Philips HTS5560 Service Manual
  1. Manuals
  2. Brands
  3. Philips Manuals
  4. Home Theater System
  5. HTS5560
  6. Service manual
Philips HTS5560 Service Manual

Philips HTS5560 Service Manual

Hide thumbs Also See for HTS5560:

Advertisement

Quick Links

Download this manual
BD Home Theater System
Service
Service
Service
Service Manual
©
Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by
RY1016
Service Audio Printed in The Netherlands Subject to modification
Version 1.1
TABLE OF CONTENTS
Location Of PCB Boards............................................ 1-2
Versions Variation ...................................................... 1-2
Specifications ............................................................ 1-3
Measurement Setup .................................................. 1-4
Service Aids .............................................................. 1-5
ESD & Safety Instruction .......................................... 1-6
Lead-free Soldering Information ................................ 1-7
Setting Procedure & Repair Instructions ...................... 2
Disassembly Instructions & Service Positions .............. 3
Block & Wiring Diagram ................................................ 4
Quick Start Guide .......................................................... 5
VFD+USB+MP3+VOL+LED Board................................ 6
Main Board .................................................................... 7
Power Board .................................................................. 8
BD Board........................................................................ 9
Touch Board ................................................................ 10
Wireless JackBoard .................................................... 11
Mechanical Exploded View.......................................... 12
Revision List ................................................................ 13
1 - 1
Chapter
HTS5560/
12/51/98
3139 785 35271
GB
