Full Motion TV Wall Mount
Instruction Manual
Rev01(B)
Model: TZMFK4
Thank you for choosing this Totnz product! At Totnz, we strive to provide
you with the best quality products and services in the industry. Should you
have any issues, please don't hesitate to contact us.
support@totnz.com
Advertisement
Summary of Contents for Totnz TZMFK4
- Page 1 Instruction Manual Rev01(B) Model: TZMFK4 Thank you for choosing this Totnz product! At Totnz, we strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us.
-
Page 2: Important Safety Information
If your TV VESA is greater than 400 x 400mm / 15.7 x 15.7" or less than VESA 100 x 100mm / 3.9 x 3.9", this mount is NOT compatible. If this mount is NOT compatible, please contact customer service at support@totnz.com to find a compatible mount. - Page 3 Do not use damaged or defective parts. lf you require replacement parts, please contact our customer service at support@totnz.com. • NOTE: Not all hardware included in this package will be used.
- Page 4 M6 x 15mm M6 x 35mm [D1] x 4 [D2] x 4 M8 x 25mm M8 x 50mm [E1] x 4 [E2] x 4 Supplied Parts and Hardware for Step 2 NOTE: The lag screw is shown in actual size Lag Screw ST5/16 x 2 3/4"...
- Page 5 When using the spacers it is important to note that they can be used in multi-layers (meaning stacked). If you have any difficulty understanding how to install the TV bolts or spacers, please contact customer service at support@totnz.com. CAUTION: Ensure the TV brackets...
- Page 6 Option C (For TV with A “Bump”) C1 / D1 / E1 B1 / B2 C2 / D2 / E2 F1 / F2 B1 / B2 Alternate Setups Alternate Spacer Setups Spacer F1 / F2 / F3 Option D For cable interference or inset holes, use spacers to create extra space between the TV and TV brackets.
- Page 7 2A-1 Stud Finder (Not lncluded) (Not lncluded) Use a stud finder (not included) to locate wood studs or use an awl (not included) to verify the edges. Mark the edge and center locations. 2A-2 HEAVY! You may need assistance Arrow with this step.
- Page 8 Step 2B Solid Concrete or Concrete Block Option WARNING: ● Avoid potential personal injury or property damage! DO NOT over-tighten the lag screws [A1]. Tighten the lag screws [A1] only until they are pulled firmly against the wall plate. ● Ensure the arm assembly / wall plate [01] is securely fastened to the wall before continuing to the next step.
- Page 9 2B-4 HEAVY! You may need assistance 1/2" (13mm) Socket Wrench with this step. Arrow (Not lncluded) Install the arm assembly / wall plate [01] using lag screws [A1]. Tighten the lag screws [A1] only until they are pulled firmly against the wall plate.
- Page 10 Step 4 Secure the TV onto the Wall Plate TV brackets are three-height-adjustable. You can choose the proper height. The first The third The second choice choice choice HEAVY! You may need ① assistance with this step. 4-1 Hang the TV to the TV plate. ①...
- Page 11 Step 5 Adjustments Tilt Tilt Adjustment 1. Slightly loosen the knob [T]. 2. Adjust TV to your desired tilt position. 3. Retighten the knob [T] to fix the tilt position. CAUTION! To prevent the TV from falling Level 7/16" (11mm) off, DO NOT over-loosen these Socket Wrench four nuts when adjustment.
- Page 12 Thank you again choosing this Totnz product! All of us do appreciate your product purchase. We hope that you are as happy with your product as we are designing and manufacturing it for you. We strive to provide you with the best quality products and services in the industry.
