Summary of Contents for AudioResolution HA-32-VCA
- Page 1 HA-32 VCA Portable, 2 individual stereo headphone amplifier Owner’s manual...
- Page 2 Do not open the device or attempt to disassemble the internal parts or modify them in any outlet, and have the device inspected by qualified AudioResolution service personnel. way. The device contains no user-serviceable parts. If it should appear to be malfunctioning, •...
- Page 3 Company names and product names herein are trademarks or registered trademarks of their respective companies. Specifications and descriptions in this owner’s manual are for information purposes only. AudioResolution reserves the right to change or modify products or specifications at any time without prior notice.
- Page 4 Dear customer, Thank you for purchasing AudioResolution HA-32 VCA, professional analog, High-Fidelity, two stereo studio headphone amplifier with VCA volume control, which guarantees perfect balance between Left and Right channels. Signal path is complete analog with high dynamic headroom and lowest noise and distortion. The unit features three analog inputs (INPUT1, INPUT2, INPUT3) and two headphone outputs from each of two stereo amplifiers.
- Page 5 HA-32 VCA - Rear panel (Output section) HA-32 VCA - Top panel HA-32 VCA - Front panel (Input section) 1) Power connector 4) INPUT A/B volume 7) Phones 2 outputs Power supply connector, 24V DC /4. Volume knob for selected input routing by the Input Headphones outputs for second headphone channel, you routing switch.
-
Page 6: Operation
Operation HA-32 VCA is a 2-channel studio headphone amplifier designed for use as a personal Recommendation headphone amplifier at studio. It features three mono balanced inputs where first two of them Always lower the volume to minimum before connecting your headphones to avoid damage of can be routed to headphones as stereo combination –... -
Page 7: Specifications
Specifications AudioResolution HA-32 VCA Input section Number of inputs 3x mono Input connector 3-pin XLR Input sensitivity Line level Nominal input level 0dBu Input type Analog Output section Number of outputs 2x 2 stereo Output connector JACK 6,3 stereo Output noise level <... -
Page 8: Block Diagram
Block diagram Routing A set to INPUT 1(L+R) Routing A set to INPUT 1(L) & INPUT 2(R) Routing A set to INPUT 2(L+R) - Page 9 | web: www.audioresolution.com MediaTech Central Europe, a.s., Drienova 34, 821 02 Bratislava, Slovak Republic (EU) Tel: +421 2 20 999 700...
