The TMP-636 Telephone Transmit & Receive Patch allows you to record and play back to
your telephone from your PC or recorder. Compatible with most business and home phones.
• Great for recording web conferences,
• Record telephone conversations,
• Playback from your sound card over the phone (announcements, music, phone
conversations, etc.)
Installation is easy, and operation is automatic. The TMP-636 is compatible with analog and
digital phones, standard PC's and sound cards, and standard audio recorders. You can
leave it connected to your phone since it does not interfere with normal telephone operation.
Will not record speakerphone.
The operation of the TMP-636 is completely automatic. Simply install it according to the
instructions below and operate your PC recording controls as usual. Note: Make sure the
"Monitor" switch on your sound card software (if any) is set to OFF to avoid feedback.
Playback can be heard in your earphone and on the other end of the call.
To Install: (See diagram)
1
Unplug headset (or handset) coil cord from the base of the telephone, and plug the short
modular cord from TMP-636 in its place.
2
Plug the headset coil cord into the modular jack on the TMP-636.
3
Insert the 3.5mm GREEN plug on the long cord into the speaker or headphone jack on
the sound card or recorder.
4
Insert the 3.5mm PINK plug on the long cord into the MIC jack on the sound card or
recorder.
FOR LEGAL USE ONLY
www.DynaMetric.com
INSTRUCTIONS
TMP-636 PC/Telephone Audio Adapter
P/N 44150
Page 1 of 4
©DynaMetric 2002 Doc 44187
6-3-05
