- Page 1 Island Range Hood Installation Guide IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference...
-
Page 2: Table Of Contents
Proline Dream Home Series – Island Range Hood Installation Guide Table of Contents Before the Installation ........3 What You Will Need . -
Page 3: Before The Installation
Before the Installation 1. Check the contents of your box. They should include, depending on the specific model of your hood: • Range hood wall or ceiling mounting bracket • Support brackets hardware • Transition duct • Chimney(s) • Hardware packet with screws As you unpack your hood, remove any protective film from chimney sleeves, the filters, or the range hood before installation. -
Page 4: Install Ductwork
Proline Dream Home Series – Island Range Hood Installation Guide Install Ductwork 1. Plan where your ductwork will be located. • Install your ductwork in the shortest unobstructed path to the outside of your home. • Select a path that avoids studs, electrical wires, and other obstacles in your walls. - Page 5 2. Make measurements and markings on your ceiling. • Find and mark the joists on your ceiling. • You can either look in your attic for the joists to get a rough idea of where they are located. Or, get on a ladder and knock on your ceiling.
-
Page 6: Range Hood Installation
Proline Dream Home Series – Island Range Hood Installation Guide Step 1 Install the ceiling bracket. • Now that you’ve made your measurements and installed ductwork, drill holes into the four ceiling marks from Step 2 above. • These holes must hit ceiling joists or the added ceiling support. The support bracket needs to be supported by something that will hold the weight of twice the range hood. - Page 7 Step 3 Attach and seal the ductwork to the range hood. • Slide the top chimney sleeve over the support brackets, covering the ceiling bracket. • Screw the chimney into place at the top of the ceiling bracket. • Slide bottom chimney sleeve over the top chimney sleeve. Make sure the vent on the top chimney is towards the top.
- Page 8 Proline Dream Home Series – Island Range Hood Installation Guide Step 5 Attach and seal the ductwork to the range hood. • Attach the duct transition piece to the top of your range hood. Then, use the included screws to attach the transition to your ductwork.
-
Page 9: After The Installation - Final Steps
After the Installation – Final Steps Now you just need to do a few quick things to ensure that your installation went smoothly. Tighten the screws that connect the support brackets to the hood. • Double check these screws and make sure they are tight so your hood is secure. Assemble and insert baffle filters and the grease tray (if included). -
Page 10: Safety Information
• Clean your range hood filters, grease trays, and the range hood every few weeks. Heavy grease buildup shortens the life of your hood and it may lead to a grease fire. • All Proline range hoods are ETL certified. They meet all industry standards and regulations to ensure your safety. -
Page 11: Warranty Information And Return Policy
In the event of a grease fire: • Smother the flames with a large lid, pan, or baking sheet. If the fire is small, smother it with baking soda or salt. For larger fires, use a fire extinguisher. • Turn off all burners. •... - Page 12 4375 W 1980 S, Salt Lake City, UT 84104 Call (877) 901-5530 support@prolinerangehoods.com www.prolinerangehoods.com Our Support team hours are: Mon-Fri 8:30 am – 5:00 pm MST...
