- Page 1 B-210 � Hardware and Install Manual � Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 2: Table Of Contents
Other Connections ..........27 � Connecting a Power Adapter (Optional) ..........27 � Connecting the DI/DO and Audio Devices (Optional) ......29 � How to Connect DI/DO Devices ............29 How to Connect Audio Devices ............32 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 3 How to Insert / Remove a Memory Card ..........39 � How to Insert the Memory Card on B-210 Camera ......39 Accessing the Camera ........41 � Configure the IP Addresses ..............41 � Access the Camera................45 � Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 4: Precautions
We cannot be held responsible for any typographical or technical errors and reserve the right to make changes to the product and manuals without prior notice. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 5 Information Technology Equipment according to European Standard EN 55022 and EN 55024. In a domestic environment, this product may cause radio interference in which cause the user may be required to take adequate measures. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 6: Safety Instructions
Safety Check Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine if the video product is in proper operating condition. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 7: Introduction
Cable Gland Drill Template Terminal Block Terminal Block Desiccant Bag (for Power) (for DI/DO and Audio In/Out) Quick Installation Guide NOTE: The pictures are for reference only, actual items may slightly vary. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 8: Physical Description
See Connecting the DI/DO and Audio Devices (Optional) on page 29 for information. Reset Button Restores the factory default settings of the To reset the camera, while the power is on, press Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 9 Insert a memory card into this slot for local recording purposes. See How to Insert / Remove a Memory Card on page 39 for more information. NOTE: Supports microSDHC and microSDXC cards. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 10: Mounting Options
Gang Box Converter. All cables are hidden inside the gang box. B-AD-WM Pendant Suitable when mounting the camera on hard and high ceilings. Mount B-31-MK B-31-ST (Straight Tube) Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 11 Suitable when mounting the camera on vertical poles. Mount B-OD-WM B-31-PM Horizontal Suitable when mounting the camera on horizontal poles. Pole Mount B-31-MK B-31-ST B-31-PM Corner Suitable when mounting the camera on a corner wall. Mount B-OD-WM B-31-CMB Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 12 NOTE: For more information about the mounting solutions and accessories, please check the website. The above mounting accessories are not included in the package. Contact your sales agents to purchase. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 13: Installing The Camera On A Surface
If the cables will be routed along the surface, just drill the three (3) screw holes on the surface. 3. Detach the drill template from the surface and insert the plastic plugs into the screw holes. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 14: Step 2: Open The Dome Cover
3. Carefully lift to open the dome cover and place it on the side of the camera. NOTE: Do not abruptly lift the dome cover; it is attached to the camera with a spring wire. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 15 DO NOT remove this desiccant bag to keep the camera interior parts dry. In case too much moisture has already been absorbed by the desiccant bag, you may replace the bag with the one included in the camera package. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 16: Step 3: Prepare For Waterproof And Connect The Cable
Cable Gland Conduit Gland For use with 1/2” flexible conduit (not For use with an Exterior-grade Ethernet included in the package) cable (not included in the package). Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 17: Waterproof Solution With Naked Cable
1. Disassemble the cable gland as shown below: Sealing Insert Body Clamping with Claw (with Washer) 2. Insert the clamping nut into the Ethernet cable. 3. Insert the sealing insert with claw. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 18 5. If the cable will be routed along the surface, pull the network cable through the side conduit hole. If the cable will pass through the surface, pull the network cable through the bottom conduit hole. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 19 How to Insert the Memory Card on page 39 and follow the procedures to install a memory card. Otherwise, skip this step. 9. Proceed with Step 4: Install the Camera to the Surface on page 25. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 20: Waterproof Solution With Conduit
Conduit Gland 1/2" Trade size (included in the camera package) (not included in the package) For use with 1/2” flexible conduit Network Cable CAT 5 or CAT 6 (not included in the package) Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 21 If connecting other input/output devices or an external power adapter, pull the cables through the flex conduit without connectors. The terminal blocks will be attached once the cables pass through the camera hole later. 4. Insert the clamping nut through the flex conduit. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 22 7. If the cable(s) will be routed along the surface, skip this step. If the cable will pass through the surface, do the following: a. Pull the network cable through the bottom conduit hole. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 23 Then, proceed with Step 4: Install the Camera to the Surface on page 25. 9. If connecting other cables, attach the terminal blocks to the cables. See Other Connections on page 27. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 24 11. Align the camera module to the guide on the housing. 12. Tighten the three (3) screws to secure the camera module to the housing. 13. Proceed with Step 4: Install the Camera to the Surface on page 25. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 25: Step 4: Install The Camera To The Surface
The manufacturer will not be responsible for camera damage caused by improper installations or the misuse of equipment for installation. Step 5: Close the Dome Cover 1. Tighten the three (3) screws to attach the dome cover to the camera body. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 26: Step 6: Connect To The Network
As needed, power up the other connected devices. Step 7: Access the Camera Live View Accessing the Camera on page 41 for more information on how to access the Live View of the camera. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 27: Other Connections
2. Take note that a standard power adapter cable has two (2) different wires: Connects to GND Pin White stripe: Connects to 12V Pin 3. Connect the wire with the white stripe to the 12V pin and the other to the GND pin. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 28 5. Set the prepared power adapter for connection later. Below is an example of a power adapter with an attached terminal block. NOTE: The power adapter is not bundled in the package. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 29: Connecting The Di/Do And Audio Devices (Optional)
Connect the wires of the output device to DIO PW Digital Output and DO. (DO) DIO GND Connect the wires of the input device to DIO GND Digital Input and DI. (DI) Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 30 In this case, use the DIO GND and DI pins to connect a DI device and use the DIO PW and DO pins to connect a DO device. See wiring scheme below: Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 31 The illustration below is a graphic example of connecting a relay to a high voltage DO device. 110V-220V AC External Power Source Relay (DO1 Device) Camera Illuminator NOTE: For more information on DI/DO connections, please refer to the Knowledge Base article on the website. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 32: How To Connect Audio Devices
Connect the wires of the audio input device to Audio Input AI_GND (Pin 3) and A_IN (Pin 4). (A1) A_IN NOTE: For more information about AUDIO in connections, please refer to the Knowledge Base article on the website. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 33: Other Adjustments And Accessories
1. Using the bundled hex screwdriver, loosen the three (3) screws to open the dome cover. 2. Using a standard Phillips screwdriver, loosen the three (3) screws securing the camera module. 3. Lift to remove the camera module from the housing. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 34: How To Install The Camera Module
How to Install the Camera Module 1. Align the camera module to the guides on the housing. 2. Tighten the three (3) screws to secure the camera module to the housing. 3. Close the dome cover. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 35: How To Replace The Dome Cover
Hold the spring wire as the screw is being removed to avoid the sudden release of the screw and cause it to fly in the air. 3. Remove the three (3) screws to detach the cover bracket. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 36 4. Remove dome cover from the cover housing. 5. Remove the rubber from the dome cover. 6. Insert the rubber into the replacement dome cover. 7. Insert the replacement dome cover into the cover housing. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 37 Place the bracket on the cover housing with the arrow on the bracket aligned to the indent (a). 9. Attach the three (3) screws to secure the bracket to the cover housing. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 38 11. There are two (2) screw holes on the bracket, attach the screw to the right screw hole using a screwdriver. Final installation should look like the illustration below. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 39: How To Insert / Remove A Memory Card
In case there is a need to remove the card, make sure to access the camera Web Configurator to safely “unmount” the card first (see the camera Firmware User’s Manual for more information). Once unmounted from the firmware, push the card to eject it from the slot. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 40 B-210 Hardware and Install Manual Once inserted, make sure to access the camera Web Configurator and “mount” the card to prepare the card for local recording. Refer to the camera Firmware User’s Manual for more information. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 41: Accessing The Camera
The IP Utility can be downloaded for free from the website. With just one click, you can launch the IP Utility and there will be an instant report as follows: Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 42 You can quickly notice the camera model in the list. Click on the IP address to automatically launch the default browser of the PC with the IP address of the target camera filled in the address bar of the browser already. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 43 Manually adjust the IP address of the PC: In the following example, based on Windows 7, we will configure the IP address to 192.168.0.99 and set Subnet Mask to 255.255.255.0 by using the steps below: Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 44 In such case, please plug in only one camera at a time, and change its IP address by using the Web browser before plugging in the next one. This way, the Web browser will not be confused about two devices having the same IP address at the same time. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 45: Access The Camera
– the user just has to accept the use of such control when prompted so. No other third party utilities are required to be installed in such case. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 46 Before logging in, you need to know the factory default Account and Password of the camera. Account: Admin � Password: 123456 � For further operations, please refer to the Firmware User Manual. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
