ARC4 - Optical ARC Detector System 2.0

A4-2-SYS-00-X

ARC4 Optical ARC Detector System 2.0

P100269327 Rev. 1.8 04.03.2022

-X

Manual

AFT microwave GmbH

Donaustr. 18

D-71522 Backnang – Waldrems

Germany

Phone: + 49 – (0)7191 / 9659 – 0

Fax : + 49 – (0)7191 / 9659 – 200

www.aft-microwave.com

info@aft-microwave.com

Table of Contents

Need help?

Do you have a question about the ARC4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aft ARC4

Page 1 Manual ARC4 - Optical ARC Detector System 2.0 A4-2-SYS-00-X ARC4 Optical ARC Detector System 2.0 ARC4 Optical ARC Detector System 2.0 AFT microwave GmbH Donaustr. 18 D-71522 Backnang – Waldrems Germany Phone: + 49 – (0)7191 / 9659 – 0 Fax : + 49 –...
Page 2: Table Of Contents
Manual ARC4 2.0 Table of Contents Preamble ..........................3 General Safety Notes ....................... 4 Unpacking ..........................6 Product Introduction ......................... 7 Front Panel Interface ......................11 Status Indication ........................12 Parameters and Settings ......................15 Installation and Initial Start ..................... 17 Safety Notes for Operation of the Device ................
Page 3: Preamble
The operating company has the obligation to:  Supply and give access to this manual to user personnel and operational staff at any time.  Train personnel concerning the use of AFT-products including safety notes. This manual contains important information for customer about: ...
Page 4: General Safety Notes
Observation of the Safety Notes is necessary to avoid injuries to personnel and damage to equipment. Therefore, it is necessary to carefully read and observe all following safety notes, before setting up the product. The described symbols and labels are generally used by AFT but do not all necessarily apply to this specific product.
Page 5 Manual ARC4 2.0 Components Equipment ground Grounding conductor Ground sensitive to conductor electrostatic discharge Fig. 2.2: Electrical symbols Table 2.1: Signal words Signal Words Meaning Indicates a dangerous area with high-risk potential. Danger Dangerous area can lead to death or serious injuries and severe damage to the product.
Page 6: Unpacking
Keep the original covers and caps for further transportation, storage and use.  Each ARC4 unit is supplied with a mains cable and connector kits for all electrical interfaces.  Ordered arc accessories such as fiber optic cables and arc viewport may be packed in the ARC4 box.
Page 7: Product Introduction
(glow) is detected with high sensitivity and fast response time. AFT arc detectors cannot avoid arcing, but they are designed to effectively limit the energy of the arc by ultra-fast light detection and by providing a fast interlock signal to shut-down the RF source.
Page 8 (AND/OR). These signals are available as TTL or O.C. With two SIMs one ARC4 system is capable of forming a total of four arc interlock signals (A, B, C, D) and thus to interlock up to four separate RF systems. The default logic for all GLBARCs is an OR combination of all 16 arc channels.
Page 9 Manual ARC4 2.0 Program keypad GLBARC keypad Arc channel keypad Power switch Fig. 4.1.: Front Panel View System Detector Interface Power Supply Modules Modules Module Module Fig. 4.2.: Back Panel View P100269327 Rev. 1.8 04.03.2022 Page 9 / 32...
Page 10 (c) CPU Module with USB and Ethernet (LAN) interface, (d) Power Supply (PS) module with Mains connector, (e) Optical Test Module (OTM) with 2x FSMA output and DB-9. For details about connector pin assignment see ARC4 2.0 datasheet. Page 10 / 32 P100269327 Rev. 1.8 04.03.2022...
Page 11: Front Panel Interface
Manual ARC4 2.0 5. Front Panel Interface The front panel of ARC4 2.0 is divided into functional fields, where multi-colored LEDs and highlighted buttons indicate current signal states or device status. ARC4 ARC CHANNELS STATUS INFO PRG / INFO TEST INT...
Page 12: Status Indication
Manual ARC4 2.0 6. Status Indication During startup the CPU verifies, if all previously registered modules are present in their slots or if any modules have been added into the chassis. Status of the given slot is shown by the corresponding button's color: constant green, constant white, blinking orange and blinking red.
Page 13 Manual ARC4 2.0 Table: 6.2: LED showing status of the device during operation Description Status OK Status alarm: in case of an error the STATUS LED changes from green to red. Possible causes:  CPU system data error  missing module ...
Page 14 Manual ARC4 2.0 Table 6.3: Front panel status info Keypad Description Active arc alarms for ARC CHANNELS 1 and 2 as well as GLOBAL ARC A By pressing a button with active alarm the alarm for this particular channel or logical group is...
Page 15: Parameters And Settings
Manual ARC4 2.0 7. Parameters and Settings Table 7.1: Operation Parameters and Settings Parameter Type Value Range Change via Definition Buttons Interface Normal: TTL-signal is low (0V) for no arc and high (5V) Signal in case an arc is detected.
Page 16 Manual ARC4 2.0 Table 7.2: Default Factory Settings Parameter Default Setting Inverted Signal Polarity Inverted Auto Reset 0.1 ms, if auto reset is activated Auto Reset Time 0.1 ms, if auto reset is activated Sensitivity Threshold 20 mV GLBARC Logic...
Page 17: Installation And Initial Start
8. Installation and Initial Start  Place the device in its intended position - the ARC4 2.0 can be used as a desktop device or installed in a 19" cabinet. Maintain environmental temperature and humidity conditions as specified in the data sheet.
Page 18: Safety Notes For Operation Of The Device
 ARC4 2.0 can only deploy its full capability of fast arc detection, if the arc viewport (observation point) is spot most close to a critical location. Even though in many cases the high light sensitivity allows the coverage of more than just a single spot, we always recommend to provide a separate arc viewport for each critical area.
Page 19: Test Functions
Manual ARC4 2.0 Test Functions The ARC4 2.0 allows the user to test proper function of light detection by two means – internal and external test. 10.1. Test Internal The internal test checks the proper function of detector itself and related electronics in all installed arc detector modules by introducing a short IR pulse from an internal IR LED through an additional bore directly into the detector input.
Page 20: Test External
10.3. Optical Test Module Multiple ARC4 Optical Test Modules (OTM) can be installed in any available slot for arc detector modules, that is slots 1-16, best starting from slot 16 and moving down. E.g., if two OTMs are to be installed, they should occupy slots 16 and 15.
Page 21: Info-Menu
Manual ARC4 2.0 The optional ARC4 Optical Test Module 2.0 is designed for precisely testing the functionality of up to two arc detector modules at a time along with connecting additional fiber optic cables. It enables the user to verify the full optical loop path of detection, from the arc viewport to the detector input. In this case the arc viewport has to be equipped with an additional FSMA test port, in such a way that the test port sends light into the arc viewport.
Page 22 Manual ARC4 2.0 ARC4 ARC CHANNELS STATUS INFO PRG / INFO TEST INT POLARITY GLOBAL ARC TEST EXT AUTORESET POWER RESET Fig.11.2: Front panel after entering INFO-Menu Current setting of polarity and autoreset for a particular channel or group is shown by color of the...
Page 23: Prg-Menu
Manual ARC4 2.0 ARC4 ARC CHANNELS STATUS INFO PRG / INFO TEST INT POLARITY GLOBAL ARC TEST EXT AUTORESET POWER RESET Fig. 11.5: Example 2: Front panel showing GLBARC group B consisting of CH1 to CH8 with a logic combination as: (CH1 AND ARC2) OR (CH3 AND CH4) OR CH5 OR CH6 OR CH7 OR CH8. All other arc channels are not active within GLBARC B.
Page 24: Prg Parameters
Manual ARC4 2.0 To save your changes: STATUS STATUS 5sec INFO INFO PRG / INFO PRG / INFO Fig. 12.2.: Steps to save changes: a press and hold PRG/INFO button for 5 seconds b the changes have been saved, PRG-Menu has been exited RESET Fig.
Page 25 Manual ARC4 2.0 The current setting of polarity and auto reset for a particular channel or group is shown by the color of the corresponding LED. Polarity = normal Polarity = inverted (default) TEST INT TEST INT TEST INT Polarity = normal...
Page 26: Prg Glbarc Logic
Manual ARC4 2.0 12.2. PRG GLBARC Logic Upon entering the menu ARC CHANNEL 1 will be highlighted. To set up the GLBARC logic, first choose the desired GLBARC group (A, B, C or D) by pressing its corresponding button while in the PRG-Menu Logic (PRG/INFO LED constant red).
Page 27: Basics Of Glbarc Logic
Note 12.3. Basics of GLBARC Logic Basically, ARC4 2.0 system interface modules offers two combinational logic schemes for a GLBARC group (A, B, C, D): an OR combination of selected arc channels and a pairwise AND combination of arc channels. Each GLBARC group can be programmed and used independently from each other.
Page 28 Manual ARC4 2.0 Fig. 12.11.: Timing diagram for GLBARC OR and AND logic with auto reset OFF (polarity = normal) Fig. 12.12.: Timing diagram for GLBARC OR and AND logic with auto reset ON. = auto reset time, polarity = normal) Page 28 / 32 P100269327 Rev.
Page 29: Maintenance, Storage And Modular Upgrade
Regard 13.3. Modular System Upgrade ARC4 2.0 can be upgraded with additional arc detector modules (ADM), optical test modules (OTM) and system interface modules (SIM) up to the max. number of card slots. ADMs and OTMs use card slots 1 to 16. The SIM models SIM-00 and SIM-01 use the dedicated slots 17 and 18 only.
Page 30: Help And Service Request
Procedure Return Shipment 1 First of all send a non-conformity or problem report. 2 Please contact AFT customer service center for RMA prior to any return shipment. Note: Return shipments without RMA will not be accepted by AFT. 3 Packing: Follow the instructions in section 3 to condition the device for packing and transport.
Page 31: Appendix
Manual ARC4 2.0 Appendix  Data Sheet A4-2-SYS-00-X P100269327 Rev. 1.8 04.03.2022 Page 31 / 32...
Page 32 Manual ARC4 2.0 Revision History: Revision Date Description 29.08.2018 initial 12.09.2018 Optical Test Module added 20.09.2018 Update product introduction 22.11.2018 Details about auto reset time 18.02.2019 USB Interface Access 17.02.2020 Safety notes revised, chapter 13.3 modular system upgrade 16.02.2021 System Interface Module SIM-01 added, RoHS 2015/863 (EU), product introduction updated 22.03.2021...
