Thank you for choosing another quality product from Amperes Electronics
Product in Summary
TD6240 is used as data receiver from Amperes PD Series of paging microphones, iPX5155 or iPX5455 IP BGM / Paging clients for zone
decoding and thereafter connected to zone selectors for activation of speaker line channels. With its harmonized protocol, it can be used
seamlessly with all UART related products from Amperes.
We shall endeavor to make products with contemporary needs and yet expandable for future upgrades. In this version, we had changed the
starting address setting, in which the start address is the start of zone number of the first channel of the device, instead of the start address of the
whole device. In such case, it will be more flexible and reduce the wastage of unused zone numberings.
We are sure you make the right decision to choose Amperes, which is not only offering the product that meets your budget, but perform beyond
your expectation.
We appreciate that you read through the manual to avoid any mishandling as well as to explore the full potential this unit can offer. Keep this
manual for future reference and we believe that you are getting an optimum product in its class.
Scan to view catalogue and latest updates
Ver 7 / 062024
INSTRUCTION MANUAL
24 Channel Data Decoder
In our support towards environment, we
shall no longer print manuals to be
accompanied with each product. Please
view through browser and print them
only when necessary.
TD6240
Improved
amperes
Go Green

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TD6240 and is the answer not in the manual?

Questions and answers

Summary of Contents for Amperes Electronics TD6240

  • Page 1 Product in Summary TD6240 is used as data receiver from Amperes PD Series of paging microphones, iPX5155 or iPX5455 IP BGM / Paging clients for zone decoding and thereafter connected to zone selectors for activation of speaker line channels. With its harmonized protocol, it can be used seamlessly with all UART related products from Amperes.

  • Page 2: Parts Identification

    This port shall be used if slave units are installed in the system. Link the data signal A/B to the data input of the next unit (Part 7). Ensure correct polarity and the unit setting. More than one TD6240 shall be used for larger system, such as 25 channels and above. 7. UNIT ADDRESS DIP SWITCHES Each decoder caters for 24 channel outputs, thus each DIP setting shall comprise address for a group of 24 channels.
  • Page 3 General Schematic Diagram TD6240 Mic connection ports do not affect paging mic PD1240 / 1280 priority. The priority level is set at the paging console Paging Mic 2 itself. PD1240 / 1280 Paging Mic 1 PD12400 / 1280 Paging Mic 3...

  • Page 4: Pin Configurations

    Multipoint Paging Installations and Connections to ZS Speaker Zone Selectors More than one PD series paging mic can be connected to TD6240, although there are only 3 connection ports available in the decoder. Use EX2800 with IN - OUT link as shown.

  • Page 5: Technical Specifications

    Dimension (WxHx D) 482 x 44 x 180 mm Weight 1.9 kg Note: The above specifications are correct at time of printing but subjected to changes without prior notice due to product improvements. PAGE 5 TD6240 | PAGING MICROPHONE DATA DECODER...

  • Page 6: Warranty Conditions

    Disclaimer Information contained in this manual is subjected to change without prior notice and does not represent a commitment on the part of the vendor. Amperes Electronics Sdn Bhd shall not be liable for any loss or damages whatsoever arising from the use of information or any error contained in this manual.
