Summary of Contents for tylr TYL-TT9038
- Page 1 INSTRUCTIONS MANUAL TYL-TT9038 P O R T A B L E V I N Y L RECORD PLAYER Revive the retro groove on the go www.tylrhome.com...
-
Page 3: Table Of Contents
Table of Contents IMPORTANT SAFETY INSTRUCTIONS ........3 PARTS AND FUNCTIONS ............5 BEFORE USE ................7 MAKING CONNECTIONS ............7 Stereo System Connection .............. 7 AUX Input Connection ..............8 OPERATING YOUR TURNTABLE ..........8 Platter Auto-Stop ................9 Pitch Control .................. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read and understand this entire manual before using this product. Keep these instructions for future reference. 1. Do not use this product near water. 2. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual. - Page 5 other hazards. Refer all servicing to qualified service personnel. 8. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 9. Do not use attachments not recommended by the product manufacturer as they may cause hazards.
-
Page 6: Parts And Functions
PARTS AND FUNCTIONS... - Page 7 Turntable Platter Turntable Spindle Tonearm Lever Hold Down Clip Auto-Stop Switch Speed Switch Tonearm Function Switch Pitch Control Knob On/Off-Volume Knob Headphone Jack Power Jack RCA Jacks Aux In Jack 45 RPM Adapter Also includes: 1 x 3.5mm Aux-in cable 1 x Power adaptor...
-
Page 8: Before Use
BEFORE USE 1. Place the unit on a flat and level surface. The selected location should be stable and free from vibration. 2. Remove the tie-wrap holding the tonearm. 3. Connect AC adaptor to the Power Jack of the unit. NOTE: Do not plug the AC power adaptor to power outlet before all the assembly is completed. -
Page 9: Aux Input Connection
AUX Input Connection You can connect an audio device to this unit and play your music through its speakers. To do this, set the Function Knob to wireless mode, connect the 3.5 mm auxiliary cable between your audio device, and the Aux-In Jack of this unit and start playing the music. -
Page 10: Platter Auto-Stop
position, the tonearm will descend slowly onto the record and begin to playback. 9. When the record is finished playing, use the Tonearm Lever again to raise the tonearm and then return it to the tonearm rest. Release the lever to let the tonearm sit back at its rest. To suspend the playback, repeat the same steps. -
Page 11: Needle Replacement
Needle Replacement Removing the Needle 1. Gently pull down the front edge of the needle. 2. Pull needle forward. 3. Pull out and remove. Installing the Needle 1. Position the needle with its tip facing down. 2. Line up the back of the needle with the cartridge. 3. -
Page 12: Bluetooth Operation
2. Turn on the wireless feature of your audio device, search for “TYL-TT9038” and pair. 3. Once your device is successfully paired with the unit, you will hear a short confirmation sound from the unit. -
Page 13: Troubleshooting
TROUBLESHOOTING There is no power. • Power adaptor is not connected correctly. • No power at the power outlet. • To help save power consumption, some models will comply with ERP energy saving standard. When there is no audio input for 20 minutes, their powers will automatically cut-off. To turn power back on and resume playing, turn off the power and turn it on again. -
Page 14: Warranty Terms And Conditions
WARRANTY TERMS AND CONDITIONS ONE-YEAR LIMITED WARRANTY ON PARTS AND LABOR TYLR provides a warranty to the original purchaser of this product against defects in materials and workmanship for one year. If a product covered by this warranty is determined to be... - Page 15 Types of Services Defective Products must be sent to any TYLR service center to obtain warranty service. TYLR is neither responsible for transportation costs to the service center nor TYLR will cover return shipping to the customer. Product returns to TYLR...
- Page 16 10. If any part or parts of the unit are replaced with a part or parts not supplied or approved by us, or if the unit has been dismantled or repaired by any person other than a TYLR authorized technician.
- Page 17 LISTED OR DESCRIBED ABOVE. ANY IMPLIED WARRANTIES, INCLUDING IMPLIED WARRANTY MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED IN DURATION TO THE PERIOD OF TIME SET FORTH ABOVE. TYLR’S TOTAL LIABILITY FOR ANY AND ALL LOSSES AND DAMAGES RESULTING FROM TYLR’S CAUSE WHATSOEVER INCLUDING...
