Summary of Contents for Philips D1601B/63
- Page 1 Always there to help you Register your product and get support at www.philips.com/support D160 D470 Question? Question? D165 D475 Contact Contact D1601B/63 Philips Philips Extended user documentation...
-
Page 2: Table Of Contents
Contents 1 Important safety instructions 7 Phonebook View the phonebook Search a record 2 Your phone Call from the phonebook What is in the box Add a record Overview of the phone Edit a record Overview of the base station Delete a record Delete all records 3 Get started... - Page 3 Register additional handsets Unregister the handsets Restore default settings 13 Technical data 14 Notice Declaration of conformity Use GAP standard compliance Compliance with EMF Disposal of your old product and battery 27 15 Frequently asked questions 16 Appendix Text and number input tables...
-
Page 4: Important Safety Instructions
1 Important • This equipment is not designed to make emergency calls when the power fails. An safety alternative has to be made available to allow emergency calls. • Do not expose the phone to excessive heat instructions caused by heating equipment or direct sunlight. •... -
Page 5: Your Phone
2 Your phone Congratulations on your purchase and welcome to Philips! Power adapter** www.philips.com/welcome. What is in the box Line cord* 2 x AAA rechargeable batteries** Handset** Guarantee Short user manual Note • * In some countries, you have to connect the line adapter to the line cord, then plug the line cord to the telephone socket. -
Page 6: Overview Of The Phone
Overview of the phone • Press and hold to lock/unlock the keypad in standby mode. • Press and hold to enter a pause. (for D160) or (for D165) • Mute or unmute the microphone. • Access to the answer machine menu in standby mode (for D165 •... -
Page 7: Overview Of The Base Station
3 Get started Overview of the base station D160 Caution • Make sure that you have read the safety instructions in the ‘Important safety instructions’ section before you connect and install your handset. Connect the base station Warning • Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed on the back or the underside of the phone. -
Page 8: Install The Supplied Batteries
Install the supplied batteries Connect each end of the power adapter to (for multi handset version • the DC input jack at the bottom of the extra handset charger. • the power socket on the wall. Caution • Risk of explosion! Keep batteries away from heat, •... -
Page 9: Configure Your Phone
Enter the new PIN/passcode again, Configure your phone then press MENU/OK » The setting is saved. time, you see a welcome message. Charge the handset Press MENU/OK. Place the handset on the base station or Set the date and time the charging cradle to charge the handset. -
Page 10: What Is Standby Mode
and you hear an alert tone. base station/charger, the bars The battery is low and needs indicate the battery level (full, recharging. When the handset is on the It displays the connection base station/charger; the bars status between the handset and base station. -
Page 11: Check The Signal Strength
4 Calls Check the signal strength The number of bars indicates the connection status Note between the handset and base station. The more bars • When the power fails, the phone cannot access are shown, the better the emergency services. connection is. -
Page 12: Answer A Call
Adjust the earpiece Note volume • The talk time of your current call is displayed on the call timer. • If you hear warning tones, the phone is almost Press to adjust the volume out of battery or out of range. Charge the battery or move the phone close to the base station. -
Page 13: Switch Between Two Calls
Intercom and When there is a periodical beep to notify you of an incoming call, you can answer conference the call in these ways: Press and to answer the call. calls » are now connected to the second call. Press and to end the current call An intercom call is a call to another handset that shares the same base station. -
Page 14: Make A Conference Call
Press and hold Note » The current caller is put on hold. • Press to join an ongoing conference with » For multi-handset versions, the another handset if [Services] > [Conference] is handsets available for intercom are set to [Auto]. displayed, then go to step 2. -
Page 15: Text And Numbers
Text and 7 Phonebook numbers This phone has a phonebook that stores up to 50 records. You can access the phonebook from the handset. Each record You can enter text and numbers for can have a name up to 12 characters long handset name, phonebook records, and and a number up to 24 digits long. -
Page 16: Call From The Phonebook
Enter the number; then press MENU/ Scroll the contact list or press MENU/OK > Press » Your new record is saved. [PHONEBOOK] > [VIEW] to access the phonebook list. Press to scroll through • Press and hold # to insert a pause. the phonebook list. -
Page 17: Delete All Records
8 Call log Press MENU/OK. The call log stores the call history of all Select [PHONEBOOK] > [DELETE ALL], missed or received calls. The incoming call press MENU/OK history includes the name and number of the caller; call time and date. This feature »... -
Page 18: Save A Call Record To The Phonebook
Save a call record to the phonebook Press Press » The incoming call log is displayed. Press MENU/OK to enter the options » The incoming call log is displayed. menu. Select a record, then press MENU/OK Select [DELETE ALL], then press MENU/OK Select [SAVE NUMBER], then press MENU/OK... -
Page 19: Redial List
9 Redial list Press REDIAL/C to enter the list of The redial list stores the call history of dialed calls. dialed calls. It includes the names and/or Select a record, then press MENU/OK numbers you have called. This phone can store up to 10 redial records. -
Page 20: Phone Settings
10 Phone Select [ON]/[OFF], then press MENU/ settings » The setting is saved. Set the docking tone Docking tone is the sound made when your own phone. you place the handset on the base station or charger. Sound settings Press MENU/OK. Select [PHONE SETUP] >... -
Page 21: Telephone Answering Machine
11 Telephone Announcements answering The announcement is the message your caller hears when the answering machine machine picks up the call. The answering machine has 2 default announcements: the [RECORD ALSO] mode and [ANSWER ONLY] mode. Note Record an announcement •... -
Page 22: Incoming Messages
Select [PLAY], then press MENU/OK to Listen to the incoming message You can listen to the incoming messages » You can listen to the current in the sequence they are recorded. announcement. • If there are new messages, press / to listen. -
Page 23: Set The Ring Delay
Set the ring delay Activate/deactivate the remote access You can set the number of times the You can allow or block remote access to phone rings before the answering the answering machine. machine picks up the call. Press / or MENU/OK > [ANSW Press / or MENU/OK >... -
Page 24: Services
12 Services Press a key to carry out a function. See the Remote access commands table below for a list of available functions. The phone supports a number of features that help you handle and manage the Note calls. • When there is no message, the phone hangs up automatically if no key is pressed for 8 seconds. -
Page 25: Network Type
Set auto prefix Select the recall duration Press MENU/OK. Make sure that the recall time is set Select [SERVICES] > [AUTO PREFIX], correctly before you can answer a second call. In normal case, the phone is already then press MENU/OK preset for the recall duration. -
Page 26: Auto Clock
Enter the system PIN. Press REDIAL/ Auto clock C to make corrections. Then press MENU/OK Note » Registration is complete in less than • This service is network dependent. assigns a handset number to the • Make sure you have subscribed to the caller ID handset. -
Page 27: Restore Default Settings
FSK, DTMF • Frequency Range : 1881.792-1897.344MHz, Maximum Transmit Pover:22.7dBm” Battery • Philips: 2 x AAA Ni-MH 1.2V 300 mAh rechargeable batteries Power adapter Base and charger • PHILIPS: EP19A-060040WXEZ, input: 100-240 V~, 50/60 Hz 200 mA, output: Vdc 400 mA •... -
Page 28: Notice
Directive 2014/53/EU. You www.philips.com/support. This symbol on a product means that the product is covered by European Directive Use GAP standard 2012/19/EU. -
Page 29: Frequently Asked Questions
Frequently asked Your system consists of materials which can be recycled and reused if disassembled questions observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment. No signal bar is displayed on the screen. • The handset is out of range. - Page 30 • The charging contacts are dirty. • The service is not activated. Check with your service provider. clean the contacts with a damp cloth. The caller's information is withheld or • unavailable. I cannot change the settings of my voice mail, what do I do? Note The voice mail service is managed by your...
-
Page 31: Appendix
Appendix Text and number input tables Space 0 A B C 2 D E F 3 G H I 4 J K L 5 M N O 6 P Q R S 7 T U V 8 W X Y Z 9 # ' , - &... - Page 32 Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license.
