Summary of Contents for Patriot SD-99
- Page 1 COUNTERTOP MERCHANDISER FREEZER USER MANUAL MODEL #: SD-99 Please read this manual completely before operating the merchandiser...
-
Page 2: Safety Precautions
1. SAFETY PRECAUTIONS The purpose of the safety precautions in this manual are to ensure safe and correct use of the unit to minimize risks that could cause serious damage and injury. The safety precautions are described in the WARNINGS and CAUTIONS. - Page 3 (12) Install the unit in a location where the countertop/surface is sturdy enough to support the load of the unit. If the countertop/surface is not sturdy enough or installation is incorrectly performed, the unit could tip over and falling shelves and contents could cause personal injury. (13) If you find gas leakage, unplug the unit immediately, open the door for ventilation and contact a qualified technician for service.
-
Page 4: How To Use
2. TECHNICAL DATA AND PRODUCT PARTS Top LED Sensor Shelf Door Contorller Feet Model SD-99 Dimensions (inch) 23.62” W x 20.55” D x 33.46” H Interior Size (inch) 18.62” W x 13.50” D x 25.00” H Volum 3.5 cu. ft The temperature range 0~-10℉... -
Page 5: Drain Tray
(3) Remove shipping package, tape, etc., and leave door open ventilate for a while. (4) The unit is cleaned before shipment. However, clean the cabinet after delivery with a damp cloth and then dry with a clean dry cloth. (5) Insert power supply plug into the wall outlet, single-phase. (6) Allow the unit to operate for at least 1.5 hour to cool the compartment before placing items in the merchandiser. - Page 6 SHELF HEIGHT ADJUSTMENT The shelf height can be adjusted, remove the shelf, and reinstall on one of the other guide rails to accommodate the product height. PLACING ITEMS IN THE MERCHANDISER This merchandiser uses a forced circulation of cold air system. If the circulation of cold air is obstructed, the items will not be adequately refrigerated.
-
Page 7: Temporary Storage
TRANSPORTATION Disconnect the power cord plug from the wall outlet. When moving the merchandiser make sure that the power cord is held by hand or taped to the back of the merchandiser so that the power cord doesn’t get wrapped around the feet/casters to avoid possible damage. TEMPORARY STORAGE ... -
Page 8: Circuit Diagram
CIRCUIT DIAGRAM... - Page 9 Patriot warrants its equipment against defects in materials and workmanship, subject to the following conditions: Patriot is warranted for one year, effective from the date of purchase by the original owner. A copy of the original receipt or other proof of purchase is required to obtain warranty coverage. This warranty applies to the original owner only, and is not assignable.
