Magnum MANUAL CSCR User Manual

Single phase submersible pump panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
SINGLE PHASE
SUBMERSIBLE PUMP PANEL - MANUAL CSCR
To find more about us and our products, scan below QR codes
Facebook
Videos
Website
KALP CONTROLS
nd
Unit 1 : #40, 2 Main Road, Pete Chennappa Industrial Estate,
Kamakshipalya, Magadi Road, Bangalore-560079. (India)
Website:
www.magnumswitchgear.com
For queries and sugges ons mail us to
info@magnumswitchgear.com
Customer Care No: +91-8884759222

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MANUAL CSCR and is the answer not in the manual?

Questions and answers

Related Manuals for Magnum MANUAL CSCR

Summary of Contents for Magnum MANUAL CSCR

  • Page 1 USER MANUAL SINGLE PHASE SUBMERSIBLE PUMP PANEL - MANUAL CSCR To find more about us and our products, scan below QR codes Facebook Videos Website KALP CONTROLS Unit 1 : #40, 2 Main Road, Pete Chennappa Industrial Estate, Kamakshipalya, Magadi Road, Bangalore-560079. (India) Website: www.magnumswitchgear.com...

  • Page 2: Table Of Contents

    INDEX Sl. No. Topic Page No. Introduction Magnum SP MANUAL CSCR Panel Installa on and Instruc ons Moun ng Template Switching and Opera ng Technical Specifica on and Configura on Panel Dimensions Circuit Diagram Preca ions and Maintenance Troub e Shooting...

  • Page 3: Introduction

    INTRODUCTION Dear Customer, Congratula ons on purchase of MAGNUM Submersible Pump Panel ‘MANUAL’ CSCR. This is made with heavy duty components, which protects your pump from hazards caused due to over-current. Located in Bangalore, Kalp Controls commenced its opera ons in the year 2009.

  • Page 4: Magnum Sp Manual Cscr Panel

    ABOUT MAGNUM SINGLE PHASE ‘MANUAL’ CSCR PANEL: Magnum submersible control panels are controlling devices for your submersible pumps. These are made from quality raw materials, enabling it to protect and control your motor consistently. Func ons: Switches your pump/motor on and off.
  • Page 5 Salient Features: Powder coated MS enclosure for complete corrosion resistance & sturdiness. Heavy Duty Start & Run Capacitors. Fi ed with Miniature Circuit Breaker for reliable overload and short circuit protec on. Easy & quick moun ng. Ergonomic design with aesthe c looks. No screw protrusion from the panel, hence addi onal safety from water, dust, corrosion and electric shock.

  • Page 6: Installa On And Instruc Ons

    INSTALLATION INSTRUCTIONS : This Control Panel is designed to run only a Single-Phase Submersible Pump. It is very important to ensure the current ra ng (power in H.P) of your motor and Control Panel are same. Drill holes as per the given Moun ng Templates. Control Panel to Submersible Pump connection, Connect the incoming power supply to P and N terminals of the connector as shown in the above picture.

  • Page 7: Moun Ng Template

    MOUNTING TEMPLATE: (Not to scale)

  • Page 8: Switching And Opera Ng

    SWITCHING AND OPERATING: Switch on the supply. Ensure MCB is in ON posi on (Upwards) Press the PNO bu on to read incoming voltage and only when voltage is in the range of 170V to 240V, try to start the motor. To start the motor press the START (green) bu on for 3 - 4 seconds and immediately releases the bu on a er motor starts.

  • Page 9: Technical Specifica On And

    TECHNICAL SPECIFICATIONS: Power range : 0.5/1/1.5/2 HP : Up to 20A Area : (185*220*135) mm Net Weight : 2.1 – 2.5 KG Frequency : 50Hz Insula on Voltage Ac (Vi) : 660V Ambient Temperature : -25°C to +55°C Terminal Capacity : 1 * 16 (mm)^2 or 2 * 10 (mm)^2 Normal Configura on of the Panel: Start...

  • Page 10: Panel Dimensions

    PANEL DIMENSIONS : A (mm) B (mm) C (mm)

  • Page 11: Circuit Diagram

    CIRCUIT DIAGRAM:...

  • Page 12: Preca Ions And Maintenance Ut

    PRECAUTIONS & MAINTENANCE: It’s best that a qualified electrician installs the panel and repairs it in case of any problem. A dust free environment is vital for long run of the control Panel. It is very important to keep the control Panel away from water or moisture.

  • Page 13: Spares And Assemblies Available

    SPARES AND ASSEMBLIES AVAILABLE FOR THIS PANEL: Part Descrip on Specifica on Part No. Magnum SR-72 Ammeter 0-30 A AM723 Magnum SR-72 Voltmeter 0-500 V AM725 60-80µf CS80 80-100µf CS100 100-120µf CS120 Magnum Start Capacitor 120-150µf CS150 150-200µf CS200 200-250µf CS250 25µf...

  • Page 14: Warranty Card And Policy

    Warranty Policy: 1. This product carries a warranty, against manufacturing defects only for a period of 12 months from the date of manufacturing. The warranty is however subject to provision of proper usage, efficient maintenance and does not cover defects arising out of fire accident, Voltage Surge, Inefficient maintenance, faulty opera on and willful or accidental damage.
