Important
Warning!
1. Not Suitable for children under 36 months.
Choking hazard due to small parts
2. For family and domestic use only
Age: 3 Years +
3. Not to be used in traffic
Maximum user
4. Adult assembly required
weight :25Kg
5. Warning! Protective equipment should be worn
6. This toy has no brake
7
. This toy is unsuitable for children under
3 years due to its maximum speed.
8. This toy contains batteries that are
non-replaceable
Please keep this manual for future reference as it contains important information.
Before first time use, charge the battery for at least 8-12 hours, no more than 20 hours.
Advertisement
Summary of Contents for Jolly Mercedes Benz GTR
- Page 1 Important Warning! 1. Not Suitable for children under 36 months. Choking hazard due to small parts 2. For family and domestic use only Age: 3 Years + 3. Not to be used in traffic Maximum user 4. Adult assembly required weight :25Kg 5.
- Page 2 Page 2 Page 3 Page 4 Page 5-7 Operate Page 8-12 Page 13 Page 14-15 Page 15 Page 16 Battery: Suitable age: 3+ years DC 6V 4.5 AH *1 /12V4.5AH*1 Product size: Load Capacity: Under 25Kg 990*550*410 mm Optimum Material: Below 40 O C Temperature: 8-12 hours,...
- Page 3 single drive; screw is on it. double drives Wheel After- are the poppet same Rearview mirror Remote control M4X12 Instruction Spanner Manual training Line wheel...
- Page 5 Installation of training wheel Turn the car upside down. Remove the M4X12mm screw that has been fixed to the car body. Installa�on of training wheel. Then fixed with M4X12mm screw. Install drive motor on the rear axle Load a wheel on the rear axle Note: Double drive left and right wheel installation method is the same;...
- Page 6 Dock the docking plug before installing the seat Note: power plugs cannot be operated in reverse Non-rechargeable batteries can not be recharged. Batteries can only be recharged under adult supervision. Rechargeable batteries should be removed from vehicle before charging. Different types of batteries or old and new batteries can not be combined. The battery should be placed in the correct polarity.
- Page 7 Press the windshield into the body until installed. tt connectio the direction bar. gn ent of the hole on the steering wheel with the hole on the direction bar and insertion of the holes on both sides of the body.
- Page 8 Step 1: open the battery cover on the back of the remote control and load into two AAA(1.5V) batteries; (dry batteries are not available in this product) Step 2: turn off the main power switch on the car; Part 3: hold down Forward and Back keys at the same time, (note that hold down at the same time) when the Speed display flashing, the main power switch on the car, the Speed display red light to stop flashing, code success;...
- Page 10 Power Switgh Forward Reverse Switch Always stop vehicle when changing the speed or direction to avoid damage between the gear box and motor. Pedal player Switch 1. Turn on the power switch first. 2. Forward ● Press the“Forward and Reverse switch” to the “Forward”position. ●...
-
Page 11: Music Button
interface: insert USB terminal, connect audio source, ca n play audio; card ack: insert card, ca n play audio; MP3 interface: through the data line ca n be connected to other devices and play audio; Music switching / volume reduction: touch the button, switch the music, press the button long, the volume is down;... - Page 13 1. Find the charging input socket below the seat. 2. Plug the charger port into the input socket. 3. Plug the charger plug into a wall outlet. The battery will begin charging.
