3.5V to 60V Input Boost / SEPIC / Flyback DC-DC Converter
Brief Description
This procedure covers the KTC3500 EVAL Kit back-end final test and assembly before the EVAL Kit is placed into
box stock. The fully assembled PCB is tested on the bench to check limited, basic functionality. Then all the
EVAL Kit physical contents are assembled and packed into the EVAL Kit box.
Ordering Information
Part Number
KTC3500EVAC-MMEV01
Eval Kit Fully Assembled PCB
May 2024 – TAP-0023-01
Description
KTC3500 EVAL Kit
Page 1 of 4
EVAL Kit Test & Assembly Procedure
Kinetic Technologies Confidential
KTC3500
IC Package
DFN33-10
Advertisement
Summary of Contents for Kinetic Technologies KTC3500
- Page 1 Brief Description This procedure covers the KTC3500 EVAL Kit back-end final test and assembly before the EVAL Kit is placed into box stock. The fully assembled PCB is tested on the bench to check limited, basic functionality. Then all the EVAL Kit physical contents are assembled and packed into the EVAL Kit box.
- Page 2 IOUT/GND Output Current - pair (red/black) of either banana-to-banana or banana-to-clip leads Test Setup Diagram Power Supply Voltmeter 12V/5A − VΩHz KTC3500EVAC-MMEV01 VOUT VOUT E-LOAD EQUIVELENT POWER RESISTOR (12ohm/50W) May 2024 – TAP-0023-01 Page 2 of 4 Kinetic Technologies Confidential...
- Page 3 Guide is on top and showing its title, as per the Photo of EVAL Kit Box with Contents. 9. Close the EVAL Kit Box. 10. Add the completed KTC3500 EVAL Kit to box stock physical inventory and into the inventory database. May 2024 – TAP-0023-01...
- Page 4 EVAL Kit Test & Assembly Procedure KTC3500 Photographs of EVAL Kit Contents and Boxing Procedures CONTENTS INSERTED ITEMS LABELING May 2024 – TAP-0023-01 Page 4 of 4 Kinetic Technologies Confidential...
