Model Number
625B11
Performance
Sensitivity(± 5 %)
Measurement Range
Frequency Range(± 5 %)
Frequency Range(± 10 %)
Frequency Range(± 3 dB)
Resonant Frequency
Broadband Resolution(1 to 10 kHz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Temperature Response
Enclosure Rating
Electrical
Settling Time(within 1% of bias)
Discharge Time Constant
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Electrical Protection
Electrical Isolation(Case)
Physical
Size - Diameter
Size - Height
Weight(without cable)
Mounting
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material
Sealing
Cable Length
Cable Type
[7]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
PRECISION INDUSTRIAL ICP® ACCELEROMETER
EN GLISH SI
100 mV/g 10.2 mV/(m/s²)
± 50 g ± 490 m/s²
30 to 390 kcpm 0.5 to 6.5 kHz
22 to 450 kcpm 0.37 to 7.5 kHz
12 to 630 kcpm 0.2 to 10.5 kHz
1,500 kcpm 25 kHz
2
50 µg
491 µm/sec
± 1 % ± 1 %
≤ 5 % ≤ 5 %
5,000 g pk 49,050 m/s² pk
-65 to +250 °F -54 to +121 °C
See Graph See Graph
IP68 IP68
≤ 8.0 sec ≤ 8.0 sec
≥ 1.0 sec ≥ 1.0 sec
18 to 28 VDC 18 to 28 VDC
2 to 20 mA 2 to 20 mA
< 100 Ohm < 100 Ohm
8 to 12 VDC 8 to 12 VDC
2.5 µg/√Hz 2
24.5 (µm/sec )/√Hz
0.8 µg/√Hz 2
7.8 (µm/sec )/√Hz
2
0.5 µg/√Hz
4.9 (µm/sec )/√Hz
RFI/ESD RFI/ESD
8 8
> 10 Ohm > 10 Ohm
1.38 in 35.1 mm
1.13 in 28.7 mm
4.7 oz 133 gm
Through Hole Through Hole
1/4-28 Male Not Applicable
2 to 5 ft-lb 2.7 to 6.8 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
10 ft 3.0 m
Polyurethane Polyurethane
Optional versions have identical specifications and accessories as listed for the standard model
[1]
except where noted below. More than one option may be used.
[2]
- Hazardous Area Approval- contact factory for
EX
specific approvals
LB - Low Bias Voltage
[3]
Output Bias Voltage
[3] Excitation Voltage
Measurement Range
[4]
M - Metric Mount
Supplied Accessory: Model M081A73 Mounting Bolt M6 x 1.00
TO - Temperature Output
Temperature Output Range
Temperature Scale Factor
[3]
Electrical Connections
Electrical Connections
Electrical Connections
Electrical Connections
[3]
[3]
[3]
[5]
N OTES:
[1]Conversion Factor 1g = 9.81 m/s².
[2]The high frequency tolerance is accurate within ±10% of the specified frequency.
[3]Typical.
[4]Zero-based, least-squares, straight line method.
[5]1/4-28 has no equivalent in S.I. units.
[6]Twisted shielded pair.
[6]
[7]See PCB Declaration of Conformance PS023 or PS061 for details.
SUPPLIED ACCESSORIES:
Model 081A73 Captive mounting bolt 1/4-28 x 1.34" (1)
Model ICS-1 NIST-traceable single-axis amplitude response calibration from 600 cpm (10
Hz) to upper 5% frequency (1)
Model 080B45 Thermal Boot (1)
Model M081A73 Mounting Bolt M6 x 1.00 (0)
Entered: LK Engineer: gs
Date: 07/11/2019 Date: 07/11/2019 Date: 07/11/2019 Date: 07/11/2019 9911
3425 Walden Avenue, Depew, NY 14043
Revision: H
ECN #: 49714
OPTION AL VERSION S
6 to 8 VDC 6 to 8 VDC
12 to 28 VDC 12 to 28 VDC
± 35 g ± 343 m/s²
+36 to +250 °F +2 to +121 °C
5.56 mV/°F + 32 +10 mV/°C
Acceleration Output Acceleration Output
Ground Ground
Temperature Output Temperature Output
Ground Ground
Sales: MC Approved: BAM Spec Number:
Phone: 800-959-4464
Fax: 716-684-3823
E-M ail: imi@ pcb.com
