Parts list
（According to the actual size; each type of screw and gasket have a spare.)
PRODUCT
INSTALLATION
GUIDE
Armrest*1 pair
Seat cushion*1 pc
Shim 13+1 pcs
X1
Spring leaf 13+1pcs
Hex wrench*1 pc
Backrest*1 pc
Castores*5 pcs
Base *1 pc
Mechanism *1 pc
SIZE： 60*68*116.5(126.5)CM
Gaslift*1 pcs
Armrest screw / mechanism screw / back screw (M8 * 20) 13 + 1
Note: before installing the chair, please sort the screws and measure the screw
length for installation.
