- Page 1 Steinway & Sons Model S Soundbar INSTALLATION MANUAL Steinway & Sons Model S Soundbar – Installation Manual Version 1.0...
-
Page 2: Table Of Contents
LOUDSPEAKER MOUNTING ON THE WALL ................5 LOUDSPEAKER PLACEMENT ADVICE IN THE ROOM ...............7 CONNECTION OF EQUIPMENT ....................8 ROOM CORRECTION INTRODUCTION ..................9 CLEANING THE SPEAKER ………....................9 STORING THE SPEAKER ………....................9 REPACKING ……………….…..……………………………..…..............9 SERVICE INFORMATION ......................9 Steinway & Sons Model S Soundbar – Installation Manual... -
Page 3: Introduction To The Model S Soundbar
Safety Warnings Physical Handling The Model S Soundbar is very heavy. It can be difficult to handle. Follow all instructions for unpacking and installation. Use ergonomically correct body positions. Be careful not to unbalance the large speaker during handling. Steinway Lyngdorf cannot be held responsible for any physical damage which occurs during the installation process. - Page 4 8. Once the wall mount profile is safely attached to the wall, lift up the Soundbar and hang it at its final wall position. Make sure the speaker cable still runs through the cable canal. Steinway & Sons Model S Soundbar – Installation Manual...
-
Page 5: Loudspeaker Mounting On The Wall
LOUDSPEAKER MOUNTING ON THE WALL 1) Aluminum wall mount profiles. The Model S Soundbar is intended to be mounted on-wall with the two provided aluminum wall mount profiles. Attach one part to the back of the Soundbar using the provided screws. Attach the counterparts on the wall. - Page 6 Note: Only use heavy-duty mounting accessories matching the heavy weight of the Soundbar. Always choose screws and dowels matching the wall material, the wall construction, and the heavy weight of the Soundbar. Steinway & Sons Model S Soundbar – Installation Manual...
-
Page 7: Loudspeaker Placement Advice In The Room
RoomPerfect calibration: • The Model S Soundbar is mechanically and acoustically designed to be placed on-wall, or in-wall. • The ideal speakers placement should be in accordance with the basic stereo triangle (60x60x60 degrees), for example in front of a TV, with the main listening area (Focus position) at the tip of the triangle. -
Page 8: Connection Of Equipment
Please note: • Model S Soundbar combined with the Steinway & Sons P100, P200, P300: 1 x A2 or 2 x A1 can be used. • Model S Soundbar combined with the Steinway & Sons SP-1: 1 x A2 must be used. -
Page 9: Room Correction Introduction
STORING THE SPEAKER The Model S Soundbar features wooden parts, lacquereded parts, as well as electro-mechanical parts which are vulnerable for sudden changes in temperature as this will cause cracks in the wooden constructions and cause serious degradation of the lifetime of the electronic circuitry. - Page 10 Steinway & Sons Model S Soundbar – Installation Manual SL AUDIO A/S • RÆVEVEJ 3 • 7800 SKIVE • DENMARK • WWW.STEINWAYLYNGDORF.COM...
