion from natural gas LL to ... Oven burners...
-
Page 23: What To Do, If
WHAT TO DO, IF ... To file an after-sales-service call is not always necessary. In some cases you may cure the problem by yourself. For this purpose please find some hints below. Important! Repair work must exclusively be carried out by experts. Inappropriate repairs may result in considerable danger for the user. -
Page 24: After-Sales-Service And Spareparts
For this reason we reccomend that for any problem you Loosen the two screws located at the sides of the contact the dealer who sold it to you, or our nearest cock bar. authorized Service Centre, specifying the nature of the Remove the cone and clean it carefully.
